ROLLBAR

Find Your Part

Ferrari 812 Competizione A Europe - ROLLBAR

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
70008082 COMPL. ROLLBAR TRIM Enquire To Order
749972 COMPL. ROLLBAR TRIM Enquire To Order
888744 COMPL. ROLLBAR TRIM $21,653.78 To Order
Photo Part No Description Price (each) Stock
822261 GASKET $304.63 To Order
Photo Part No Description Price (each) Stock
949005 COMPL. CENTRE REAR WINDOW GASKETS $966.92 To Order
Photo Part No Description Price (each) Stock
886537 LH LATERAL WATERPROOF SHIELD $286.67 To Order
886538 RH LATERAL WATERPROOF SHIELD $286.67 To Order
851821 LH LATERAL WATERPROOF SHIELD $136.16 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
936344 SCREW $0.41 To Order
936344 SCREW $0.41 To Order
Photo Part No Description Price (each) Stock
62769800 WASHER $0.23 To Order
62769800 WASHER $0.23 To Order
Photo Part No Description Price (each) Stock
877077 COMPL. REMOVABLE CENTRE ROLL BAR WALL $208.58 To Order
Photo Part No Description Price (each) Stock
821988 BRACKET $30.08 To Order
Photo Part No Description Price (each) Stock
88004600 SCREW $1.65 To Order
Photo Part No Description Price (each) Stock
14059190 NUT $0.28 To Order
Photo Part No Description Price (each) Stock
858345 COMPL. RH ROLLBAR BRACKET $78.82 To Order
858348 COMPL. LH ROLLBAR BRACKET $78.82 To Order
Photo Part No Description Price (each) Stock
897538 SCREW $1.77 To Order
Photo Part No Description Price (each) Stock
12646621 WASHER $0.15 To Order
Photo Part No Description Price (each) Stock
832616 SHIM $15.75 To Order
832618 SHIM $15.54 To Order
Photo Part No Description Price (each) Stock
869911 LH CENTRE WATERPROOF MEMBRANE Enquire To Order
Photo Part No Description Price (each) Stock
746139 COMPL. OUTER FASTENER BRACKET $64.49 To Order
Photo Part No Description Price (each) Stock
910625 ADJUSTMENT SHIM $13.76 To Order
Photo Part No Description Price (each) Stock
925745 SCREW $1.56 To Order
Photo Part No Description Price (each) Stock
113113 WASHER $1.07 To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 $1.51 To Order
Photo Part No Description Price (each) Stock
87583800 ADJUSTMENT SHIM $1.85 To Order
856009 ADJUSTMENT SHIM $8.44 To Order
Photo Part No Description Price (each) Stock
85833900 SCREW $0.36 ARRIVING SOON
Photo Part No Description Price (each) Stock
822232 RH POWER REAR WINDOW SEAL $556.31 To Order
Photo Part No Description Price (each) Stock
822249 LH POWER REAR WINDOW SEAL $556.31 To Order
Photo Part No Description Price (each) Stock
852577 COMPL. RH REAR WINDOW SEAL CONTAINER $243.67 To Order
Photo Part No Description Price (each) Stock
851760 COMPL. LH REAR WINDOW SEAL CONTAINER $243.67 To Order
Photo Part No Description Price (each) Stock
263276 WASHER $0.16 To Order
Photo Part No Description Price (each) Stock
301785 SCREW $0.71 To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 $1.51 To Order
Photo Part No Description Price (each) Stock
890406 SCREW $7.44 To Order
Photo Part No Description Price (each) Stock
833463 RH LATERAL POWER REAR WINDOW $352.54 To Order
Photo Part No Description Price (each) Stock
