Front Brakes Discs of Lamborghini Lamborghini Gallardo Superleggera

View All

Lamborghini Gallardo Superleggera - Front Brakes Discs

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	400615302B	Front Brake Disc RH	400615302B Front Brake Disc RH	-	1	Enquire
001	400615302E	RH FRONT BRAKE DISK (CARBOCERAMIC BRAKE)	400615302E RH FRONT BRAKE DISK (CARBOCERAMIC BRAKE)	-	1	Enquire
001	400615301E	LH FRONT BRAKE DISK (CARBOCERAMIC BRAKE)	400615301E LH FRONT BRAKE DISK (CARBOCERAMIC BRAKE)	-	1	Enquire
001	400615301B	LH Front Brake Disc	400615301B LH Front Brake Disc	-	1	Enquire
002	400615106R	RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - BLACK FRONT CALIPERS)	400615106R RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - BLACK FRONT CALIPERS)	-	1	Enquire
002	400615106AA	RH FRONT BRAKE CALIPER (SILVER)	400615106AA RH FRONT BRAKE CALIPER (SILVER)	-	1	Enquire
002	400615106AB	RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - GREY FRONT CALIPERS)	400615106AB RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - GREY FRONT CALIPERS)	-	1	Enquire
002	400615106T	RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - YELLOW FRONT CALIPERS)	400615106T RH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - YELLOW FRONT CALIPERS)	-	1	Enquire
002	400615106Q	RH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS)	400615106Q RH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS)	-	1	Enquire
002	400615105AB	LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - GREY FRONT CALIPERS)	400615105AB LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - GREY FRONT CALIPERS)	-	1	Enquire
002	400615105Q	LH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS)	400615105Q LH FRONT BRAKE CALIPER (BLACK FRONT CALIPERS)	-	1	Enquire
002	400615105AA	LH FRONT BRAKE CALIPER (SILVER)	400615105AA LH FRONT BRAKE CALIPER (SILVER)	-	1	Enquire
002	400615105R	LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - BLACK FRONT CALIPERS)	400615105R LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - BLACK FRONT CALIPERS)	-	1	Enquire
002	400615106S	RH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS)	400615106S RH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS)	-	1	Enquire
002	400615105S	LH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS)	400615105S LH FRONT BRAKE CALIPER (YELLOW FRONT CALIPERS)	-	1	Enquire
002	400615105T	LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - YELLOW FRONT CALIPERS)	400615105T LH FRONT BRAKE CALIPER (CARBOCERAMIC BRAKE - YELLOW FRONT CALIPERS)	-	1	Enquire
003	400611775A	HOSE	400611775A HOSE	-	2	Enquire
004	WHT003303	SCREW WITH HOLE	WHT003303 SCREW WITH HOLE	-	2	Enquire
005	WHT001191	WASHER	WHT001191 WASHER	-	4	Enquire
006	400615376A	RH BRACKET	400615376A RH BRACKET	-	1	Enquire
006	400615375A	LH BRACKET	400615375A LH BRACKET	-	1	Enquire
007	N10581101	SCREW	N10581101 SCREW	-	2	Enquire
008	WHT001330A	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	WHT001330A SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	-	2	Enquire
009	400698151	Front Brake Pad Set	400698151 Front Brake Pad Set	-	1	Enquire
010	400615273	BLEEDER	400615273 BLEEDER	-	2	Enquire
011	400615325	KIT BOOT (INCLUDES 20 BOOT)	400615325 KIT BOOT (INCLUDES 20 BOOT)	-	1	Enquire
012	400698135	JOURNAL AND CLIP	400698135 JOURNAL AND CLIP	-	2	Enquire
013	400611691	SEAL RING	400611691 SEAL RING	-	2	Enquire
014	4S0698151AA	1 SET OF BRAKE PADS FOR DISK BRAKE	4S0698151AA 1 SET OF BRAKE PADS FOR DISK BRAKE	-	1	Enquire
015	400698137	BRAKE PAD WEAR SENSOR	400698137 BRAKE PAD WEAR SENSOR	-	2	Enquire
016	N10289701	SCREW M6X16	N10289701 SCREW M6X16	-	2	Enquire
017	R1400210	1 SET SPRINGS	R1400210 1 SET SPRINGS	-	1	Enquire
