Lamborghini Huracan LP640 Performante Coupe - Dashboard Air Pipe

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Dashboard Air Pipe of Lamborghini Lamborghini Huracan LP640 Performante Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 4T0819382A
AIR GUIDE 		- 1 Enquire
003 4H0907658
Sensor For Air Quality And Air Humidity 		- 1 Enquire
009 4T0819267A
ATTACHMENT BARS 		- 1 Enquire
010 4T0819904M
FRESH AIR VENT 		- 1 Enquire
010 4T0819904J
Fresh Air Vent (opt - Mat Paint-right) 		- 1 Enquire
010 4T0819904K
FRESH AIR VENT 		- 1 Enquire
010 4T0819904B
FRESH AIR VENT 		- 1 Enquire
010 4T0819904H
FRESH AIR VENT 		- 1 Enquire
011 4T0819903H
FRESH AIR VENT 		- 1 Enquire
011 4T0819903K
FRESH AIR VENT 		- 1 Enquire
011 4T0819903M
FRESH AIR VENT 		- 1 Enquire
011 4T0819903J
Fresh Air Vent (opt - Mat Paint-left) 		- 1 Enquire
011 4T0819903B
FRESH AIR VENT 		- 1 Enquire
012 4T0819559A
Arm (side, Left) 		- 1 Enquire
012 4T0819560A
Arm (side, Right) 		- 1 Enquire
013 4T0819706B
Fresh Air Vent (forged-right) 		- 1 Enquire
013 4T0819706K
FRESH AIR VENT 		- 1 Enquire
013 4T0819706J
Fresh Air Vent (opt - Metallic Steel Painted-right) 		- 1 Enquire
013 4T0819706R
FRESH AIR VENT 		- 1 Enquire
013 4T0819706L
Fresh Air Vent (mat Paint-right) 		- 1 Enquire
013 4T0819705L
Fresh Air Vent (mat Paint-left) 		- 1 Enquire
013 4T0819705R
FRESH AIR VENT 		- 1 Enquire
013 4T0819705Q
FRESH AIR VENT 		- 1 Enquire
013 4T0819705K
FRESH AIR VENT 		- 1 Enquire
013 4T0819706Q
FRESH AIR VENT 		- 1 Enquire
013 4T0819706H
FRESH AIR VENT 		- 1 Enquire
013 4T0819705B
Fresh Air Vent (forged-left) 		- 1 Enquire
013 4T0819705H
FRESH AIR VENT 		- 1 Enquire
013 4T0819705J
Fresh Air Vent (opt - Metallic Steel Painted-left) 		- 1 Enquire
014 4T0819946
ARM 		- 1 Enquire
014 4T0819945
ARM 		- 1 Enquire
015 4T0819889A
Air Guide Grille (left) 		- 1 Enquire
015 4T0819890A
Air Guide Grille (right) 		- 1 Enquire
017 N91173301
HEX. NUT WITH WASHER 		- 7 Enquire
018 N10738101
HEX SOCKET HEAD BOLT (COMBI) 		- 10 Enquire
019 400863119
BUNGS 		- 12 Enquire
021 4B0820539
TEMPERATURE SENSOR 		- 1 Enquire
023 4T0819621
BLANKET 		- 1 Enquire
