Name: Steering column
Rating: 5.0 (1 reviews)

Find Your Part

Steering column of Ferrari Ferrari 512 M

View All

Ferrari 512 M - Steering column

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	165946	Steering wheel complete	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101648	Ring nut	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601774	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164255	Steering wheel coating	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164256	Electric horn push button	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150540	Unhook deviation assembly	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101106	Tongue	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	146374	Cardanic transmission	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13274972	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63093800	Steering column rubber protection	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	121580	Upper steering column cover	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	121581	Lower steering column cover	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13275217	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13525170	THREADED INSERT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	121588	Bush	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	121589	Pipe	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16045024	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147985	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	120988	Shaft	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	114865	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14163870	FLEXIBLE PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148020	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	131487	Lever	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164283	Complete anti-theft system	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	121611	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	95401152	BLANK KEY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150427	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150427	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	125518	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134070	SPACER WASHER mm. 1,0	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11060076	Seeger Ring	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134065	SPACER WASHER mm. 1,0	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	123382	R.H. tie rod	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	123383	L.H. tie rod	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81591700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	120990	R.H. bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	120991	L.H. bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	124826	Plate	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	81591700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16043221	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14040711	NUT M8 FLANGED	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127496	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	136024	Steering column support	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	138710	Upper shaft	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134061	BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11066876	SEEGER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62770100	Spring	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62772500	Rivet	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	125694	Ground cable	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	134068	DITTO, THICKNESS mm. 1.3	134068 DITTO, THICKNESS mm. 1.3 Possible mounting	-	1	Enquire
-	134069	DITTO, THICKNESS mm. 1.4	134069 DITTO, THICKNESS mm. 1.4 Possible mounting	-	1	Enquire
-	134066	DITTO, THICKNESS mm. 1.1	134066 DITTO, THICKNESS mm. 1.1 Possible mounting	-	1	Enquire
-	134067	DITTO, THICKNESS mm. 1.2	134067 DITTO, THICKNESS mm. 1.2 Possible mounting	-	1	Enquire
-	134071	DITTO, THICKNESS mm. 1.1	134071 DITTO, THICKNESS mm. 1.1 Possible mounting	-	1	Enquire
-	134072	DITTO, THICKNESS mm. 1.2	134072 DITTO, THICKNESS mm. 1.2 Possible mounting	-	1	Enquire
-	134073	DITTO, THICKNESS mm. 1.3	134073 DITTO, THICKNESS mm. 1.3 Possible mounting	-	1	Enquire
-	134074	DITTO, THICKNESS mm. 1.4	134074 DITTO, THICKNESS mm. 1.4 Possible mounting	-	1	Enquire
-	164283	Complete anti-theft system	164283 Complete anti-theft system Valid for USA and CDN / Doors locks set included /	-	1	Enquire
-	148656	Unhook deviation assembly	148656 Unhook deviation assembly Valid for USA and J	-	1	Enquire
-	137819	ELECTRIC HORN PUSH BUTTON	137819 ELECTRIC HORN PUSH BUTTON Valid for steering wheel 167566	-	1	Enquire
-	165946	Steering wheel complete	165946 Steering wheel complete Valid after stock exhaustion / of 161012	-	1	Enquire
1	165946	Steering wheel complete	165946 Steering wheel complete	-	1	Enquire
2	101648	Ring nut	101648 Ring nut	-	1	Enquire
3	12601774	WASHER	12601774 WASHER	-	1	Enquire
4	164255	Steering wheel coating	164255 Steering wheel coating	-	1	Enquire
5	164256	Electric horn push button	164256 Electric horn push button Valid for steering wheel 165946	-	1	Enquire
6	150540	Unhook deviation assembly	150540 Unhook deviation assembly Not for USA and J	-	1	Enquire
7	101106	Tongue	101106 Tongue	-	1	Enquire
8	146374	Cardanic transmission	146374 Cardanic transmission	-	1	Enquire
9	13274972	SCREW	13274972 SCREW	-	2	Enquire
10	12604178	Washer	12604178 Washer	-	2	Enquire
11	63093800	Steering column rubber protection	63093800 Steering column rubber protection	-	1	Enquire
12	121580	Upper steering column cover	121580 Upper steering column cover	-	1	Enquire
13	121581	Lower steering column cover	121581 Lower steering column cover	-	1	Enquire
14	13275217	SCREW	13275217 SCREW	-	2	Enquire
15	12604178	Washer	12604178 Washer	-	2	Enquire
16	13525170	THREADED INSERT	13525170 THREADED INSERT	-	2	Enquire
17	121588	Bush	121588 Bush	-	2	Enquire
18	121589	Pipe	121589 Pipe	-	1	Enquire
19	16045024	SCREW	16045024 SCREW	-	1	Enquire
20	147985	NUT	147985 NUT	-	1	Enquire
21	120988	Shaft	120988 Shaft	-	1	Enquire
22	114865	WASHER	114865 WASHER	-	2	Enquire
23	14163870	FLEXIBLE PIN	14163870 FLEXIBLE PIN	-	1	Enquire
24	148020	NUT	148020 NUT	-	1	Enquire
25	131487	Lever	131487 Lever	-	1	Enquire
26	164283	Complete anti-theft system	164283 Complete anti-theft system Not for USA and CDN / Doors locks set included /	-	1	Enquire
27	121611	SCREW	121611 SCREW	-	2	Enquire
28	95401152	BLANK KEY	95401152 BLANK KEY	-	-	Enquire
29	150427	SCREW	150427 SCREW	-	1	Enquire
30	150427	SCREW	150427 SCREW	-	1	Enquire
31	125518	SCREW	125518 SCREW	-	1	Enquire
32	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	1	Enquire
33	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	2	Enquire
34	134070	SPACER WASHER mm. 1,0	134070 SPACER WASHER mm. 1,0	-	1	Enquire
35	11060076	Seeger Ring	11060076 Seeger Ring	-	2	Enquire
36	134065	SPACER WASHER mm. 1,0	134065 SPACER WASHER mm. 1,0	-	1	Enquire
37	123382	R.H. tie rod	123382 R.H. tie rod	-	1	Enquire
38	123383	L.H. tie rod	123383 L.H. tie rod	-	1	Enquire
39	81591700	SCREW	81591700 SCREW	-	4	Enquire
40	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	4	Enquire
41	127494	WASHER	127494 WASHER	-	4	Enquire
42	120990	R.H. bracket	120990 R.H. bracket	-	1	Enquire
43	120991	L.H. bracket	120991 L.H. bracket	-	1	Enquire
44	124826	Plate	124826 Plate	-	2	Enquire
45	81591700	SCREW	81591700 SCREW	-	2	Enquire
46	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	2	Enquire
47	127494	WASHER	127494 WASHER	-	2	Enquire
48	16043221	SCREW	16043221 SCREW	-	2	Enquire
49	14040711	NUT M8 FLANGED	14040711 NUT M8 FLANGED	-	2	Enquire
50	127496	WASHER	127496 WASHER	-	2	Enquire
51	136024	Steering column support	136024 Steering column support	-	1	Enquire
52	138710	Upper shaft	138710 Upper shaft	-	1	Enquire
53	134061	BEARING	134061 BEARING	-	2	Enquire
54	11066876	SEEGER RING	11066876 SEEGER RING	-	1	Enquire
55	62770100	Spring	62770100 Spring	-	2	Enquire
56	62772500	Rivet	62772500 Rivet	-	2	Enquire
57	125694	Ground cable	125694 Ground cable	-	1	Enquire
