View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	320598	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	316737	COMPL. RH FUEL PIPE MOUNTING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	316735	COMPL. LH FUEL PIPE MOUNTING BRACKET	Enquire	To Order

View All

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	316734	FUEL DELIVERY PIPE	316734 FUEL DELIVERY PIPE Applies until depletion	-	1	Enquire
0001	961203	FUEL DELIVERY PIPE	961203 FUEL DELIVERY PIPE Applicable after depletion of 316734	-	1	Enquire
0002	320598	CLIP	320598 CLIP	-	4	Enquire
0003	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM M6 X 16	-	4	Enquire
0004	316737	COMPL. RH FUEL PIPE MOUNTING BRACKET	316737 COMPL. RH FUEL PIPE MOUNTING BRACKET	-	1	Enquire
0005	316735	COMPL. LH FUEL PIPE MOUNTING BRACKET	316735 COMPL. LH FUEL PIPE MOUNTING BRACKET	-	1	Enquire
