185041 |
RING
|
185041
RING
Thickness mm. 4,60 / Possible fitting |
$39.17 |
1 |
|
|
|
|
- |
185037 |
SNAP RING
|
185037
SNAP RING
Thickness mm. 1,60 / Possible fitting |
$70.00 |
1 |
|
|
|
|
- |
185040 |
RING
|
185040
RING
Thickness mm. 4,85 / Possible fitting |
$47.67 |
1 |
|
|
|
|
- |
185036 |
SNAP RING
|
185036
SNAP RING
Thickness mm. 1,85 / Possible fitting |
$40.50 |
1 |
|
|
|
|
- |
188495 |
RING
|
188495
RING
Thickness mm. 6,10 - Possible fitting / Valid for secondary shaft with / groove for flexible ring 183976 / See Pos. 40 |
$36.21 |
1 |
|
|
|
|
- |
188496 |
RING
|
188496
RING
Thickness mm. 5,80 - Possible fitting / Valid for secondary shaft with / groove for flexible ring 183976 / See Pos. 40 |
$36.21 |
1 |
|
|
|
|
- |
185038 |
RING
|
185038
RING
Thickness mm. 3,95 - Possible fitting / Valid for secondary shaft without / groove for flexible ring 183976 / See Pos. 40 |
$36.94 MSRP: 48.25 (23.4% off)
|
1 |
|
|
|
|
- |
185039 |
RING
|
185039
RING
Thickness mm. 3,60 - Possible fitting / Valid for secondary shaft without / groove for flexible ring 183976 / See Pos. 40 |
$36.94 |
1 |
|
|
|
|
- |
188461 |
5th AND 6th DRIVEN GEAR
|
188461
5th AND 6th DRIVEN GEAR
GEAR / Valid for secondary shaft with / groove for flexible ring 183976 / See Pos. 40 |
$545.22 |
1 |
|
|
|
|
- |
185043 |
RING ADJUSTER
|
185043
RING ADJUSTER
Thickness mm. 2,5 / Possible fitting |
$18.59 |
1 |
|
|
|
|
- |
185044 |
RING ADJUSTER
|
185044
RING ADJUSTER
Thickness mm. 2,2 / Possible fitting |
$32.32 |
1 |
|
|
|
|
- |
185046 |
RING ADJUSTER
|
185046
RING ADJUSTER
Thickness mm. 6,85 / Possible fitting |
$36.94 |
1 |
|
|
|
|
- |
185047 |
RING ADJUSTER
|
185047
RING ADJUSTER
Thickness mm. 6,60 / Possible fitting |
$36.94 MSRP: 53.34 (30.7% off)
|
1 |
|
|
|
|
- |
190013 |
COMPETE BEVEL SET
|
190013
COMPETE BEVEL SET
Valid for secondary shaft with / groove for flexible ring 183976 / See Pos. 40 |
$1,815.82 |
1 |
|
|
|
|
1 |
190013 |
COMPETE BEVEL SET
|
190013
COMPETE BEVEL SET
Valid for secondary shaft without / groove for flexible ring 183976 / See Pos. 40 |
$1,815.82 |
1 |
|
|
|
|
2 |
849234 |
SCREW
|
849234
SCREW |
$2.92 |
9 |
|
|
|
|
3 |
185022 |
ROLLER BEARING
|
185022
ROLLER BEARING |
$347.97 |
1 |
|
|
|
|
4 |
185045 |
RING ADJUSTER
|
185045
RING ADJUSTER
Thickness mm. 7,10 |
$36.94 |
1 |
|
|
|
|
5 |
185042 |
RING ADJUSTER
|
185042
RING ADJUSTER
Thickness mm. 2,8 |
$11.54 |
1 |
|
|
|
|
6 |
185020 |
BEARING MOUNTING
|
185020
BEARING MOUNTING |
$624.03 |
1 |
|
|
|
|
7 |
185021 |
Roller Bearing
|
185021
Roller Bearing |
$185.79 |
1 |
|
|
|
|
8 |
196667 |
GEARBOX RING NUT M45 X 1.5
|
196667
GEARBOX RING NUT M45 X 1.5 |
$68.97 |
1 |
|
|
|
|
9 |
185018 |
