Name: FUEL PUMPS AND PIPES
Rating: 4.2 (1 reviews)

FUEL PUMPS AND PIPES of Ferrari Ferrari 360 Challenge (2000)

View All

Ferrari 360 Challenge (2000) - FUEL PUMPS AND PIPES

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	239814	RH Fuel Pump	$587.98	To Order

Photo	Part No	Description	Price (each)	Stock
	239813	LH Fuel Pump and Fuel Level Indicator Control	$611.98	To Order

Photo	Part No	Description	Price (each)	Stock
	194140	FUEL LEVEL INDICATOR	$176.49	To Order

Photo	Part No	Description	Price (each)	Stock
	182501	R.H. PUMP SUPPORT COVER	$2,198.28	To Order

Photo	Part No	Description	Price (each)	Stock
	170945	RING NUT	$36.27	To Order

Photo	Part No	Description	Price (each)	Stock
	182502	L.H. PUMP SUPPORT COVER	$2,198.28	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WASHER	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	183103	CONNECTION SLEEVE	$107.49	To Order

Photo	Part No	Description	Price (each)	Stock
	13001690	SCREW COLLAR	$1.36	To Order

Photo	Part No	Description	Price (each)	Stock
	10977624	SCREW	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	178753	LH Fuel Delivery Pipe	$176.49	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	178445	RH Fuel Delivery Pipe	$240.67	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	170946	FUEL PUMP SEAL	$11.86	To Order

Photo	Part No	Description	Price (each)	Stock
	182900	DISAREATOR	$115.19	To Order

Photo	Part No	Description	Price (each)	Stock
	178430	FASTENER CLIP	$0.41	To Order

Photo	Part No	Description	Price (each)	Stock
	160855	GROUND CABLE	$208.58	To Order

Photo	Part No	Description	Price (each)	Stock
	10902424	SCREW	$0.15	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WASHER	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	14498801	WASHER	$0.11	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	239814	RH Fuel Pump	239814 RH Fuel Pump	$587.98	1
2	239813	LH Fuel Pump and Fuel Level Indicator Control	239813 LH Fuel Pump and Fuel Level Indicator Control FUEL LEVEL INDICATOR / CONTROL /	$611.98 MSRP: ~~654.71~~ (6.5% off)	1
3	194140	FUEL LEVEL INDICATOR	194140 FUEL LEVEL INDICATOR	$176.49	1
4	182501	R.H. PUMP SUPPORT COVER	182501 R.H. PUMP SUPPORT COVER	$2,198.28	1
5	170945	RING NUT	170945 RING NUT	$36.27	2
6	182502	L.H. PUMP SUPPORT COVER	182502 L.H. PUMP SUPPORT COVER	$2,198.28	1
7	12643724	WASHER	12643724 WASHER	$0.06 MSRP: ~~0.50~~ (88% off)	2
8	11197774	WASHER	11197774 WASHER	$0.06 MSRP: ~~0.30~~ (80% off)	2
9	183103	CONNECTION SLEEVE	183103 CONNECTION SLEEVE	$107.49	2
10	13001690	SCREW COLLAR	13001690 SCREW COLLAR	$1.36	4
11	10977624	SCREW	10977624 SCREW	$0.06	38
12	12604178	Washer	12604178 Washer	-	38	Enquire
13	178753	LH Fuel Delivery Pipe ARRIVING SOON	178753 LH Fuel Delivery Pipe ARRIVING SOON	$176.49 MSRP: ~~226.81~~ (22.2% off)	1
14	178445	RH Fuel Delivery Pipe ARRIVING SOON	178445 RH Fuel Delivery Pipe ARRIVING SOON	$240.67 MSRP: ~~307.57~~ (21.8% off)	1
15	170946	FUEL PUMP SEAL	170946 FUEL PUMP SEAL	$11.86 MSRP: ~~24.30~~ (51.2% off)	2
16	182900	DISAREATOR	182900 DISAREATOR	$115.19	1
17	178430	FASTENER CLIP	178430 FASTENER CLIP	$0.41 MSRP: ~~0.75~~ (45.3% off)	4
18	160855	GROUND CABLE	160855 GROUND CABLE	$208.58	2
19	10902424	SCREW	10902424 SCREW	$0.15 MSRP: ~~0.70~~ (78.6% off)	2
20	11197774	WASHER	11197774 WASHER	$0.06 MSRP: ~~0.30~~ (80% off)	2
21	14498801	WASHER	14498801 WASHER	$0.11 MSRP: ~~0.20~~ (45% off)	2
