Exhaust System 2

Lamborghini Gallardo Spyder

Find Your Part

Lamborghini Gallardo Spyder - Exhaust System 2

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Exhaust System 2 of Lamborghini Lamborghini Gallardo Spyder Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 N0245097
CLAMP 		- 1 Enquire
002 407611937B
HOSE 		- 1 Enquire
003 N10201901
CLAMP 		- 1 Enquire
004 400611921
CONNECTOR 		- 1 Enquire
005 443131541
VACUUM TANK ASSEMBLY 		- 1 Enquire
006 N10017303
NUT 		- 1 Enquire
007 7L131611C
HOSE 		- 1 Enquire
008 407906217B
BRACKET 		- 1 Enquire
009 N0902612
SCREW (M6X20) 		- 1 Enquire
010 407131381
PIPE 		- 1 Enquire
011 7L131694
BRACKET 		- 5 Enquire
012 WHT001194
SCREW 		- 6 Enquire
013 400127217
CLAMP 		- 28 Enquire
014 400131849A
HOSE 		- 2 Enquire
015 7M131208
PIPE 		- 2 Enquire
016 400131385E
PIPE 		- 1 Enquire
017 N90937701
CABLE TIES 		- 4 Enquire
018 7M131543
PROTECTION 		- 2 Enquire
020 400131585A
CONNECTOR 		- 1 Enquire
021 400131846
HOSE 		- 2 Enquire
022 400131843
HOSE 		- 1 Enquire
023 400131791
CONNECTOR 		- 1 Enquire
024 7L131461A
HOSE 		- 1 Enquire
025 400131245A
CONNECTOR 		- 1 Enquire
027 400906407
BRACKET 		- 1 Enquire
028 N0161661
RIVET (4.0X10.0) 		- 2 Enquire
029 77906283
SOLENOID VALVE 		- 1 Enquire
030 400131850B
HOSE 		- 1 Enquire
031 400131845A
HOSE 		- 1 Enquire
032 400133587
REDUCTION 		- 1 Enquire
033 7M131145A
PIPE 		- 1 Enquire
037 46905291B
NON-RETURN VALVE 		- 1 Enquire
