LUBRICATION SYSTEM: TANK, PUMP AND FILTER of Ferrari Ferrari 458 Speciale Aperta

View All

Ferrari 458 Speciale Aperta - LUBRICATION SYSTEM: TANK, PUMP AND FILTER

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	793012	COMPL. OIL PUMP	Enquire	To Order
	781584	COMPL. OIL PUMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	274261	COMPL. OIL TANK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	237937	COMPLETE CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	176179	RUBBER PIPE FROM TANK TO CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	258855	3-WAY CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	165608	RUBBER PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	141235	RUBBER PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	290312	RH INLET PIPE	Enquire	To Order
	274264	RH INLET PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	290313	LH INLET PIPE	Enquire	To Order
	274266	LH INLET PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13432070	HOSE COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	287204	PIPE WITH FLANGE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	255176	OIL PICKUP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104212	O-RING	Enquire	To Order
	862084	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	239453	YOKE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	284579	OIL VAPOUR BREATHER PIPE	Enquire	To Order
	281311	OIL VAPOUR BREATHER PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13432070	HOSE COLLAR	Enquire	To Order
	13431970	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	100332	OIL PICKUP FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	125521	O-RING D78.97-8X100	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11500524	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	177576	CABLE GROMMET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	293107	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	253909	OIL RECOVERY PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	121903	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	239452	YOKE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10261460	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	241986	COLLAR FOR HOSE UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	275528	PUMP SEAL FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14306424	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14306624	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	292495	CALIBRATED STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	986899	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	247044	HEXAGONAL OIL PUMP DRIVE ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	271893	OIL PUMP GASKET KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14326101	THREADED PLUG	Enquire	To Order
	291502	CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	819489	FLANGED BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	255546	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	263347	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	294005	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	293410	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	299989	OIL PUMP HEAT SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	274262	OIL TANK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	284208	OIL VAPOUR BREATHER PIPE ON HEADS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	284209	OIL VAPOUR BREATHER PIPE, TANK SIDE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13046011	NUT	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	793012	COMPL. OIL PUMP	793012 COMPL. OIL PUMP	-	1	Enquire
1	781584	COMPL. OIL PUMP	781584 COMPL. OIL PUMP No longer supplied; Replaced by 793012	-	1	Enquire
2	274261	COMPL. OIL TANK	274261 COMPL. OIL TANK After depletion, order loose components; Applicable until depletion	-	1	Enquire
3	237937	COMPLETE CAP	237937 COMPLETE CAP	-	1	Enquire
