Fuel Pump

Lamborghini Huracan LP580 Coupe

Find Your Part

Lamborghini Huracan LP580 Coupe - Fuel Pump

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Fuel Pump of Lamborghini Lamborghini Huracan LP580 Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 7L127025S
FUEL PUMP 		- 2 Enquire
002 79121129
SPACER BUSH 		- 4 Enquire
003 N10451408
OVAL HEXAGON SOCKET HEAD BOLT 		- 4 Enquire
004 7L127411E
RETAINER FOR FUEL LINE 		- 4 Enquire
005 7L127509BK
FUEL PIPE (RIGHT) 		- 1 Enquire
006 N90986501
SPRING BAND CLAMP 		- 8 Enquire
007 WHT005184
O-RING 		- 2 Enquire
008 6E127065
DRAIN CONNECTION 		- 2 Enquire
009 7L127501BQ
FUEL LINE 		- 1 Enquire
009 7L127501BJ
FUEL LINE 		- 1 Enquire
010 6E127065C
DRAIN CONNECTION 		- 4 Enquire
011 7L127509BR
FUEL LINE 		- 1 Enquire
012 7L127509BE
FUEL PIPE (RIGHT) 		- 1 Enquire
013 7L127509CD
FUEL PIPE (LEFT) 		- 1 Enquire
014 N10405604
OVAL HEXAGON SOCKET HEAD BOLT 		- 2 Enquire
015 7L127503AE
FUEL RAIL 		- 1 Enquire
016 6E906051K
FUEL PRESSURE SENSOR 		- 1 Enquire
018 7L127509AN
FUEL HOSE 		- 1 Enquire
019 7L127503AC
FUEL RAIL 		- 1 Enquire
020 N90925202
HEXAGON SOCKET HEAD COLLARED BOLT, THREAD FORMING 		- 2 Enquire
021 7L201215A
FUEL PIPE 		- 1 Enquire
022 7L127509BQ
FUEL PIPE (LEFT) 		- 1 Enquire
023 N91020301
SPRING BAND CLAMP 		- 2 Enquire
