INTERCOOLER

Find Your Part

Ferrari F8 Spider USA - INTERCOOLER

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
748562 LH INTERCOOLER $1,975.24 To Order
748559 RH INTERCOOLER $1,975.24 To Order
Photo Part No Description Price (each) Stock
319950 ELECTRIC FAN FOR INTERCOOLER $433.23 To Order
Photo Part No Description Price (each) Stock
14446624 WASHER $0.06 To Order
Photo Part No Description Price (each) Stock
14054048 NUT Enquire To Order
Photo Part No Description Price (each) Stock
816925 LH HOSE CONNECTION FROM TURBO TO INTERCOOLER $874.39 To Order
816925 LH HOSE CONNECTION FROM TURBO TO INTERCOOLER $874.39 To Order
816924 RH HOSE CONNECTION FROM TURBO TO INTERCOOLER $874.39 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
317449 HOSE CONNECTOR WITH FLANGE, LH SIDE $240.67 To Order
317448 HOSE CONNECTOR WITH FLANGE, RH SIDE $240.67 To Order
Photo Part No Description Price (each) Stock
231619 SCREW $0.31 To Order
Photo Part No Description Price (each) Stock
132829 O-RING $1.51 To Order
Photo Part No Description Price (each) Stock
859764 SCREW COLLAR $4.21 To Order
Photo Part No Description Price (each) Stock
315495 DUMP-VALVE $192.54 To Order
Photo Part No Description Price (each) Stock
231619 SCREW $0.31 To Order
Photo Part No Description Price (each) Stock
781216 UPPER INTERCOOLER FASTENER BRACKET $25.79 To Order
Photo Part No Description Price (each) Stock
772080 LH INTERCOOLER UPPER TRELLIS $152.42 To Order
772069 RH INTERCOOLER UPPER TRELLIS $152.42 To Order
Photo Part No Description Price (each) Stock
12646624 WASHER $0.23 To Order
Photo Part No Description Price (each) Stock
290938 INTERCOOLER FASTENER RUBBER BUSH $11.05 To Order
Photo Part No Description Price (each) Stock
66121400 WASHER $11.46 To Order
Photo Part No Description Price (each) Stock
12643778 BLACK WASHER D.6.45-18X1.5 $0.28 To Order
Photo Part No Description Price (each) Stock
10902024 SCREW $0.06 To Order
Photo Part No Description Price (each) Stock
290935 BUSH $6.18 To Order
Photo Part No Description Price (each) Stock
794445 LOWER FASTENER BRACKET FOR LH INTERCOOLER $59.35 To Order
794444 LOWER FASTENER BRACKET FOR RH INTERCOOLER $62.56 To Order
Photo Part No Description Price (each) Stock
13578801 WASHER $0.34 To Order
Photo Part No Description Price (each) Stock
316040 SCREW $5.19 To Order
Photo Part No Description Price (each) Stock
14304824 SCREW $0.28 To Order
Photo Part No Description Price (each) Stock
337903 HOSE $90.30 To Order
Photo Part No Description Price (each) Stock
814108 LH PIPE FROM INTERCOOLER TO THROTTLE BODY $774.05 To Order
814107 RH PIPE FROM INTERCOOLER TO THROTTLE BODY $759.72 To Order
Photo Part No Description Price (each) Stock
14040614 NUT $0.15 To Order
Photo Part No Description Price (each) Stock
239829 VIBRATION DAMPER Enquire To Order
Photo Part No Description Price (each) Stock
897058 HIGH PRESSURE PIPE ADJUSTER BRACKET $21.48 To Order
775075 HIGH PRESSURE PIPE ADJUSTER BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
880041 Allen Head Bolt M6 X 26 $6.18 To Order
Photo Part No Description Price (each) Stock
318185 CONNECTOR HOSE ON THROTTLE BODY $272.34 To Order
Photo Part No Description Price (each) Stock
311609 COLLAR $3.13 To Order
Photo Part No Description Price (each) Stock
908630 COLLAR $5.58 To Order
Photo Part No Description Price (each) Stock
337911 RUBBER PIPE FOR LH DUMP VALVE $91.72 To Order
337910 RUBBER PIPE FOR RH DUMP VALVE $54.46 To Order
Photo Part No Description Price (each) Stock
178053 CLAMP $1.54 To Order
Photo Part No Description Price (each) Stock
224271 CLAMP $1.60 To Order
Photo Part No Description Price (each) Stock
821185 CLIP $2.63 To Order
Photo Part No Description Price (each) Stock
324947 COILED PIPE $301.00 To Order
Photo Part No Description Price (each) Stock
325077 LH COIL COOLING PIPE $64.17 To Order
