Name: OIL SUMP
Rating: 4.6 (1 reviews)

OIL SUMP of Lamborghini Lamborghini Aventador LP780 Ultimae Roadster

View All

Lamborghini Aventador LP780 Ultimae Roadster - OIL SUMP (103.02.00)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	N10709401	HEXAGON HEAD BOLT (COMBI)	$6.00	To Order

Photo	Part No	Description	Price (each)	Stock
	N10689302	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	$3.11	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	7M103121C	SEAL	$16.70	To Order

Photo	Part No	Description	Price (each)	Stock
	N91084501	O-RING	$7.56	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	7M103627	BUNGS	$42.22	To Order

Photo	Part No	Description	Price (each)	Stock
	22103139B	DOWEL SLEEVE	$7.80	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	7M103321B	CYLINDER LINER	$833.35	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT005218	SEAL RING	$9.94	To Order

Photo	Part No	Description	Price (each)	Stock
	7M103937A	BUNGS	$268.81	To Order

Photo	Part No	Description	Price (each)	Stock
	7M115540	OIL SPRAY JET	$255.40	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT000406	SEAL RING	$3.55	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N91014801	O-RING	$1.55	To Order

Photo	Part No	Description	Price (each)	Stock
	N90111301	O-RING	$0.30	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N90443601	O-RING	$8.80	To Order

Photo	Part No	Description	Price (each)	Stock
	50121113B	COOLANT REGULATOR	$70.81	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	7M103649	SEAL	$26.10	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N91084801	HEXAGON SOCKET HEAD BOLT	$0.83	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	7M121121E	COVER FOR THERMOSTAT	$766.14	To Order

Photo	Part No	Description	Price (each)	Stock
	7M919561	OIL PRESSURE SENDER	$296.38	To Order

Photo	Part No	Description	Price (each)	Stock
	N91096702	OVAL HEXAGON SOCKET HEAD BOLT	$1.34	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	79907601	IMPULSE SENDER	$176.09	To Order

Photo	Part No	Description	Price (each)	Stock
	N91096702	OVAL HEXAGON SOCKET HEAD BOLT	$1.34	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	7M103158E	AIR VENT	$1,458.36	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10456103	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	$0.51	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	59919523F	TEMPERATURE SENSOR	$64.33	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470971729	HEAT DEFLECTOR HOSE	$43.07	To Order

Photo	Part No	Description	Price (each)	Stock
	N10562301	CABLE TIES	$1.32	To Order

Photo	Part No	Description	Price (each)	Stock
	6H906433E	IMPULSE SENDER	$118.95	To Order

View All

Diagram Tap to enlarge

Oil Sump

Lamborghini Aventador LP780 Ultimae Roadster

Illustration Number: 103.02.00

Lamborghini Aventador LP780 Ultimae Roadster - OIL SUMP (103.02.00)

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	N10709401	HEXAGON HEAD BOLT (COMBI)	N10709401 HEXAGON HEAD BOLT (COMBI) M8X120X80	$6.00	1
2	N10689302	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD IN STOCK	N10689302 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD M8X25 IN STOCK	$3.11 MSRP: ~~7.17~~ (56.6% off)	24
3	7M103121C	SEAL	7M103121C SEAL	$16.70	1
4	N91084501	O-RING IN STOCK	N91084501 O-RING 63 -09X3,53 IN STOCK	$7.56	1
5	7M103627	BUNGS	7M103627 BUNGS	$42.22	1
6	22103139B	DOWEL SLEEVE IN STOCK	22103139B DOWEL SLEEVE 16X13 -5 IN STOCK	$7.80	6
7	7M103321B	CYLINDER LINER	7M103321B CYLINDER LINER 95	$833.35	12
8	WHT005218	SEAL RING	WHT005218 SEAL RING	$9.94	12
9	7M103937A	BUNGS	7M103937A BUNGS	$268.81	1
10	7M115540	OIL SPRAY JET	7M115540 OIL SPRAY JET	$255.40	1
11	WHT000406	SEAL RING IN STOCK	WHT000406 SEAL RING 24 -3X31,9X2 IN STOCK	$3.55	1
12	N91014801	O-RING	N91014801 O-RING 11 -11X1,78	$1.55 MSRP: ~~7.14~~ (78.3% off)	14
13	N90111301	O-RING IN STOCK	N90111301 O-RING 12 -42X1,78 IN STOCK	$0.30 MSRP: ~~2.50~~ (88% off)	14
14	N90443601	O-RING	N90443601 O-RING	$8.80	2
15	50121113B	COOLANT REGULATOR IN STOCK	50121113B COOLANT REGULATOR 80C-102C IN STOCK	$70.81	2
16	7M103649	SEAL IN STOCK	7M103649 SEAL IN STOCK	$26.10	2
17	N91084801	HEXAGON SOCKET HEAD BOLT IN STOCK	N91084801 HEXAGON SOCKET HEAD BOLT M6X18 IN STOCK	$0.83 MSRP: ~~7.29~~ (88.6% off)	8
18	7M121121E	COVER FOR THERMOSTAT	7M121121E COVER FOR THERMOSTAT	$766.14	2
19	7M919561	OIL PRESSURE SENDER	7M919561 OIL PRESSURE SENDER UNTIL ENGINE - 6L1201300 ORDER ALSO REF.29	$296.38	1
21	N91096702	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N91096702 OVAL HEXAGON SOCKET HEAD BOLT M6X16 IN STOCK	$1.34 MSRP: ~~7.29~~ (81.6% off)	1
24	79907601	IMPULSE SENDER	79907601 IMPULSE SENDER FLYWHEEL	$176.09	1
25	N91096702	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N91096702 OVAL HEXAGON SOCKET HEAD BOLT M6X16 IN STOCK	$1.34 MSRP: ~~7.29~~ (81.6% off)	1
26	7M103158E	AIR VENT IN STOCK	7M103158E AIR VENT IN STOCK	$1,458.36	7
27	N10456103	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD IN STOCK	N10456103 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD M4X10 IN STOCK	$0.51 MSRP: ~~7.31~~ (93% off)	1
28	59919523F	TEMPERATURE SENSOR IN STOCK	59919523F TEMPERATURE SENSOR IN STOCK	$64.33	2
29	470971729	HEAT DEFLECTOR HOSE	470971729 HEAT DEFLECTOR HOSE	$43.07	1
30	N10562301	CABLE TIES	N10562301 CABLE TIES 4 -7X194	$1.32 MSRP: ~~7.18~~ (81.6% off)	1
31	6H906433E	IMPULSE SENDER	6H906433E IMPULSE SENDER CRANCKSHAFT ENGINE-3 PIN	$118.95	1
