Name: RADIO UNIT
Rating: 4.0 (1 reviews)

Find Your Part

RADIO UNIT of Lamborghini Lamborghini Aventador LP770 SVJ Coupe

View All

Lamborghini Aventador LP770 SVJ Coupe - RADIO UNIT

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	8T0035415A	MID-RANGE BASS SPEAKER	8T0035415A MID-RANGE BASS SPEAKER STANDARD	-	2	Enquire
1	470035411	MID-RANGE BASS SPEAKER	470035411 MID-RANGE BASS SPEAKER PREMIUM SOUND SYS	-	2	Enquire
2	470035467B	ADAPTER CABLE FOR RADIO POWER AND LOUDSPEAKER CONNECTION	470035467B ADAPTER CABLE FOR RADIO POWER AND LOUDSPEAKER CONNECTION PREMIUM SOUND SYS-LEFT	-	1	Enquire
2	470035468B	ADAPTER CABLE FOR RADIO POWER AND LOUDSPEAKER CONNECTION	470035468B ADAPTER CABLE FOR RADIO POWER AND LOUDSPEAKER CONNECTION PREMIUM SOUND SYS-RIGHT	-	1	Enquire
3	8T0035399	TREBLE SPEAKER	8T0035399 TREBLE SPEAKER STANDARD	-	2	Enquire
3	470035399	TREBLE SPEAKER	470035399 TREBLE SPEAKER PREMIUM SOUND SYS	-	2	Enquire
4	-	RADIO UNIT	RADIO UNIT SEE ILLUSTRATION :- 907-050	-	-	Enquire
5	-	MULTIMEDIA SYSTEM (REAR SEAT ENTERTAINMENTRSE)	MULTIMEDIA SYSTEM (REAR SEAT ENTERTAINMENTRSE) SEE ILLUSTRATION :- 907-050	-	-	Enquire
6	-	AMPLIFIERS	AMPLIFIERS SEE ILLUSTRATION :- 907-040	-	-	Enquire
7	N10595002	ROUND HD. SCREW	N10595002 ROUND HD. SCREW M5X18	-	8	Enquire
8	N10464802	OVAL HEXAGON SOCKET HEAD BOLT	N10464802 OVAL HEXAGON SOCKET HEAD BOLT 4X12	-	12	Enquire
9	-	BLANKET	BLANKET SEE ILLUSTRATION :- 907-050	-	-	Enquire
10	4N0035500	WLAN AERIAL	4N0035500 WLAN AERIAL 'W-LAN'	-	1	Enquire
11	4T0035720	RETAINING BAR	4T0035720 RETAINING BAR	-	1	Enquire
12	8S7035503B	AERIAL	8S7035503B AERIAL	-	1	Enquire
13	4T0035751C	EL.CONTROL UNIT	4T0035751C EL.CONTROL UNIT TSU UNIT	-	1	Enquire
13	4T0035751B	EL.CONTROL UNIT	4T0035751B EL.CONTROL UNIT	-	1	Enquire
14	471035821	MOUNTING BAR	471035821 MOUNTING BAR	-	1	Enquire
15	5Q0035726	USB CONNECTOR	5Q0035726 USB CONNECTOR	-	1	Enquire
16	N10017304	HEXAGON COLLAR NUT	N10017304 HEXAGON COLLAR NUT M5	-	5	Enquire
17	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD	N10569501 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD M5X16	-	1	Enquire
18	N01100412	HEXAGON NUT	N01100412 HEXAGON NUT M4	-	3	Enquire
19	470035909	TRIM FOR CONNECTION OF AUDIO SOURCES	470035909 TRIM FOR CONNECTION OF AUDIO SOURCES DASH PANEL BOX	-	1	Enquire
