COMFORT SEAT of Lamborghini Lamborghini Aventador LP780 Ultimae Roadster

View All

Lamborghini Aventador LP780 Ultimae Roadster - COMFORT SEAT (881.01.00)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN

IN STOCK

AS

ARRIVING SOON

TO

To Order

PE

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	470881003	COMPLETE SEAT WITH BACKREST AND HEADREST, MECHANICALLY ADJUSTABLE	$12,069.86	To Order
	470881003A	COMPLETE SEAT WITH BACKREST AND HEADREST, ELECTRICALLY ADJUSTABLE	$15,174.70	To Order
	470881004	COMPLETE SEAT WITH BACKREST AND HEADREST, MECHANICALLY ADJUSTABLE	$12,069.86	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	470881152	HEAD RESTRAINT COVER	$178.78	To Order
	470881152A	HEAD RESTRAINT COVER	$2,056.46	To Order
	470881152B	HEAD RESTRAINT COVER	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	470881463E	BACKREST MAT	$663.98	To Order
	470881463F	BACKREST MAT	$6,538.96	To Order
	470881463G	BACKREST MAT	Enquire	To Order

...and 3 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	470881087B	COVER	$50.50	To Order

Photo	Part No	Description	Price (each)	Stock
	470881097J	SEAT PAD	$3,461.01	To Order
	470881097L	SEAT PAD	$3,461.01	To Order
	470881097M	SEAT PAD	$446.23	To Order

...and 7 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	8K0959817	SETTING KNOB	Enquire	To Order
	8K09598174PK	SETTING KNOB	$38.06	To Order
	8K0959818	SETTING KNOB	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	3C0959817	PUSHBUTTON CAP	$229.18	To Order
	3C0959818	PUSHBUTTON CAP	$229.18	To Order
	8K0959815	SETTING KNOB	$2.23	To Order

...and 3 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	4H0959777A	SWITCH FOR LUMBAR SUPPORT ADJUSTMENT	$78.09	To Order

Photo	Part No	Description	Price (each)	Stock
	1K0959777	SWITCH FOR BACKREST ADJUSTING	$50.40	To Order
	1K0959778	SWITCH FOR BACKREST ADJUSTING	$50.40	To Order
	8K0959747	SWITCH FOR SEAT LONGITUDINAL- SEAT HEIGHT- SEAT RAKE AND BACKREST ADJUSTMENT	$143.17	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	N91136801	HEXAGON SOCKET HEAD PANEL BOLT	$0.37	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470881743	FASTENING CLIP	$3.98	To Order

Photo	Part No	Description	Price (each)	Stock
	N91049601	OVAL HEAD PANEL SCREW (COMBI)	$0.67	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10430103	HEXAGON SOCKET FLAT HEAD BOLT	$0.80	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10578904	FLAT ROUND HEAD BOLT	$1.68	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N01152721	WASHER	$1.63	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470959245A	SEAT ADJUSTMENT MOTOR FOR LONGITUDINAL ADJUSTMENT	$977.16	To Order

Photo	Part No	Description	Price (each)	Stock
	470881265	BOWDEN CABLE FOR SEAT HEIGHT ADJUSTMENT	$149.20	To Order

Photo	Part No	Description	Price (each)	Stock
	470881901A	HEAD RESTRAINT WITH COVER	$900.55	To Order

Photo	Part No	Description	Price (each)	Stock
	470881901	HEAD RESTRAINT	$799.73	To Order

Photo	Part No	Description	Price (each)	Stock
	470898010	1 SET ATTACHMENT PARTS	$164.00	To Order

Photo	Part No	Description	Price (each)	Stock
	470881219	GUIDE RAIL FOR SEAT	$409.95	To Order
	470881219A	GUIDE RAIL FOR SEAT	$2,291.65	To Order