905958 LH LATERAL POWER REAR WINDOW $352.54 To Order
Photo Part No Description Price (each) Stock
851686 COMPL. RH FRONT CLOSURE PANEL $143.33 To Order
Photo Part No Description Price (each) Stock
851762 COMPL. LH FRONT CLOSURE PANEL $143.33 To Order
Photo Part No Description Price (each) Stock
851758 COMPL. RH BRACKET $130.43 To Order
Photo Part No Description Price (each) Stock
851643 COMPL. LH BRACKET $130.43 To Order
Photo Part No Description Price (each) Stock
14059290 FLANGED NUT M6 $1.51 To Order
Photo Part No Description Price (each) Stock
905955 RH REAR WINDOW LIFTER $741.57 To Order
Photo Part No Description Price (each) Stock
905956 LH REAR WINDOW LIFTER $741.57 To Order
Photo Part No Description Price (each) Stock
822309 COMPL. LH UPPER REINFORCEMENT $272.34 To Order
822229 COMPL. RH UPPER REINFORCEMENT $272.34 To Order
Photo Part No Description Price (each) Stock
277287 SCREW $16.65 To Order
Photo Part No Description Price (each) Stock
903295 SCREW $0.66 To Order
Photo Part No Description Price (each) Stock
13578324 WASHER $0.23 To Order
Photo Part No Description Price (each) Stock
939580 WATER DRAIN PIPE $55.89 To Order
Photo Part No Description Price (each) Stock
331573 CABLE TIE $0.36 To Order
Photo Part No Description Price (each) Stock
82051100 CLIP $0.97 To Order
Photo Part No Description Price (each) Stock
951947 LH DRAIN PIPE BRACKET $34.38 To Order
951957 RH DRAIN PIPE BRACKET $34.38 To Order
Photo Part No Description Price (each) Stock
822233 LH WATERPROOF MEMBRANE Enquire To Order
822294 RH WATERPROOF MEMBRANE Enquire To Order
Photo Part No Description Price (each) Stock
822299 CENTRE WATERPROOF MEMBRANE Enquire To Order
Photo Part No Description Price (each) Stock
231625 SCREW $0.65 To Order
Photo Part No Description Price (each) Stock
12643724 WASHER $0.06 To Order
Photo Part No Description Price (each) Stock
14591687 FASTENER BUTTON $0.06 To Order
Photo Part No Description Price (each) Stock
870348 PLATE $10.89 To Order
Photo Part No Description Price (each) Stock
12640624 WASHER $0.16 To Order
Photo Part No Description Price (each) Stock
14506587 PLUG $0.21 To Order
Photo Part No Description Price (each) Stock
949923 LH OUTER ROLL BAR WATERPROOF MEMBRANE $67.36 To Order
949922 RH OUTER ROLL BAR WATERPROOF MEMBRANE $67.36 To Order
Photo Part No Description Price (each) Stock
762660 LH INNER ROLL BAR WATERPROOF MEMBRANE $34.38 To Order
762639 RH INNER ROLL BAR WATERPROOF MEMBRANE $34.38 To Order
View All
ROLLBAR of Ferrari Ferrari 812 Competizione A Europe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 70008082
COMPL. ROLLBAR TRIM
Version in coloured naked weave carbon - CECM - CECM for carbon colour selection - For better colour match, also order adjacent off-catalogue components; Off-catalogue version 		- 1 Enquire
0001 749972
COMPL. ROLLBAR TRIM
Matte finish carbon version 		- 1 Enquire
0001 888744
COMPL. ROLLBAR TRIM
Gloss finish carbon version 		$21,653.78 1
0002 822261
GASKET 		$304.63 1
0003 949005
COMPL. CENTRE REAR WINDOW GASKETS 		$966.92 1
0004 886537
LH LATERAL WATERPROOF SHIELD 		$286.67 1