325076 RH COIL COOLING PIPE $64.17 To Order
Photo Part No Description Price (each) Stock
231619 SCREW $0.31 To Order
Photo Part No Description Price (each) Stock
296781 COLLAR 30-45MM $9.00 To Order
Photo Part No Description Price (each) Stock
303385 CLIP $0.31 To Order
Photo Part No Description Price (each) Stock
814120 HOSE FROM TUB TO RESONATOR $63.05 To Order
Photo Part No Description Price (each) Stock
741580 REDUCER FOR RESONATOR $6.86 To Order
Photo Part No Description Price (each) Stock
310096 SOUND GENERATOR $272.34 To Order
Photo Part No Description Price (each) Stock
814124 PIPE FROM INTAKE DUCT TO QUARTERLIGHT $54.46 To Order
Photo Part No Description Price (each) Stock
314100 RIVET $0.49 To Order
Photo Part No Description Price (each) Stock
10448890 BRACKET WITH SHEATH $2.71 To Order
Photo Part No Description Price (each) Stock
248334 SCREW $0.68 To Order
Photo Part No Description Price (each) Stock
296781 COLLAR 30-45MM $9.00 To Order
View All
INTERCOOLER of Ferrari Ferrari F8 Spider USA Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 748562
LH INTERCOOLER 		$1,975.24 1
0001 748559
RH INTERCOOLER 		$1,975.24 1
0002 319950
ELECTRIC FAN FOR INTERCOOLER 		$433.23 2
0003 14446624
WASHER 		$0.06 8
0004 14054048
NUT 		- 8 Enquire
0005 816925
LH HOSE CONNECTION FROM TURBO TO INTERCOOLER 		$874.39 1
0005 816925
LH HOSE CONNECTION FROM TURBO TO INTERCOOLER 		$874.39 1
0005 816924
RH HOSE CONNECTION FROM TURBO TO INTERCOOLER 		$874.39 1
0005 816924
RH HOSE CONNECTION FROM TURBO TO INTERCOOLER 		$874.39 1
0006 317449
HOSE CONNECTOR WITH FLANGE, LH SIDE 		$240.67 1
0006 317448
HOSE CONNECTOR WITH FLANGE, RH SIDE 		$240.67 1
0007 231619
SCREW
M6 X 22 		$0.31 4
0008 132829
O-RING 		$1.51 (22.6% off) 2
0009 859764
SCREW COLLAR 		$4.21 8
0010 315495
DUMP-VALVE 		$192.54 2
0011 231619
SCREW
M6 X 20 		$0.31 10
0012 781216
UPPER INTERCOOLER FASTENER BRACKET 		$25.79 2
0013 772080
LH INTERCOOLER UPPER TRELLIS 		$152.42 1
0013 772069
RH INTERCOOLER UPPER TRELLIS 		$152.42 1
0014 12646624
WASHER 		$0.23 (20.7% off) 8
0015 290938
INTERCOOLER FASTENER RUBBER BUSH 		$11.05 2
0016 66121400
WASHER 		$11.46 (22.4% off) 2
0017 12643778
BLACK WASHER D.6.45-18X1.5 		$0.28 (44% off) 2
0018 10902024
SCREW
M6 X 12 		$0.06 (82.9% off) 2
0019 290935
BUSH 		$6.18 4
0020 794445
LOWER FASTENER BRACKET FOR LH INTERCOOLER 		$59.35 1
0020 794444
LOWER FASTENER BRACKET FOR RH INTERCOOLER 		$62.56 1
0021 13578801
WASHER 		$0.34 4
0022 316040
SCREW 		$5.19 4
0023 14304824
SCREW
L. 55 mm 		$0.28 4
0024 337903
HOSE 		$90.30 2
0025 814108
LH PIPE FROM INTERCOOLER TO THROTTLE BODY 		$774.05 1
0025 814107
RH PIPE FROM INTERCOOLER TO THROTTLE BODY 		$759.72 1
0026 14040614
NUT 		$0.15 2
0027 239829
VIBRATION DAMPER 		- 2 Enquire
0028 897058
HIGH PRESSURE PIPE ADJUSTER BRACKET
Applies until depletion 		$21.48 2
0028 775075
HIGH PRESSURE PIPE ADJUSTER BRACKET
Applicable after depletion of 897058 		- 2 Enquire
0029 880041
Allen Head Bolt M6 X 26
M6 X 20 		$6.18 2
0030 318185
CONNECTOR HOSE ON THROTTLE BODY 		$272.34 2
0031 311609
COLLAR 		$3.13 2
0032 908630
COLLAR 		$5.58 2
0033 337911
RUBBER PIPE FOR LH DUMP VALVE 		$91.72 1
0033 337910
RUBBER PIPE FOR RH DUMP VALVE 		$54.46 1
0034 178053
CLAMP 		$1.54 2
0035 224271
CLAMP 		$1.60 2
0036 821185
CLIP 		$2.63 2
0037 324947
COILED PIPE 		$301.00 2
0038 325077
LH COIL COOLING PIPE 		$64.17 1
0038 325076
RH COIL COOLING PIPE 		$64.17 1
0039 231619
SCREW
M6 X 18 		$0.31 4
0040 296781
COLLAR 30-45MM 		$9.00 1
0041 303385
CLIP
170 mm 		$0.31 2
0042 814120
HOSE FROM TUB TO RESONATOR 		$63.05 1
0043 741580
REDUCER FOR RESONATOR 		$6.86 1
0044 310096
SOUND GENERATOR 		$272.34 1
0045 814124
PIPE FROM INTAKE DUCT TO QUARTERLIGHT 		$54.46 1
0046 314100
RIVET 		$0.49 2
0047 10448890
BRACKET WITH SHEATH 		$2.71 2
0048 248334
SCREW
M6 X 14 		$0.68 2
0049 296781
COLLAR 30-45MM 		$9.00 1