Photo	Part No	Description	Price (each)	Stock
	470971365B	SEAT FRAME WIRING HARNESS	$291.01	To Order
	470971365C	SEAT FRAME WIRING HARNESS	$775.54	To Order
	470971366F	SEAT FRAME WIRING HARNESS	$486.56	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	8K0980341B	SEAT POSITION SENSOR	$24.87	To Order

Photo	Part No	Description	Price (each)	Stock
	470898053	SUNDRY PARTS SET	$66.07	To Order

View All

COMFORT SEAT of Lamborghini Lamborghini Aventador LP780 Ultimae Roadster

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

	#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Order Qty	Add to Cart
	1	470881003	COMPLETE SEAT WITH BACKREST AND HEADREST, MECHANICALLY ADJUSTABLE	470881003 COMPLETE SEAT WITH BACKREST AND HEADREST, MECHANICALLY ADJUSTABLE LEFT MANUAL SEAT - SUPPLY VIN-LEFT	$12,069.86	1
	1	470881003A	COMPLETE SEAT WITH BACKREST AND HEADREST, ELECTRICALLY ADJUSTABLE	470881003A COMPLETE SEAT WITH BACKREST AND HEADREST, ELECTRICALLY ADJUSTABLE LEFT ELECTRIC SEAT - SUPPLY VIN-LEFT	$15,174.70	1
	1	470881004	COMPLETE SEAT WITH BACKREST AND HEADREST, MECHANICALLY ADJUSTABLE	470881004 COMPLETE SEAT WITH BACKREST AND HEADREST, MECHANICALLY ADJUSTABLE RIGHT MANUAL SEAT - SUPPLY VIN-RIGHT	$12,069.86	1
	1	470881004A	COMPLETE SEAT WITH BACKREST AND HEADREST, ELECTRICALLY ADJUSTABLE	470881004A COMPLETE SEAT WITH BACKREST AND HEADREST, ELECTRICALLY ADJUSTABLE RIGHT ELECTRIC SEAT - SUPPLY VIN-RIGHT	$15,174.70	1
	2	470881152	HEAD RESTRAINT COVER	470881152 HEAD RESTRAINT COVER	$178.78	2
	2	470881152A	HEAD RESTRAINT COVER	470881152A HEAD RESTRAINT COVER CARBON INTERIOR-LEFT A. RIGHT	$2,056.46	2
	2	470881152B	HEAD RESTRAINT COVER	470881152B HEAD RESTRAINT COVER MATT CARBON PACK	-	1		Enquire
	2	470881998	HEAD RESTRAINT COVER	470881998 HEAD RESTRAINT COVER SUPPLY VIN	$747.31	2
	3	470881463E	BACKREST MAT	470881463E BACKREST MAT LEFT	$663.98	1
	3	470881463F	BACKREST MAT	470881463F BACKREST MAT CARBON SHINY-LEFT	$6,538.96	1
	3	470881463G	BACKREST MAT	470881463G BACKREST MAT MATT CARBON PACK-LEFT	-	1		Enquire
	3	470881464F	BACKREST MAT	470881464F BACKREST MAT RIGHT	$576.62	1
	3	470881464G	BACKREST MAT	470881464G BACKREST MAT CARBON SHINY-RIGHT	$6,538.96	1
	3	470881464H	BACKREST MAT	470881464H BACKREST MAT MATT CARBON PACK-RIGHT	-	1		Enquire
	4	470881087B	COVER	470881087B COVER SPORT SEAT	$50.50	2
	5	470881097J	SEAT PAD	470881097J SEAT PAD CARBON INTERIOR-ELECTRIC LEFT	$3,461.01	1
