Front Suspension - Levers

Ferrari F40

Find Your Part

Ferrari F40 - Front suspension - Levers

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
133602 Rod link Enquire To Order
Photo Part No Description Price (each) Stock
16103621 NUT Enquire To Order
Photo Part No Description Price (each) Stock
127498 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
100984 Grommet Enquire To Order
Photo Part No Description Price (each) Stock
100985 Spacer tube Enquire To Order
Photo Part No Description Price (each) Stock
117730 Washer Enquire To Order
Photo Part No Description Price (each) Stock
148020 NUT Enquire To Order
Photo Part No Description Price (each) Stock
121679 Pin Enquire To Order
Photo Part No Description Price (each) Stock
125396 Screw Enquire To Order
Photo Part No Description Price (each) Stock
121392 Upper lever, right Enquire To Order
Photo Part No Description Price (each) Stock
132175 Lower lever, right Enquire To Order
Photo Part No Description Price (each) Stock
154537 Flamblock for upper lever Enquire To Order
Photo Part No Description Price (each) Stock
192281 Lower fork Enquire To Order
Photo Part No Description Price (each) Stock
128368 Screw Enquire To Order
Photo Part No Description Price (each) Stock
148020 NUT Enquire To Order
Photo Part No Description Price (each) Stock
190246 WASHER. Enquire To Order
Photo Part No Description Price (each) Stock
150238 Nut -For car with lifting Enquire To Order
Photo Part No Description Price (each) Stock
101041 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
115072 Upper adjusting plate for caster angle Enquire To Order
Photo Part No Description Price (each) Stock
124365 Lower adjusting plate for caster angle Enquire To Order
Photo Part No Description Price (each) Stock
103256 Upper adjusting plate Enquire To Order
Photo Part No Description Price (each) Stock
125397 Lower adjusting plate Enquire To Order
Photo Part No Description Price (each) Stock
109013 Screw Enquire To Order
Photo Part No Description Price (each) Stock
12574521 Nyloc Nut Enquire To Order
Photo Part No Description Price (each) Stock
15971621 Screw Enquire To Order
Photo Part No Description Price (each) Stock
12574521 Nyloc Nut Enquire To Order
Photo Part No Description Price (each) Stock
112441 Screw Enquire To Order
Photo Part No Description Price (each) Stock
148020 NUT Enquire To Order
Photo Part No Description Price (each) Stock
114818 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
118118 Stabilizer rod Enquire To Order
Photo Part No Description Price (each) Stock
130606 Pad for rod Enquire To Order
Photo Part No Description Price (each) Stock
138389 Support -Valid after Enquire To Order
Photo Part No Description Price (each) Stock
13516824 STUD BOLT Enquire To Order
Photo Part No Description Price (each) Stock
14054511 NUT Enquire To Order
Photo Part No Description Price (each) Stock
116280 Upper ball joint Enquire To Order
Photo Part No Description Price (each) Stock
133944 LOWER BALL JOINT Enquire To Order
Photo Part No Description Price (each) Stock
122237 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
10520024 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
102683 Spacer Enquire To Order
Photo Part No Description Price (each) Stock
127849 Screw Enquire To Order
Photo Part No Description Price (each) Stock
149807 NUT Enquire To Order
View All
Front suspension - Levers of Ferrari Ferrari F40 Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 138389
Support -Valid after
With assembly 133227 		- 2 Enquire
- 107341
Ditto, thickness 3 mm. 		- - Enquire
- 107342
Ditto, thickness 3,25 mm. 		- - Enquire
- 101039
Ditto, thickness 1 mm. 		- - Enquire
- 107338
SPACER WASHER mm. 1,5 		- - Enquire
- 107339
Ditto, thickness 2 mm. 		- - Enquire
- 107340
Ditto, thickness 2,5 mm 		- - Enquire
- 121393
Upper lever, left 		- 1 Enquire
- 132176
Lower lever, left 		- 1 Enquire
1 133602
Rod link 		- 2 Enquire
2 16103621
NUT 		- 2 Enquire
3 127498
WASHER 		- 2 Enquire
4 100984
Grommet 		- 8 Enquire
5 100985
Spacer tube 		- 2 Enquire
6 117730
Washer 		- 4 Enquire
7 148020
NUT 		- 2 Enquire
8 121679
Pin 		- 2 Enquire
9 125396
Screw 		- 2 Enquire
10 121392
Upper lever, right 		- 1 Enquire
11 132175
Lower lever, right 		- 1 Enquire
12 154537
Flamblock for upper lever 		- 8 Enquire
13 192281
Lower fork 		- 4 Enquire
14 128368
Screw 		- 4 Enquire
15 148020
NUT 		- 8 Enquire
16 190246
WASHER.
thickness 6 mm. / (Possible mounting) 		- 4 Enquire
17 150238
Nut -For car with lifting 		- 4 Enquire
18 101041
WASHER 		- 4 Enquire
19 115072
Upper adjusting plate for caster angle
caster angle / (Possible mounting) 		- - Enquire
20 124365
Lower adjusting plate for caster angle
caster angle / Possible mounting 		- - Enquire
21 103256
Upper adjusting plate 		- 8 Enquire
22 125397
Lower adjusting plate 		- 8 Enquire
23 109013
Screw 		- 2 Enquire
24 12574521
Nyloc Nut 		- 4 Enquire
25 15971621
Screw 		- 2 Enquire
26 12574521
Nyloc Nut 		- 2 Enquire
27 112441
Screw 		- 2 Enquire
28 148020
NUT 		- 2 Enquire
29 114818
SCREW 		- 2 Enquire
30 118118
Stabilizer rod 		- 1 Enquire
31 130606
Pad for rod 		- 2 Enquire
32 138389
Support -Valid after
Valid till depletion 		- 2 Enquire
33 13516824
STUD BOLT
Valid for support 130532 		- 4 Enquire
34 14054511
NUT 		- 4 Enquire
35 116280
Upper ball joint 		- 2 Enquire
36 133944
LOWER BALL JOINT 		- 2 Enquire
37 122237
WASHER 		- 4 Enquire
38 10520024
WASHER 		- 2 Enquire
39 102683
Spacer
Valid for support 130532 		- 4 Enquire
40 127849
Screw 		- 4 Enquire
41 149807
NUT 		- 4 Enquire
