View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	51000542	FRONT TYRE	51000542 FRONT TYRE PNEUMATICO ANT. 235/35 ZR 18	-	2	Enquire
002	5236291	ORNAMENT	5236291 ORNAMENT FREGIO -USE: 0052006285	-	2	Enquire
003	5335195	SUPPORT - SUPPORTO	5335195 SUPPORT - SUPPORTO O	-	2	Enquire
004	5330906	VALVE	5330906 VALVE VALVOLA	-	2	Enquire
005	410407338	NUT	410407338 NUT DADO	-	2	Enquire
006	410407631	WASHER	410407631 WASHER	-	2	Enquire
007	51001039	HUB	51001039 HUB MOZZO	-	2	Enquire
008	51000983	LEFT HUB HOUSING	51000983 LEFT HUB HOUSING PORTAMOZZO SX	-	1	Enquire
008	51000984	RIGHT HUB HOUSING	51000984 RIGHT HUB HOUSING PORTAMOZZO DX	-	1	Enquire
009	8514501	BEARING	8514501 BEARING CUSCINETTO	-	2	Enquire
010	5233369	PLUG	5233369 PLUG GHIERA	-	2	Enquire
011	51001033	PHONIC WHEEL	51001033 PHONIC WHEEL RUOTA FONICA	-	2	Enquire
012	51001038	PIN	51001038 PIN PERNO	-	2	Enquire
013	51001075LB	LOCKING WHEEL BOLT SET	51001075LB LOCKING WHEEL BOLT SET (includes 1 bolt for each wheel and removal tool)	-	1	Enquire
013	51001075	STUD	51001075 STUD COLONNETTA	-	10	Enquire
014	51001073	FRONT RIM	51001073 FRONT RIM CERCHIO RUOTA ANTERIORE	-	2	Enquire
015	51001139	TYRE REVOLUT. SENS.	51001139 TYRE REVOLUT. SENS. SENSORE GIRI RUOTA LAVOR.	-	2	Enquire
016	51001477	SUPPORT - SUPPORTO	51001477 SUPPORT - SUPPORTO O	-	2	Enquire
017	8400606	WASHER	8400606 WASHER RONDELLA	-	2	Enquire
018	8410611	WASHER	8410611 WASHER RONDELLA	-	2	Enquire
019	8100603	SCREW	8100603 SCREW VITE	-	2	Enquire
