Name: LIGHTING SYSTEMS
Rating: 4.3 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	84340000	SCREW	$1.94	To Order

Photo	Part No	Description	Price (each)	Stock
	828235	RH TAIL LIGHT	$3,326.19	To Order

Photo	Part No	Description	Price (each)	Stock
	828237	LH TAIL LIGHT	$3,326.19	To Order

Photo	Part No	Description	Price (each)	Stock
	828236	CENTRE TAIL LIGHT	$4,090.87	To Order

Photo	Part No	Description	Price (each)	Stock
	88831000	GRUB SCREW M5 X 40	$0.57	To Order

Photo	Part No	Description	Price (each)	Stock
	12647724	WASHER	$0.15	To Order

Photo	Part No	Description	Price (each)	Stock
	974896	LUGGAGE COMPARTMENT LIGHT	$64.17	To Order

Photo	Part No	Description	Price (each)	Stock
	880000	RH TURN INDICATOR	$243.67	To Order

Photo	Part No	Description	Price (each)	Stock
	879997	LH TURN INDICATOR	$243.67	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
0001	828208	RH HEADLAMP	828208 RH HEADLAMP	$11,225.92	1
0001	873915	RH HEADLAMP	873915 RH HEADLAMP Applicable for GD	$11,225.92	1
0002	828186	LH HEADLAMP	828186 LH HEADLAMP	$11,225.92	1
0002	873910	LH HEADLAMP	873910 LH HEADLAMP Applicable for GD	$11,225.92	1
0003	84340000	SCREW	84340000 SCREW M6 X 45	$1.94	8
0004	12643778	BLACK WASHER D.6.45-18X1.5	12643778 BLACK WASHER D.6.45-18X1.5 No longer supplied - Replaced by 12640678; 18 X 1.5	$0.28 MSRP: ~~0.50~~ (44% off)	8
0004	12647724	WASHER	12647724 WASHER 15 X 25 X 2	$0.15	8
0005	828235	RH TAIL LIGHT	828235 RH TAIL LIGHT	$3,326.19	1
0006	828237	LH TAIL LIGHT	828237 LH TAIL LIGHT	$3,326.19	1
0007	828236	CENTRE TAIL LIGHT	828236 CENTRE TAIL LIGHT	$4,090.87	1
0008	88831000	GRUB SCREW M5 X 40	88831000 GRUB SCREW M5 X 40 M5 X 30	$0.57	12
0009	12647724	WASHER	12647724 WASHER D. 5.50 - 15 X 1	$0.15	12
0010	974896	LUGGAGE COMPARTMENT LIGHT	974896 LUGGAGE COMPARTMENT LIGHT	$64.17	4
0011	880000	RH TURN INDICATOR	880000 RH TURN INDICATOR	$243.67	1
0012	879997	LH TURN INDICATOR	879997 LH TURN INDICATOR	$243.67	1
