REAR ARMS of Lamborghini Lamborghini Huracan LP610 Spyder

View All

Lamborghini Huracan LP610 Spyder - REAR ARMS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	8K0407613B	WHEEL HUB	$301.28	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	8E0407643A	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	$13.54	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	WHT007142	HEXAGON BOLT	$8.48	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	WHT002059	BOLT, HEX HEAD WITH SHOULDER (COMBI)	$6.14	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	WHT000237	BALL SCREW	$7.21	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10660901	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	$6.86	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10405604	OVAL HEXAGON SOCKET HEAD BOLT	$1.25	IN STOCK

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
01	4T0505433C	REAR LEFT HUB CARRIER (CONTACT YOUR AREA MANAGER)	4T0505433C REAR LEFT HUB CARRIER (CONTACT YOUR AREA MANAGER)	$665.33	1
01	4T0505434C	REAR RIGHT HUB CARRIER (CONTACT YOUR AREA MANAGER)	4T0505434C REAR RIGHT HUB CARRIER (CONTACT YOUR AREA MANAGER)	$694.91	1
02	4T0505311A	WISHBONE	4T0505311A WISHBONE	$638.45	1
02	4T0505312A	WISHBONE	4T0505312A WISHBONE	$638.45	1
03	4T0505324	WISHBONE	4T0505324 WISHBONE	$1,209.67	1
03	4T0505323	WISHBONE	4T0505323 WISHBONE	$610.21	1
04	4S0501529B	TRACK ROD IN STOCK	4S0501529B TRACK ROD IN STOCK	$810.77	2
05	8K0407625F	DUOBLE BALL BEARING IN STOCK	8K0407625F DUOBLE BALL BEARING IN STOCK	$322.09	2
06	4S0941273D	LEVEL SENSOR WITH POLES	4S0941273D LEVEL SENSOR WITH POLES	$215.74	1
06	4S0941274D	LEVEL SENSOR WITH POLES IN STOCK	4S0941274D LEVEL SENSOR WITH POLES IN STOCK	$222.85	1
08	4S0407203E	BALANCING PLATE IN STOCK	4S0407203E BALANCING PLATE IN STOCK	$8.19	4
08	4S0407203G	BALANCING PLATE IN STOCK	4S0407203G BALANCING PLATE IN STOCK	$7.93	4
08	4S0407203D	BALANCING PLATE IN STOCK	4S0407203D BALANCING PLATE IN STOCK	$8.19	4
08	4S0407203C	BALANCING PLATE IN STOCK	4S0407203C BALANCING PLATE IN STOCK	$7.93	4
09	WHT004898	HEXAGON COLLAR NUT SELF-LOCKING IN STOCK	WHT004898 HEXAGON COLLAR NUT SELF-LOCKING IN STOCK	$7.13	4
10	8K0407613B	WHEEL HUB IN STOCK	8K0407613B WHEEL HUB IN STOCK	$301.28	2
12	8E0407643A	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD IN STOCK	8E0407643A SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD IN STOCK	$13.54	2
13	WHT007142	HEXAGON BOLT IN STOCK	WHT007142 HEXAGON BOLT IN STOCK	$8.48	8
14	WHT002059	BOLT, HEX HEAD WITH SHOULDER (COMBI) IN STOCK	WHT002059 BOLT, HEX HEAD WITH SHOULDER (COMBI) IN STOCK	$6.14	8
15	WHT000237	BALL SCREW IN STOCK	WHT000237 BALL SCREW IN STOCK	$7.21	8
16	N10660901	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD IN STOCK	N10660901 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD IN STOCK	$6.86	8
17	N10405604	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N10405604 OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	$1.25	8
