Anti-Theft System

Ferrari Portofino Europe

Find Your Part

Ferrari Portofino Europe - ANTI-THEFT SYSTEM

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
293416 ANTI-LIFT SENSOR Enquire To Order
Photo Part No Description Price (each) Stock
85833700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
294011 ANTI-THEFT SYSTEM SENSOR Enquire To Order
Photo Part No Description Price (each) Stock
85833700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
336779 COMPL. ANTI-THEFT SYSTEM SIREN Enquire To Order
Photo Part No Description Price (each) Stock
14040611 NUT Enquire To Order
Photo Part No Description Price (each) Stock
328403 KEYLESS KEY KIT Enquire To Order
328404 KEYLESS KEY KIT Enquire To Order
Photo Part No Description Price (each) Stock
6326163 SECRET CARD LABEL FOR KEYS Enquire To Order
Photo Part No Description Price (each) Stock
330644 GLONASS ECU Enquire To Order
855471 GLONASS ECU Enquire To Order
316923 ADR10 SATELLITE ALARM SYSTEM ECU Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
336507 GLONASS GSM ANTENNA Enquire To Order
336507 GLONASS GSM ANTENNA Enquire To Order
278514 GSM ANTENNA Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
343201 GLONASS SWITCH Enquire To Order
Photo Part No Description Price (each) Stock
792528 ERA GLONASS SWITCH SURROUND Enquire To Order
Photo Part No Description Price (each) Stock
11223887 CLIP Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire To Order
14059290 FLANGED NUT M6 Enquire To Order
14059290 FLANGED NUT M6 Enquire To Order
Photo Part No Description Price (each) Stock
332825 GLONASS SPEAKER Enquire To Order
Photo Part No Description Price (each) Stock
336506 GLONASS GPS ANTENNA Enquire To Order
336506 GLONASS GPS ANTENNA Enquire To Order
278513 GPS ANTENNA Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
333337 GSM MICROPHONE Enquire To Order
Photo Part No Description Price (each) Stock
85833700 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
338074 NAVTRAK ADR10 MOUNTING BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 Enquire To Order
Photo Part No Description Price (each) Stock
866260 KEY AND BLOCK KIT Enquire To Order
866261 KEY AND BLOCK KIT Enquire To Order
Photo Part No Description Price (each) Stock
824397 DRIVER CARD Enquire To Order
307604 DRIVER CARD FOR NAVTRACK Enquire To Order
Photo Part No Description Price (each) Stock
16285014 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
824398 RF ANTENNA Enquire To Order
Photo Part No Description Price (each) Stock
982069 START DISABLE WIRING HARNESS Enquire To Order
View All
ANTI-THEFT SYSTEM of Ferrari Ferrari Portofino Europe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 293416
ANTI-LIFT SENSOR 		- 1 Enquire
0002 85833700
SCREW
Applicable for ERA GLONASS system - Applicable for Russia, Armenia, Belarus, Kazakhstan and Kyrgyzstan markets; M5 X 14 		- 2 Enquire
0003 294011
ANTI-THEFT SYSTEM SENSOR 		- 1 Enquire
0004 85833700
SCREW
M5 X 12 		- 2 Enquire
0005 336779
COMPL. ANTI-THEFT SYSTEM SIREN 		- 1 Enquire
0006 14040611
NUT 		- 2 Enquire
0007 328403
KEYLESS KEY KIT 		- 1 Enquire
0007 328404
KEYLESS KEY KIT 		- 1 Enquire
0008 6326163
SECRET CARD LABEL FOR KEYS 		- 1 Enquire
0009 330644
GLONASS ECU
Applicable for ERA GLONASS system - Applicable for Russia, Armenia, Belarus, Kazakhstan and Kyrgyzstan markets; No longer supplied - Replaced by 855471; Unprogrammed 		- 1 Enquire
0009 855471
GLONASS ECU
Applicable for ERA GLONASS system - Applicable for Russia, Armenia, Belarus, Kazakhstan and Kyrgyzstan markets; Programmed 		- 1 Enquire
0009 316923
ADR10 SATELLITE ALARM SYSTEM ECU
Request ASM authorisation - Version with satellite alarm system 		- 1 Enquire
0009 824396
TCU ECALL / SVR
Version with SVR satellite alarm system with or without card 		- 1 Enquire
0010 336507
GLONASS GSM ANTENNA
Version with SVR satellite alarm system with or without card 		- 1 Enquire
0010 336507
GLONASS GSM ANTENNA 		- 1 Enquire
0010 278514
GSM ANTENNA 		- 1 Enquire
0010 336507
GLONASS GSM ANTENNA 		- 1 Enquire
0011 343201
GLONASS SWITCH
Applicable for ERA GLONASS system - Applicable for Russia, Armenia, Belarus, Kazakhstan and Kyrgyzstan markets 		- 1 Enquire
0012 792528
ERA GLONASS SWITCH SURROUND
Applicable for ERA GLONASS system - Applicable for Russia, Armenia, Belarus, Kazakhstan and Kyrgyzstan markets 		- 1 Enquire
0013 11223887
CLIP
Applicable for ERA GLONASS system - Applicable for Russia, Armenia, Belarus, Kazakhstan and Kyrgyzstan markets 		- 1 Enquire
0014 14059290
FLANGED NUT M6 		- 1 Enquire
0014 14059290
FLANGED NUT M6 		- 1 Enquire
0014 14059290
FLANGED NUT M6 		- 1 Enquire
0015 332825
GLONASS SPEAKER
Applicable for ERA GLONASS system - Applicable for Russia, Armenia, Belarus, Kazakhstan and Kyrgyzstan markets 		- 1 Enquire
0016 336506
GLONASS GPS ANTENNA
Version with SVR satellite alarm system with or without card 		- 1 Enquire
0016 336506
GLONASS GPS ANTENNA 		- 1 Enquire
0016 278513
GPS ANTENNA 		- 1 Enquire
0016 336506
GLONASS GPS ANTENNA 		- 1 Enquire
0017 333337
GSM MICROPHONE
Applicable for ERA GLONASS system - Applicable for Russia, Armenia, Belarus, Kazakhstan and Kyrgyzstan markets 		- 1 Enquire
0018 85833700
SCREW
M5 X 14 		- 2 Enquire
0019 338074
NAVTRAK ADR10 MOUNTING BRACKET 		- 1 Enquire
0020 14059290
FLANGED NUT M6 		- 1 Enquire
0021 866260
KEY AND BLOCK KIT
Contains 2 keys, 3 barrels, 1 secret card and 2 keyless key fobs 		- 1 Enquire
0021 866261
KEY AND BLOCK KIT
Contains 2 keys, 3 barrels, 1 secret card and 1 keyless key 		- 1 Enquire
0022 824397
DRIVER CARD
Version with SVR satellite alarm system with card - Request ASM authorisation 		- 1 Enquire
0022 307604
DRIVER CARD FOR NAVTRACK
Version with satellite alarm system with card - Request ASM authorisation 		- 1 Enquire
0023 16285014
SCREW
M5 X 16 		- 1 Enquire
0024 824398
RF ANTENNA
Version with SVR satellite alarm system with card 		- 1 Enquire
0025 982069
START DISABLE WIRING HARNESS
Version with SVR satellite alarm system with or without card 		- 1 Enquire
