Electrical System 3 of Lamborghini Lamborghini Diablo SV (1995-1997)

View All

Lamborghini Diablo SV (1995-1997) - Electrical System 3

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	5931167	KNOB	5931167 KNOB POMELLO	$89.84	1
002	5931299	FLANGE	5931299 FLANGE FLANGIA	$233.25 MSRP: ~~243.50~~ (4.2% off)	1
003	5931163	CONNECTING BLOCK	5931163 CONNECTING BLOCK STACCABATTERIA	$235.12	1
004	6137476	ELECT CABLE	6137476 ELECT CABLE CAVO ELETTRICO	$72.09	1
005	6137471	CONNECTION	6137471 CONNECTION CONNESSIONE	-	1	Enquire
006	5937655	SUPPORT - SUPPORTO	5937655 SUPPORT - SUPPORTO O	-	2	Enquire
007	6137473	ELECT CABLE	6137473 ELECT CABLE CAVO ELETTRICO	$183.83	1
008	6135923	GROUND CABLE	6135923 GROUND CABLE CAVO MASSA	$81.76	1
009	6137478	CASE	6137478 CASE SCATOLA MEGA	-	2	Enquire
010	6137475	ELECT CABLE	6137475 ELECT CABLE CAVO ELETTRICO FUSE	$256.22	1
011	6137474	ELECT CABLE	6137474 ELECT CABLE CAVO ELETTRICO	$95.43	1
012	1624948	BATTERY	1624948 BATTERY BATTERIA	$1,147.87	1
013	4130608	PLATE	4130608 PLATE STAFFA	$32.49	1
014	WHT002962	WASHER 14X8.4X1.5 IN STOCK	WHT002962 WASHER 14X8.4X1.5 RONDELLA IN STOCK	$0.33 MSRP: ~~7.35~~ (95.5% off)	1
015	8410819	WASHER	8410819 WASHER RONDELLA	$2.29 MSRP: ~~2.40~~ (4.6% off)	1
016	8700815	SCREW IN STOCK	8700815 SCREW VITE IN STOCK	$0.21 MSRP: ~~7.36~~ (97.1% off)	1
017	6134543	SHIELD	6134543 SHIELD PROTEZIONE	$57.82	1
018	6136784	GROUND CABLE	6136784 GROUND CABLE CAVO MASSA	$85.98 MSRP: ~~86.90~~ (1.1% off)	1
019	8832006	STRAP	8832006 STRAP FASCETTA	$2.99	3
020	6137477	ELECT CABLE	6137477 ELECT CABLE CAVO ELETTRICO	$80.51	1
021	5936741	TAP BATTERY CHARG.	5936741 TAP BATTERY CHARG. PRESA PER CARICA BATTERIA	$17.99 MSRP: ~~18.20~~ (1.2% off)	1
022	5937868	GROUND CONNEC.	5937868 GROUND CONNEC. LINGUETTA PER PR. CARICA BATT.	$17.37 MSRP: ~~18.05~~ (3.8% off)	1
023	6137479	FUSE	6137479 FUSE FUSIBILE250A	$12.81	1
024	5937037	SUPPORT - SUPPORTO	5937037 SUPPORT - SUPPORTO O	$317.62	1
025	5937026	SUPPORT - SUPPORTO	5937026 SUPPORT - SUPPORTO O	$94.67	1
026	5937027	SUPPORT - SUPPORTO	5937027 SUPPORT - SUPPORTO O	$34.68	1