	5	470881097L	SEAT PAD	470881097L SEAT PAD CARBON INTERIOR-MANUAL LEFT	$3,461.01	1
	5	470881097M	SEAT PAD	470881097M SEAT PAD MANUAL LEFT	$446.23	1
	5	470881097N	SEAT PAD	470881097N SEAT PAD CARBON SHINY-ELECTRIC LEFT	$434.16	1
	5	470881097Q	SEAT PAD	470881097Q SEAT PAD MATT CARBON PACK-ELECTRIC LEFT	-	1		Enquire
	5	470881098K	SEAT PAD	470881098K SEAT PAD CARBON INTERIOR-ELECTRIC RIGHT	$3,366.94	1
	5	470881098M	SEAT PAD	470881098M SEAT PAD CARBON INTERIOR-MANUAL RIGHT	$3,461.01	1
	5	470881098N	SEAT PAD	470881098N SEAT PAD MANUAL RIGHT	$361.57	1
	5	470881098P	SEAT PAD	470881098P SEAT PAD CARBON SHINY-ELECTRIC RIGHT	$434.16	1
	5	470881098R	SEAT PAD	470881098R SEAT PAD MATT CARBON PACK-ELECTRIC RIGHT	-	1		Enquire
	6	8K0959817	SETTING KNOB	8K0959817 SETTING KNOB LEFT	-	1		Enquire
	6	8K09598174PK	SETTING KNOB	8K09598174PK SETTING KNOB LEFT-SOUL (BLACK)	$38.06	1
	6	8K0959818	SETTING KNOB	8K0959818 SETTING KNOB RIGHT	-	1		Enquire
	6	8K09598184PK	SETTING KNOB	8K09598184PK SETTING KNOB RIGHT-SOUL (BLACK)	$9.08	1
	7	3C0959817	PUSHBUTTON CAP	3C0959817 PUSHBUTTON CAP MECHANICAL REGULATION - ELECTRICAL SEATBACK-MANUAL LEFT	$229.18	1
	7	3C0959818	PUSHBUTTON CAP	3C0959818 PUSHBUTTON CAP MECHANICAL REGULATION - ELECTRICAL SEATBACK-MANUAL RIGHT	$229.18	1
	7	8K0959815	SETTING KNOB	8K0959815 SETTING KNOB ELECTRICAL REGULATION-ELECTRIC LEFT	$2.23	1
	7	8K09598154PK	SETTING KNOB	8K09598154PK SETTING KNOB ELECTRICAL REGULATION - LEFT-SOUL (BLACK)	$38.06	1
	7	8K0959816	SETTING KNOB	8K0959816 SETTING KNOB ELECTRICAL REGULATION-ELECTRIC RIGHT	$2.23	1
	7	8K09598164PK	SETTING KNOB	8K09598164PK SETTING KNOB ELECTRICAL REGULATION - RIGHT-SOUL (BLACK)	$9.21	1
	8	4H0959777A	SWITCH FOR LUMBAR SUPPORT ADJUSTMENT	4H0959777A SWITCH FOR LUMBAR SUPPORT ADJUSTMENT	$78.09	2
	9	1K0959777	SWITCH FOR BACKREST ADJUSTING	1K0959777 SWITCH FOR BACKREST ADJUSTING MANUAL REGULATION-LEFT	$50.40	1
	9	1K0959778	SWITCH FOR BACKREST ADJUSTING	1K0959778 SWITCH FOR BACKREST ADJUSTING MANUAL REGULATION-RIGHT	$50.40	1
	9	8K0959747	SWITCH FOR SEAT LONGITUDINAL- SEAT HEIGHT- SEAT RAKE AND BACKREST ADJUSTMENT	8K0959747 SWITCH FOR SEAT LONGITUDINAL- SEAT HEIGHT- SEAT RAKE AND BACKREST ADJUSTMENT ELECTRICAL REGULATION-LEFT	$143.17	1
	9	8K0959748C	SWITCH FOR SEAT LONGITUDINAL- SEAT HEIGHT- SEAT RAKE AND BACKREST ADJUSTMENT	8K0959748C SWITCH FOR SEAT LONGITUDINAL- SEAT HEIGHT- SEAT RAKE AND BACKREST ADJUSTMENT ELECTRICAL REGULATION-RIGHT	$133.18	1
