View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	917151	COMPL. WATER RETURN PIPE FROM SINGLE OIL HEAT EXCHANGER	$301.00	To Order

Photo	Part No	Description	Price (each)	Stock
	795600	DELIVERY PIPE TO HEATER	$100.33	To Order

Photo	Part No	Description	Price (each)	Stock
	287632	O-RING	$3.23	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SCREW	$0.31	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW	$0.68	To Order

Photo	Part No	Description	Price (each)	Stock
	82051100	CLIP	$0.97	To Order

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	917151	COMPL. WATER RETURN PIPE FROM SINGLE OIL HEAT EXCHANGER	917151 COMPL. WATER RETURN PIPE FROM SINGLE OIL HEAT EXCHANGER	$301.00	1
0002	795600	DELIVERY PIPE TO HEATER	795600 DELIVERY PIPE TO HEATER	$100.33	1
0003	287632	O-RING	287632 O-RING Also included in engine gasket set	$3.23	1
0004	231619	SCREW	231619 SCREW M6 X 20	$0.31	2
0005	865868	BRACKET	865868 BRACKET Applies until depletion	$31.52	1
0005	957851	BRACKET	957851 BRACKET Applicable after depletion of 865868	-	1	Enquire
0006	248334	SCREW	248334 SCREW M6 X 14	$0.68	2
0007	82051100	CLIP	82051100 CLIP	$0.97	1
