Power Steering of Lamborghini Lamborghini Gallardo Superleggera

View All

Lamborghini Gallardo Superleggera - Power Steering

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	400422857A	RETURN HOSE	400422857A RETURN HOSE	-	1	Enquire
002	4B0422379	SPRING BAND CLAMP	4B0422379 SPRING BAND CLAMP	-	2	Enquire
003	400422371	OIL TANK	400422371 OIL TANK	-	1	Enquire
005	N90749002	HEXAGON HEAD BOLT (COMBI)	N90749002 HEXAGON HEAD BOLT (COMBI)	-	4	Enquire
006	N10124308	OVAL HEXAGON SOCKET HEAD BOLT	N10124308 OVAL HEXAGON SOCKET HEAD BOLT	-	3	Enquire
007	400422279A	SCREW WITH HOLE	400422279A SCREW WITH HOLE	-	1	Enquire
008	N0138481	WASHER	N0138481 WASHER	-	2	Enquire
009	400145153C	PUMP	400145153C PUMP	-	1	Enquire
010	408422890	PIPE	408422890 PIPE	-	1	Enquire
011	57145225D	DRIVE SHAFT	57145225D DRIVE SHAFT	-	1	Enquire
012	79145115B	PIN	79145115B PIN	-	2	Enquire
013	N10418001	CLAMP	N10418001 CLAMP	-	1	Enquire
014	WHT000417	O-Ring	WHT000417 O-Ring	-	1	Enquire
015	400422973	HOSE	400422973 HOSE	-	1	Enquire
016	400422293C	CONNECTOR	400422293C CONNECTOR	-	1	Enquire
017	402422893J	HOSE (OIL FLOW)	402422893J HOSE (OIL FLOW)	-	1	Enquire
018	N206253	CLAMP	N206253 CLAMP	-	2	Enquire
019	400611799B	BRACKET	400611799B BRACKET	-	1	Enquire
020	400611799A	CLIP	400611799A CLIP	-	2	Enquire
021	400422887A	PIPE	400422887A PIPE	-	1	Enquire
022	N90686901	SPRING BAND CLAMP	N90686901 SPRING BAND CLAMP	-	1	Enquire
023	N0206104	CLAMP	N0206104 CLAMP	-	2	Enquire
024	408422493	SUPPORT	408422493 SUPPORT	-	1	Enquire
025	400422360	PLUG	400422360 PLUG	-	1	Enquire
026	N90533002	SCREW	N90533002 SCREW	-	2	Enquire
027	N90533002	SCREW	N90533002 SCREW	-	2	Enquire
028	N90533002	SCREW	N90533002 SCREW	-	2	Enquire
029	400422929	CONNECTOR	400422929 CONNECTOR	-	1	Enquire
040	N10082911	SCREW M6X16	N10082911 SCREW M6X16	-	2	Enquire
041	431129669	GROMMET	431129669 GROMMET	-	2	Enquire
042	N10562301	CABLE TIES	N10562301 CABLE TIES	-	2	Enquire