	10	N91136801	HEXAGON SOCKET HEAD PANEL BOLT IN STOCK	N91136801 HEXAGON SOCKET HEAD PANEL BOLT 4 -2X11 IN STOCK	$0.37	5
	11	470881743	FASTENING CLIP	470881743 FASTENING CLIP	$3.98	4
	12	N91049601	OVAL HEAD PANEL SCREW (COMBI) IN STOCK	N91049601 OVAL HEAD PANEL SCREW (COMBI) 4 -2X15 IN STOCK	$0.67 MSRP: ~~7.31~~ (90.8% off)	4
	13	N10430103	HEXAGON SOCKET FLAT HEAD BOLT IN STOCK	N10430103 HEXAGON SOCKET FLAT HEAD BOLT M5X16 IN STOCK	$0.80 MSRP: ~~7.30~~ (89% off)	4
	14	N10578904	FLAT ROUND HEAD BOLT IN STOCK	N10578904 FLAT ROUND HEAD BOLT M8X20 IN STOCK	$1.68 MSRP: ~~7.17~~ (76.6% off)	8
	15	N01152721	WASHER IN STOCK	N01152721 WASHER IN STOCK	$1.63 MSRP: ~~7.12~~ (77.1% off)	8
	17	470959245A	SEAT ADJUSTMENT MOTOR FOR LONGITUDINAL ADJUSTMENT	470959245A SEAT ADJUSTMENT MOTOR FOR LONGITUDINAL ADJUSTMENT	$977.16	1
	18	470881265	BOWDEN CABLE FOR SEAT HEIGHT ADJUSTMENT	470881265 BOWDEN CABLE FOR SEAT HEIGHT ADJUSTMENT	$149.20	2
	19	470881901A	HEAD RESTRAINT WITH COVER	470881901A HEAD RESTRAINT WITH COVER SUPPLY VIN - WITH LOGO	$900.55	2
	20	470881901	HEAD RESTRAINT	470881901 HEAD RESTRAINT SUPPLY VIN	$799.73	2
	23	470898010	1 SET ATTACHMENT PARTS	470898010 1 SET ATTACHMENT PARTS	$164.00	1
	24	470881219	GUIDE RAIL FOR SEAT	470881219 GUIDE RAIL FOR SEAT MANUAL	$409.95	1
	24	470881219A	GUIDE RAIL FOR SEAT	470881219A GUIDE RAIL FOR SEAT FULL ELECTRIC	$2,291.65	1
	25	470971365B	SEAT FRAME WIRING HARNESS	470971365B SEAT FRAME WIRING HARNESS MANUAL-LEFT LHD	$291.01	1
	25	470971365C	SEAT FRAME WIRING HARNESS	470971365C SEAT FRAME WIRING HARNESS FULL ELECTRIC-LEFT LHD	$775.54	1
	25	470971366F	SEAT FRAME WIRING HARNESS	470971366F SEAT FRAME WIRING HARNESS MANUAL-RIGHT LHD	$486.56	1
	25	470971366H	SEAT FRAME WIRING HARNESS	470971366H SEAT FRAME WIRING HARNESS FULL ELECTRIC-RIGHT LHD	$830.65	1
	25	472881365B	SEAT FRAME WIRING HARNESS	472881365B SEAT FRAME WIRING HARNESS MANUAL-LEFT RHD	$518.82	1
	25	472881365C	SEAT FRAME WIRING HARNESS	472881365C SEAT FRAME WIRING HARNESS FULL ELECTRIC-LEFT RHD	$775.54	1
	25	472881366E	SEAT FRAME WIRING HARNESS	472881366E SEAT FRAME WIRING HARNESS MANUAL-RIGHT RHD	-	1		Enquire
	25	472881366G	SEAT FRAME WIRING HARNESS	472881366G SEAT FRAME WIRING HARNESS FULL ELECTRIC-RIGHT RHD	$736.57	1
	27	8K0980341B	SEAT POSITION SENSOR	8K0980341B SEAT POSITION SENSOR	$24.87	2
	28	470898053	SUNDRY PARTS SET	470898053 SUNDRY PARTS SET	$66.07	1
