Name: POWER STEERING
Rating: 4.6 (1 reviews)

POWER STEERING of Lamborghini Lamborghini Aventador LP780 Ultimae

View All

Lamborghini Aventador LP780 Ultimae - POWER STEERING (422.02.00)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	400422886A	OIL COOLER	$551.15	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470422898	OIL HOSE	$128.65	To Order

Photo	Part No	Description	Price (each)	Stock
	470422857L	RETURN HOSE	$143.17	To Order

Photo	Part No	Description	Price (each)	Stock
	471422891C	RETURN HOSE	$276.21	To Order

Photo	Part No	Description	Price (each)	Stock
	471422893F	OIL PRESSURE LINE	$439.51	To Order

Photo	Part No	Description	Price (each)	Stock
	N10197601	EAR CRIMP HOSE CLAMP	$1.37	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10017307	HEXAGON COLLAR NUT	$1.81	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10124304	OVAL HEXAGON SOCKET HEAD BOLT	$1.55	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N10664901	SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD	$3.05	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	400422871D	MOUNTING BAR	$7.27	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	N90898101	OVAL HEXAGON SOCKET HEAD BOLT	$2.29	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	420201190A	CLIP	$9.27	To Order

Photo	Part No	Description	Price (each)	Stock
	N10017304	HEXAGON COLLAR NUT	$1.81	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470422871	MOUNTING BAR	$23.61	To Order

Photo	Part No	Description	Price (each)	Stock
	420611793A	BRACKET	$4.16	To Order

Photo	Part No	Description	Price (each)	Stock
	470422859E	RETURN PIPE	$277.57	To Order

Photo	Part No	Description	Price (each)	Stock
	472422891	OIL RETURN HOSE	$299.06	To Order

Photo	Part No	Description	Price (each)	Stock
	472422173	MOUNTING BAR	$22.26	To Order

Photo	Part No	Description	Price (each)	Stock
	472422893D	OIL PRESSURE LINE	$544.36	To Order

Photo	Part No	Description	Price (each)	Stock
	N01508210	HEXAGON COLLAR NUT	$1.96	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	470298021E	O-RING	$34.75	To Order

Photo	Part No	Description	Price (each)	Stock
	470298021F	O-RING	$23.40	To Order

Photo	Part No	Description	Price (each)	Stock
	470298021G	O-RING	$23.40	To Order

Photo	Part No	Description	Price (each)	Stock
	470298021H	O-RING	$23.40	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT001190	ROUND HD. SCREW	$0.53	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	WHT000778	WASHER	$0.64	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	3D0971838F	CABLE TIE WITH HOLDER FOR WELD PIN:	$2.84	To Order

Photo	Part No	Description	Price (each)	Stock
	400251189B	CLAMP	$10.80	IN STOCK

View All

Diagram Tap to enlarge

Power Steering

Lamborghini Aventador LP780 Ultimae

Illustration Number: 422.02.00

Lamborghini Aventador LP780 Ultimae - POWER STEERING (422.02.00)

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	400422886A	OIL COOLER IN STOCK	400422886A OIL COOLER IN STOCK	$551.15	1
2	470422898	OIL HOSE	470422898 OIL HOSE	$128.65	1
3	470422857L	RETURN HOSE	470422857L RETURN HOSE	$143.17	1
4	471422891C	RETURN HOSE	471422891C RETURN HOSE LHD	$276.21	1
5	471422893F	OIL PRESSURE LINE	471422893F OIL PRESSURE LINE	$439.51	1
6	N10197601	EAR CRIMP HOSE CLAMP IN STOCK	N10197601 EAR CRIMP HOSE CLAMP 19 -8X7X0,6 IN STOCK	$1.37 MSRP: ~~7.18~~ (80.9% off)	2
7	N10017307	HEXAGON COLLAR NUT IN STOCK	N10017307 HEXAGON COLLAR NUT M5 IN STOCK	$1.81 MSRP: ~~7.33~~ (75.3% off)	2
8	N10124304	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N10124304 OVAL HEXAGON SOCKET HEAD BOLT M6X20 IN STOCK	$1.55	5
10	N10664901	SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD IN STOCK	N10664901 SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD M8X16 IN STOCK	$3.05 MSRP: ~~7.27~~ (58% off)	1
11	400422871D	MOUNTING BAR IN STOCK	400422871D MOUNTING BAR LOWER IN STOCK	$7.27	2
12	N90898101	OVAL HEXAGON SOCKET HEAD BOLT IN STOCK	N90898101 OVAL HEXAGON SOCKET HEAD BOLT M6X14 IN STOCK	$2.29 MSRP: ~~7.01~~ (67.3% off)	3
13	420201190A	CLIP	420201190A CLIP	$9.27	1
14	N10017304	HEXAGON COLLAR NUT IN STOCK	N10017304 HEXAGON COLLAR NUT M5 IN STOCK	$1.81	1
15	470422871	MOUNTING BAR	470422871 MOUNTING BAR	$23.61	1
16	420611793A	BRACKET	420611793A BRACKET	$4.16	1
17	470422859E	RETURN PIPE	470422859E RETURN PIPE	$277.57	1
18	472422891	OIL RETURN HOSE	472422891 OIL RETURN HOSE	$299.06	1
19	472422173	MOUNTING BAR	472422173 MOUNTING BAR	$22.26	1
20	472422893D	OIL PRESSURE LINE	472422893D OIL PRESSURE LINE	$544.36	1
21	N01508210	HEXAGON COLLAR NUT IN STOCK	N01508210 HEXAGON COLLAR NUT M6 IN STOCK	$1.96	1
22	470298021E	O-RING	470298021E O-RING 8 -76 X 1,8	$34.75	2
23	470298021F	O-RING	470298021F O-RING 7 -65 X 1,63	$23.40	2
24	470298021G	O-RING	470298021G O-RING 7 -94 X 1,78	$23.40	2
25	470298021H	O-RING	470298021H O-RING 10 -82 X 1,78	$23.40	3
26	WHT001190	ROUND HD. SCREW IN STOCK	WHT001190 ROUND HD. SCREW M5X12 IN STOCK	$0.53	2
27	WHT000778	WASHER IN STOCK	WHT000778 WASHER 30X36X1 IN STOCK	$0.64	2
28	3D0971838F	CABLE TIE WITH HOLDER FOR WELD PIN:	3D0971838F CABLE TIE WITH HOLDER FOR WELD PIN: 5	$2.84	1
29	400251189B	CLAMP IN STOCK	400251189B CLAMP IN STOCK	$10.80	1
