Ferrari 360 Challenge (2000) - ELECTRICAL SYSTEM

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
182854 FRONT PART CONNECTING CABLES $3,184.38 To Order
Photo Part No Description Price (each) Stock
200827 ABS/ASR INSTALLATION CONNECTING CABLES $621.09 To Order
Photo Part No Description Price (each) Stock
172887 PEDAL DEVICE CONNECTING CABLES $2,227.17 To Order
Photo Part No Description Price (each) Stock
182851 DASHBOARD CONNECTION CABLES $5,770.12 To Order
Photo Part No Description Price (each) Stock
183483 CABLES FOR RH REAR TUNNEL CONNECTION $3,224.43 To Order
Photo Part No Description Price (each) Stock
177914 CABLES FOR LH REAR TUNNEL CONNECTION $5,927.37 To Order
Photo Part No Description Price (each) Stock
200836 REAR LIGHTS CONNECTING CABLES $1,123.20 To Order
Photo Part No Description Price (each) Stock
207330 COMPLETE CABLES F1 TRANSMISSION CONNECTION $1,296.37 To Order
Photo Part No Description Price (each) Stock
177912 CONNECTION CABLES FOR RH ENGINE COMPARTMENT $2,968.49 To Order
Photo Part No Description Price (each) Stock
213155 COMPLETE CONNECTION CABLES FOR MOTOR UTILITIES $1,739.90 To Order
Photo Part No Description Price (each) Stock
200840 CONNECTION CABLES FOR LH ENGINE COMPARTMENT $1,789.11 To Order
Photo Part No Description Price (each) Stock
155073 CABLE FOR ENGINE-FRAME EARTH $12.98 To Order
Photo Part No Description Price (each) Stock
199873 R.H. SIDE ENGINE INJECTION CABLES $703.40 To Order
Photo Part No Description Price (each) Stock
199874 L.H. SIDE ENGINE INJECTION CABLES $703.40 To Order
Photo Part No Description Price (each) Stock
182857 SPECIFICATION ACQUISITION WIRING $6,198.55 To Order
Photo Part No Description Price (each) Stock
184250 INERTIAL SWITCH LINK CABLE $561.59 To Order
View All
ELECTRICAL SYSTEM of Ferrari Ferrari 360 Challenge (2000) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 213155
COMPLETE CONNECTION CABLES FOR MOTOR UTILITIES
CABLES FOR MOTOR UTILITIES 		$1,739.90 (20.7% off) 1
- 200838
PEDAL DEVICE CONNECTING CABLES -Not for GD-
CABLES / Valid from car Ass. Nr. 36995 		$62.56 1
1 182854
FRONT PART CONNECTING CABLES
CABLES 		$3,184.38 1
2 200827
ABS/ASR INSTALLATION CONNECTING CABLES
CONNECTING CABLES 		$621.09 1
3 172887
PEDAL DEVICE CONNECTING CABLES
CABLES / Valid till car Ass. Nr. 36994 		$2,227.17 1
4 182851
DASHBOARD CONNECTION CABLES 		$5,770.12 1
5 183483
CABLES FOR RH REAR TUNNEL CONNECTION
CONNECTION 		$3,224.43 1
6 177914
CABLES FOR LH REAR TUNNEL CONNECTION
CONNECTION 		$5,927.37 1
7 200836
REAR LIGHTS CONNECTING CABLES
CABLES 		$1,123.20 2
8 207330
COMPLETE CABLES F1 TRANSMISSION CONNECTION
TRANSMISSION CONNECTION 		$1,296.37 1
9 177912
CONNECTION CABLES FOR RH ENGINE COMPARTMENT
R.H. ENGINE COMPARTMENT 		$2,968.49 1
10 213155
COMPLETE CONNECTION CABLES FOR MOTOR UTILITIES
CABLES FOR MOTOR UTILITIES / Not as spare part now / Replaced by 188108 		$1,739.90 (20.7% off) 1
11 200840
CONNECTION CABLES FOR LH ENGINE COMPARTMENT
L.H. ENGINE COMPARTMENT 		$1,789.11 1
12 155073
CABLE FOR ENGINE-FRAME EARTH 		$12.98 (42.3% off) 1
13 199873
R.H. SIDE ENGINE INJECTION CABLES
CABLES 		$703.40 1
14 199874
L.H. SIDE ENGINE INJECTION CABLES
CABLES 		$703.40 1
15 182857
SPECIFICATION ACQUISITION WIRING
WIRING 		$6,198.55 1
16 184250
INERTIAL SWITCH LINK CABLE
CABLE 		$561.59 1
