Steering 4 of Lamborghini Lamborghini Diablo VT Roadster (1998-2000)

View All

Lamborghini Diablo VT Roadster (1998-2000) - Steering 4

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	4036976	PIPE	4036976 PIPE TUBO	$10.79	1
002	8100618	SCREW	8100618 SCREW VITE	$0.28 MSRP: ~~7.35~~ (96.2% off)	2
003	8831320	STRAP	8831320 STRAP FASCETTA	$3.24	6
004	5134584	RIGID PIPE	5134584 RIGID PIPE TUBO	$150.74	1
005	4036492	BUSHING	4036492 BUSHING BUSSOLA	-	4	Enquire
006	4036493	NUT	4036493 NUT DADO	$6.45 MSRP: ~~6.70~~ (3.7% off)	2
007	4036490	CONNECTION	4036490 CONNECTION RACCORDO	$21.05 MSRP: ~~21.95~~ (4.1% off)	2
008	4034577	PIPE	4034577 PIPE TUBO	$4.16 MSRP: ~~4.30~~ (3.3% off)	1
009	4037387	W/W RESERVOIR	4037387 W/W RESERVOIR SERBATOIO	-	1	Enquire
010	N91122801	WASHER 18,5X24X1,5 IN STOCK	N91122801 WASHER 18,5X24X1,5 RONDELLA IN STOCK	$3.05 MSRP: ~~7.18~~ (57.5% off)	3
011	4037389	CONNECTION	4037389 CONNECTION RACCORDO	$227.67	1
012	4037377	WASHER	4037377 WASHER RONDELLA	$3.92	2
013	4009760	SCREW	4009760 SCREW VITE FORATA	-	2	Enquire
014	WHT002961	WASHER IN STOCK	WHT002961 WASHER RONDELLA IN STOCK	$0.42	2
015	N01118312	HEXAGON NUT, SELF-LOCKING IN STOCK	N01118312 HEXAGON NUT, SELF-LOCKING DADO IN STOCK	$2.04	2
016	4037205	PIPE	4037205 PIPE TUBO	$54.94	1
017	4033472	CONNECTION	4033472 CONNECTION RACCORDO	$17.00 MSRP: ~~17.20~~ (1.2% off)	3
018	4036816	OIL PUMP	4036816 OIL PUMP POM PA	$4,668.10	1
019	4033467	CONNECTION	4033467 CONNECTION RACCORDO	$93.54 MSRP: ~~97.80~~ (4.4% off)	1
020	N90226404	HEXAGON COLLAR NUT SELF-LOCKING	N90226404 HEXAGON COLLAR NUT SELF-LOCKING DADO	$2.29 MSRP: ~~7.22~~ (68.3% off)	2
021	WHT002962	WASHER 14X8.4X1.5 IN STOCK	WHT002962 WASHER 14X8.4X1.5 RONDELLA IN STOCK	$0.33 MSRP: ~~7.35~~ (95.5% off)	2
022	1737044	PIN	1737044 PIN PERNO	$186.73	2
023	4037039	SCREW	4037039 SCREW VITE	$48.23	2
024	WHT002962	WASHER 14X8.4X1.5 IN STOCK	WHT002962 WASHER 14X8.4X1.5 RONDELLA IN STOCK	$0.33 MSRP: ~~7.35~~ (95.5% off)	4
025	4037040	SUPPORT - (Valid for vehicles with lifting system) SUPPORTO	4037040 SUPPORT - (Valid for vehicles with lifting system) SUPPORTO O	$120.36	1
026	1736808	FLEXIBLE JOINT	1736808 FLEXIBLE JOINT GIUNTO ELASTICO	$584.37	1
027	WHT003040	WASHER 5.3X1.5X15 (For Becker Radio System)	WHT003040 WASHER 5.3X1.5X15 (For Becker Radio System) RONDELLA	$7.53	2
028	N0211963	NUT IN STOCK	N0211963 NUT DADO IN STOCK	$0.76	2
029	4034570	VALVE	4034570 VALVE GRUPPO VALVOLE	$1,013.65 MSRP: ~~1,060.00~~ (4.4% off)	1
030	4033465	PIPE	4033465 PIPE TUBO	$506.62	1
031	4034582	PIPE	4034582 PIPE TUBO	$663.77 MSRP: ~~692.00~~ (4.1% off)	1
032	4036491	CONNECTION	4036491 CONNECTION RACCORDO	-	1	Enquire
033	4037104	SUPPORT - SUPPORTO	4037104 SUPPORT - SUPPORTO O	$178.66	1
034	8410820	WASHER	8410820 WASHER RONDELLA	$0.19 MSRP: ~~7.37~~ (97.4% off)	3
035	N01029315	SCREW (FROM VIN 5LA01545)	N01029315 SCREW (FROM VIN 5LA01545) VITE	$1.22 MSRP: ~~7.23~~ (83.1% off)	3
036	8100613	SCREW	8100613 SCREW VITE	$0.27 MSRP: ~~7.35~~ (96.3% off)	2
037	WHT002961	WASHER IN STOCK	WHT002961 WASHER RONDELLA IN STOCK	$0.42	2
038	5134578	RIGID PIPE	5134578 RIGID PIPE TUBO	$26.42	1
039	4036494	SUPPORT - (Valid for vehicles with lifting system) SUPPORTO	4036494 SUPPORT - (Valid for vehicles with lifting system) SUPPORTO O	-	1	Enquire
040	WHT002961	WASHER IN STOCK	WHT002961 WASHER RONDELLA IN STOCK	$0.42	2
