GEARBOX AND FASTENERS of Ferrari Ferrari SF90 Spider USA

View All

Ferrari SF90 Spider USA - GEARBOX AND FASTENERS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	781648	COMPL. DCT GEARBOX	Enquire	To Order
	847147	COMPL. DCT GEARBOX	Enquire	To Order
	990446	COMPL. DCT GEARBOX	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	769008	RETENTION BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	750165	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	912129	GEARBOX MOUNT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	763347	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	259441	BUSHING COVER COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	292738	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102032	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	921971	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12644924	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	938921	RH GEARBOX BUSHING SHIM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	938909	LH GEARBOX BUSHING SHIM	Enquire	To Order
	938915	LH GEARBOX BUSHING SHIM	Enquire	To Order
	938916	LH GEARBOX BUSHING SHIM	Enquire	To Order

...and 3 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	851485	SELF-LOCKING NUT	Enquire	To Order
	851485	SELF-LOCKING NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059421	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	913205	OIL PLUG COMPL. WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	247723	VIBRATION DAMPER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13578324	WASHER	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	781648	COMPL. DCT GEARBOX	781648 COMPL. DCT GEARBOX Request ASM authorisation; Applies until depletion	-	1	Enquire
0001	847147	COMPL. DCT GEARBOX	847147 COMPL. DCT GEARBOX Applies until depletion - Applicable after depletion of 781648; Request ASM authorisation	-	1	Enquire
0001	990446	COMPL. DCT GEARBOX	990446 COMPL. DCT GEARBOX Request ASM authorisation	-	1	Enquire
0002	769008	RETENTION BRACKET	769008 RETENTION BRACKET	-	1	Enquire
0003	750165	SCREW	750165 SCREW Replaced by screw 14306734 ref.3 and washer 10519624 ref. 18; No longer supplied; M8 X 1.25 X 40	-	2	Enquire
0004	912129	GEARBOX MOUNT	912129 GEARBOX MOUNT	-	1	Enquire
0005	763347	SCREW	763347 SCREW M10 X 1.25 X 35	-	4	Enquire
0006	259441	BUSHING COVER COLLAR	259441 BUSHING COVER COLLAR	-	1	Enquire
0007	292738	SCREW	292738 SCREW M8 X 30	-	6	Enquire
0008	102032	CENTERING DOWEL	102032 CENTERING DOWEL	-	2	Enquire
0009	921971	SCREW	921971 SCREW M14 X 1.5 X 210	-	1	Enquire
0010	12644924	WASHER	12644924 WASHER	-	2	Enquire
0011	938921	RH GEARBOX BUSHING SHIM	938921 RH GEARBOX BUSHING SHIM Th. 0.49 mm	-	1	Enquire
0012	938909	LH GEARBOX BUSHING SHIM	938909 LH GEARBOX BUSHING SHIM Installed if necessary; Th. 0.49 mm	-	1	Enquire
0012	938915	LH GEARBOX BUSHING SHIM	938915 LH GEARBOX BUSHING SHIM Installed if necessary; Th. 0.69 mm	-	1	Enquire
0012	938916	LH GEARBOX BUSHING SHIM	938916 LH GEARBOX BUSHING SHIM Installed if necessary; Th. 0.89 mm	-	1	Enquire
0012	938917	LH GEARBOX BUSHING SHIM	938917 LH GEARBOX BUSHING SHIM Installed if necessary; Th. 1.09 mm	-	1	Enquire
0012	938918	LH GEARBOX BUSHING SHIM	938918 LH GEARBOX BUSHING SHIM Installed if necessary; Th. 1.29 mm	-	1	Enquire
0012	938919	LH GEARBOX BUSHING SHIM	938919 LH GEARBOX BUSHING SHIM Installed if necessary; Th. 1.59 mm	-	1	Enquire
0013	851485	SELF-LOCKING NUT	851485 SELF-LOCKING NUT	-	1	Enquire
0013	851485	SELF-LOCKING NUT	851485 SELF-LOCKING NUT	-	1	Enquire
0014	14059421	NUT	14059421 NUT	-	9	Enquire
0015	913205	OIL PLUG COMPL. WITH WASHER	913205 OIL PLUG COMPL. WITH WASHER	-	4	Enquire
0016	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 22	-	2	Enquire
0017	247723	VIBRATION DAMPER	247723 VIBRATION DAMPER	-	1	Enquire
0018	13578324	WASHER	13578324 WASHER	-	2	Enquire
