Elettrical System

Lamborghini Gallardo LP570 4 SL

Find Your Part

Lamborghini Gallardo LP570 4 SL - Elettrical System

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Elettrical System of Lamborghini Lamborghini Gallardo LP570 4 SL Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 408971140AA
CENTRAL WIRING HARNESS (RNSE / AMI) 		- 1 Enquire
001 404971140
CENTRAL WIRING HARNESS (WITHOUT MULTIMEDIA SYSTEM AND ELECTRONIC PREPARATION) 		- 1 Enquire
003 402971035D
DOOR WIRING HARNESS (DRIVER SIDE) 		- 1 Enquire
003 400971036D
DOOR WIRING HARNESS (PASSENGER SIDE) 		- 1 Enquire
003 404971035
DOOR WIRING HARNESS (DRIVER SIDE / IMOBILIZATION DEVICE) 		- 1 Enquire
003 403971036
DOOR WIRING HARNESS (PASSENGER SIDE - VERSIONS WITHOUT RNSE) 		- 1 Enquire
008 400971194B
WIRING HARNESS 		- 1 Enquire
011 408971551AD
WIRING HARNESS INFOTAINMENT (RNSE / AMI / REAR VIEW CAMERA / BLUETOOTH) 		- 1 Enquire
011 408971551AE
WIRING HARNESS INFOTAINMENT (RNSE / AMI / BLUETOOTH) 		- 1 Enquire
013 400971235B
CABLE 		- 1 Enquire
015 400971793D
CABLE (CABLE STARTER MOTOR EXCITATION) 		- 1 Enquire
017 408971320L
WIRING HARNESS DASHBOARD (VERSIONS WITH NAVIGATOR) 		- 1 Enquire
017 408971320K
WIRING HARNESS DASHBOARD (VERSIONS WITHOUT NAVIGATOR) 		- 1 Enquire
018 400971679A
WIRING HARNESS (PASSENGER SIDE DRAWER) 		- 1 Enquire
019 400971899
CLAMP ( - 23 MM) 		- 4 Enquire
026 N10003703
SCREW M6X17.00 (M6X17) 		- 4 Enquire