4	176179	RUBBER PIPE FROM TANK TO CONNECTOR	176179 RUBBER PIPE FROM TANK TO CONNECTOR Applicable for USA, CDN, USA LIGHT	-	1	Enquire
5	258855	3-WAY CONNECTOR	258855 3-WAY CONNECTOR Applicable for USA, CDN, USA LIGHT	-	1	Enquire
6	165608	RUBBER PIPE	165608 RUBBER PIPE Applicable for USA, CDN, USA LIGHT	-	1	Enquire
7	141235	RUBBER PIPE	141235 RUBBER PIPE Applicable for USA, CDN, USA LIGHT	-	1	Enquire
8	290312	RH INLET PIPE	290312 RH INLET PIPE Applicable for USA, CDN, USA LIGHT	-	1	Enquire
8	274264	RH INLET PIPE	274264 RH INLET PIPE Not for USA, CDN, USA LIGHT	-	1	Enquire
9	290313	LH INLET PIPE	290313 LH INLET PIPE Applicable for USA, CDN, USA LIGHT	-	1	Enquire
9	274266	LH INLET PIPE	274266 LH INLET PIPE Not for USA, CDN, USA LIGHT	-	1	Enquire
10	13432070	HOSE COLLAR	13432070 HOSE COLLAR D. 15.7	-	2	Enquire
11	287204	PIPE WITH FLANGE	287204 PIPE WITH FLANGE	-	1	Enquire
12	255176	OIL PICKUP	255176 OIL PICKUP	-	1	Enquire
13	104212	O-RING	104212 O-RING Also supplied with kit 271893 ref. 37	-	2	Enquire
13	862084	GASKET	862084 GASKET Also supplied with kit 271893 ref. 37	-	1	Enquire
14	239453	YOKE	239453 YOKE	-	1	Enquire
15	284579	OIL VAPOUR BREATHER PIPE	284579 OIL VAPOUR BREATHER PIPE After depletion, order loose components; Applicable for USA, CDN, USA LIGHT; Applicable until depletion	-	1	Enquire
15	281311	OIL VAPOUR BREATHER PIPE	281311 OIL VAPOUR BREATHER PIPE Not for USA, CDN, USA LIGHT	-	1	Enquire
16	13432070	HOSE COLLAR	13432070 HOSE COLLAR D. 15.7; Head side	-	2	Enquire
16	13431970	COLLAR	13431970 COLLAR Tank side	-	1	Enquire
17	100332	OIL PICKUP FILTER	100332 OIL PICKUP FILTER	-	1	Enquire
18	125521	O-RING D78.97-8X100	125521 O-RING D78.97-8X100	-	1	Enquire
19	11500524	STUD BOLT	11500524 STUD BOLT	-	4	Enquire
20	177576	CABLE GROMMET	177576 CABLE GROMMET	-	4	Enquire
21	293107	THREADED PLUG	293107 THREADED PLUG	-	1	Enquire
22	231620	SCREW	231620 SCREW M6 X 25	-	4	Enquire
23	12643724	WASHER	12643724 WASHER	-	4	Enquire
24	253909	OIL RECOVERY PIPE	253909 OIL RECOVERY PIPE	-	1	Enquire
25	121903	GASKET	121903 GASKET Also supplied with kit 271893 ref. 37	-	4	Enquire
26	239452	YOKE	239452 YOKE	-	2	Enquire
27	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM M6 X 14	-	2	Enquire
28	10261460	GASKET	10261460 GASKET	-	1	Enquire
29	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM M6 X 14	-	4	Enquire
30	241986	COLLAR FOR HOSE UNION	241986 COLLAR FOR HOSE UNION Applicable for USA, CDN, USA LIGHT	-	1	Enquire
31	275528	PUMP SEAL FILTER	275528 PUMP SEAL FILTER	-	1	Enquire
32	14306424	SCREW	14306424 SCREW M8 X 20	-	2	Enquire
33	14306624	SCREW	14306624 SCREW M8 X 35	-	2	Enquire
34	292495	CALIBRATED STUD BOLT	292495 CALIBRATED STUD BOLT	-	2	Enquire
35	986899	WASHER	986899 WASHER	-	6	Enquire
36	247044	HEXAGONAL OIL PUMP DRIVE ROD	247044 HEXAGONAL OIL PUMP DRIVE ROD	-	1	Enquire
37	271893	OIL PUMP GASKET KIT	271893 OIL PUMP GASKET KIT	-	1	Enquire
38	14326101	THREADED PLUG	14326101 THREADED PLUG Applicable for USA, CDN, USA LIGHT	-	1	Enquire
38	291502	CONNECTOR	291502 CONNECTOR Not for USA, CDN, USA LIGHT	-	1	Enquire
39	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	4	Enquire
40	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	4	Enquire
41	819489	FLANGED BUSHING	819489 FLANGED BUSHING	-	8	Enquire
42	255546	CLIP	255546 CLIP	-	1	Enquire
43	263347	BRACKET	263347 BRACKET	-	1	Enquire
44	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM	-	2	Enquire
45	294005	STUD BOLT	294005 STUD BOLT	-	1	Enquire
46	293410	STUD BOLT	293410 STUD BOLT	-	1	Enquire
47	299989	OIL PUMP HEAT SHIELD	299989 OIL PUMP HEAT SHIELD	-	1	Enquire
48	231619	SOCKET HEAD SCREW M6 X 22 WITH WASHER	231619 SOCKET HEAD SCREW M6 X 22 WITH WASHER M6 X 18	-	2	Enquire
49	274262	OIL TANK	274262 OIL TANK	-	1	Enquire
50	284208	OIL VAPOUR BREATHER PIPE ON HEADS	284208 OIL VAPOUR BREATHER PIPE ON HEADS Applicable for USA, CDN, USA LIGHT	-	1	Enquire
51	284209	OIL VAPOUR BREATHER PIPE, TANK SIDE	284209 OIL VAPOUR BREATHER PIPE, TANK SIDE Applicable for USA, CDN, USA LIGHT	-	1	Enquire
52	13046011	NUT	13046011 NUT	-	1	Enquire
