Timing System - Tappets

Ferrari 812 GTS (Europe)

Find Your Part

Ferrari 812 GTS (Europe) - TIMING SYSTEM - TAPPETS

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
TIMING SYSTEM - TAPPETS of Ferrari Ferrari 812 GTS (Europe) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 241906
VARIABLE VALVE TIMING ADJUSTER, INTAKE CAMSHAFT 		- 2 Enquire
2 254892
SCREW HEX HEAD M14 X 15 		- 4 Enquire
3 197975
SEAL RING
Also comes with engine gasket set 		- 12 Enquire
4 240559
DIAMOND COATED WASHER 		- 4 Enquire
5 321295
RH INTAKE CAMSHAFT 		- 1 Enquire
6 321296
LH INTAKE CAMSHAFT 		- 1 Enquire
7 248020
VARIABLE VALVE TIMING ADJUSTER, EXHAUST CAMSHAFT 		- 2 Enquire
8 321297
RH EXHAUST CAMSHAFT 		- 1 Enquire
9 321298
LH EXHAUST CAMSHAFT 		- 1 Enquire
10 255431
HYDRAULIC TAPPET 		- 48 Enquire
11 179763
VALVE SPRING SEMI-CONE 		- 96 Enquire
12 320911
UPPER VALVE SPRING CAP 		- 48 Enquire
13 789304
INTERNAL SPRING 		- 48 Enquire
14 789285
EXTERNAL VALVE RETURN SPRING 		- 48 Enquire
15 221473
OIL SEAL
Also comes with engine gasket set 		- 48 Enquire
16 321017
LOWER VALVE SPRING CAP 		- 48 Enquire
17 6213498
VALVE GUIDE 		- 48 Enquire
18 319722
INTAKE VALVE 		- 24 Enquire
18 319636
EXHAUST VALVE 		- 24 Enquire
19 849666
INTAKE VALVE SEAT 		- 12 Enquire
19 849695
EXHAUST VALVE SEAT 		- 12 Enquire
19 6325709
INTAKE VALVE SEAT
No longer supplied - Replaced by 849666 		- 12 Enquire
19 6323691
EXHAUST VALVE SEAT
No longer supplied - Replaced by 849695 		- 12 Enquire