0004 886538
RH LATERAL WATERPROOF SHIELD 		$286.67 1
0004 851821
LH LATERAL WATERPROOF SHIELD 		$136.16 1
0004 851887
RH LATERAL WATERPROOF SHIELD 		$136.16 1
0005 936344
SCREW
M5 X 12 		$0.41 11
0005 936344
SCREW
M5 X 12 		$0.41 11
0006 62769800
WASHER 		$0.23 (23.3% off) 21
0006 62769800
WASHER 		$0.23 (23.3% off) 25
0007 877077
COMPL. REMOVABLE CENTRE ROLL BAR WALL 		$208.58 1
0008 821988
BRACKET 		$30.08 1
0009 88004600
SCREW
M5 X 16 		$1.65 10
0010 14059190
NUT
M5 		$0.28 2
0011 858345
COMPL. RH ROLLBAR BRACKET 		$78.82 1
0011 858348
COMPL. LH ROLLBAR BRACKET 		$78.82 1
0012 897538
SCREW
M6 X 20 		$1.77 2
0013 12646621
WASHER
D. 6.45 - 15 X 1.5 		$0.15 2
0014 832616
SHIM
1 mm 		$15.75 4
0014 832618
SHIM
0.6 mm 		$15.54 4
0015 869911
LH CENTRE WATERPROOF MEMBRANE 		- 1 Enquire
0016 86276300
SCREW
M6 X 22 		$3.91 4
0017 746139
COMPL. OUTER FASTENER BRACKET 		$64.49 2
0018 910625
ADJUSTMENT SHIM
1 mm 		$13.76 6
0019 925745
SCREW
M5 X 35 		$1.56 4
0020 113113
WASHER
D. 6.45-16 X 2 		$1.07 (58.2% off) 2
0021 14059290
FLANGED NUT M6
M6 		$1.51 6
0022 87583800
ADJUSTMENT SHIM
Th. 1 mm 		$1.85 12
0022 856009
ADJUSTMENT SHIM
Th. 0.6 mm 		$8.44 4
0023 85833900
SCREW
M5 X 12
ARRIVING SOON 		$0.36 2
0024 822232
RH POWER REAR WINDOW SEAL 		$556.31 1
0025 822249
LH POWER REAR WINDOW SEAL 		$556.31 1
0026 852577
COMPL. RH REAR WINDOW SEAL CONTAINER 		$243.67 1
0027 851760
COMPL. LH REAR WINDOW SEAL CONTAINER 		$243.67 1
0028 263276
WASHER 		$0.16 4
0029 301785
SCREW
M5 X 40 		$0.71 4
0030 14059290
FLANGED NUT M6
M6 		$1.51 6
0031 890406
SCREW
M6 		$7.44 10
0032 833463
RH LATERAL POWER REAR WINDOW 		$352.54 1
0033 905958
LH LATERAL POWER REAR WINDOW 		$352.54 1
0034 851686
COMPL. RH FRONT CLOSURE PANEL 		$143.33 1
0035 851762
COMPL. LH FRONT CLOSURE PANEL 		$143.33 1
0036 851758
COMPL. RH BRACKET 		$130.43 1
0037 851643
COMPL. LH BRACKET 		$130.43 1
0038 14059290
FLANGED NUT M6
M6 		$1.51 6
0039 905955
RH REAR WINDOW LIFTER 		$741.57 1
0040 905956
LH REAR WINDOW LIFTER 		$741.57 1
0041 822309
COMPL. LH UPPER REINFORCEMENT 		$272.34 1
0041 822229
COMPL. RH UPPER REINFORCEMENT 		$272.34 1
0042 277287
SCREW
M10 X 1.25 X 40 		$16.65 2
0043 903295
SCREW
M8 X 1.25 X 25 		$0.66 8
0044 13578324
WASHER
D. 8.15 - 24 X 2 		$0.23 8
0045 939580
WATER DRAIN PIPE 		$55.89 2
0046 331573
CABLE TIE 		$0.36 2
0047 82051100
CLIP 		$0.97 2
0048 951947
LH DRAIN PIPE BRACKET 		$34.38 1
0048 951957
RH DRAIN PIPE BRACKET 		$34.38 1
0049 822233
LH WATERPROOF MEMBRANE 		- 1 Enquire
0049 822294
RH WATERPROOF MEMBRANE 		- 1 Enquire
0050 822299
CENTRE WATERPROOF MEMBRANE 		- 1 Enquire
0051 231625
SCREW
M6 X 25 		$0.65 4
0052 12643724
WASHER 		$0.06 (88% off) 4
0053 14591687
FASTENER BUTTON 		$0.06 (87.8% off) 2
0054 870348
PLATE
0.5 mm 		$10.89 1
0055 12640624
WASHER
6.5 X 22 X 2.5 		$0.16 (44.8% off) 8
0056 14506587
PLUG 		$0.21 (65% off) 1
0057 949923
LH OUTER ROLL BAR WATERPROOF MEMBRANE 		$67.36 1
0057 949922
RH OUTER ROLL BAR WATERPROOF MEMBRANE 		$67.36 1
0058 762660
LH INNER ROLL BAR WATERPROOF MEMBRANE 		$34.38 1
0058 762639
RH INNER ROLL BAR WATERPROOF MEMBRANE 		$34.38 1