3rd AND 4th SPEED GEAR CONTROL
|
185018
3rd AND 4th SPEED GEAR CONTROL
GEAR |
$1,672.72 |
1 |
|
|
|
|
10 |
185017 |
5th AND 6th DRIVEN GEAR
|
185017
5th AND 6th DRIVEN GEAR
GEAR / Valid for secondary shaft without / groove for flexible ring 183976 / See Pos. 40 |
$3,610.28 |
1 |
|
|
|
|
11 |
183974 |
RING
|
183974
RING
Thickness mm. 4,30 - Possible fitting / Valid for secondary shaft without / groove for flexible ring 183976 / See Pos. 40 |
$38.12 |
1 |
|
|
|
|
12 |
184014 |
ROLLER BEARING CAGE
|
184014
ROLLER BEARING CAGE |
$21.59 |
1 |
|
|
|
|
13 |
183946 |
2nd SPEED GEAR
|
183946
2nd SPEED GEAR |
$1,522.03 |
1 |
|
|
|
|
14 |
183976 |
SNAP RING
|
183976
SNAP RING
Thickness mm. 2,10 |
$13.70 |
1 |
|
|
|
|
15 |
183971 |
BUSHING
|
183971
BUSHING |
$86.21 |
1 |
|
|
|
|
16 |
184016 |
ROLLER BEARING CAGE
|
184016
ROLLER BEARING CAGE |
$27.49 MSRP: 33.00 (16.7% off)
|
1 |
|
|
|
|
17 |
183945 |
1st SPEED GEAR
|
183945
1st SPEED GEAR |
$887.62 |
1 |
|
|
|
|
18 |
183972 |
CENTRE BEARING
|
183972
CENTRE BEARING
Thickness mm. 5,10 |
$87.18 |
1 |
|
|
|
|
19 |
184020 |
Roller Bearing
|
184020
Roller Bearing |
$167.98 MSRP: 280.72 (40.2% off)
|
1 |
|
|
|
|
20 |
184042 |
SNAP RING
|
184042
SNAP RING |
$13.70 MSRP: 15.17 (9.7% off)
|
1 |
|
|
|
|
21 |
185168 |
REVERSE GEAR
|
185168
REVERSE GEAR |
$251.73 |
1 |
|
|
|
|
22 |
184018 |
ROLLER BEARING CAGE
|
184018
ROLLER BEARING CAGE |
$32.38 MSRP: 37.00 (12.5% off)
|
1 |
|
|
|
|
23 |
185167 |
REVERSE GEAR COMPLETE SYNCHRONIZER
|
185167
REVERSE GEAR COMPLETE SYNCHRONIZER
SYNCHRONIZER |
$198.21 |
1 |
|
|
|
|
24 |
184041 |
SNAP RING
|
184041
SNAP RING |
$5.12 MSRP: 12.20 (58% off)
|
1 |
|
|
|
|
25 |
14303624 |
SCREW
|
14303624
SCREW |
$0.45 |
4 |
|
|
|
|
26 |
10571379 |
WASHER
|
10571379
WASHER |
$0.06 |
4 |
|
|
|
|
27 |
216271 |
GEARBOX OIL PUMP
|
216271
GEARBOX OIL PUMP |
$1,379.94 |
1 |
|
|
|
|
28 |
185164 |
1ST AND 2ND SPEED SYNCHRONISER
|
185164
1ST AND 2ND SPEED SYNCHRONISER
SYNCHRONIZER |
$2,088.64 |
1 |
|
|
|
|
29 |
185050 |
PUMP DRIVE SHAFT
|
185050
PUMP DRIVE SHAFT |
$60.96 |
1 |
|
|
|
|
30 |
184017 |
DRAWN CUP NEEDLE BEARING
|
184017
DRAWN CUP NEEDLE BEARING |
$9.95 MSRP: 29.98 (66.8% off)
|
2 |
|
|
|
|
31 |
183975 |
RING
|
183975
RING |
$27.42 |
2 |
|
|
|
|
32 |
183969 |
IDLE GEAR FOR REVERSE
|
183969
IDLE GEAR FOR REVERSE |
$1,004.53 |
1 |
|
|
|
|
33 |
184991 |
PAD FOR SYNCHRONIZER |
184991
PAD FOR SYNCHRONIZER
Not as spare part replaced by 188320 / See ref. 41 / |
-
|
3 |
|
Enquire
|
|
|
34 |
184997 |
BALL |
184997
BALL
Not as spare part replaced by 188320 / See ref. 41 |
-
|
3 |
|
Enquire
|
|
|
35 |
184989 |
SPRING FOR BALL |
184989
SPRING FOR BALL
Not as spare part replaced by 188320 / See ref. 41 |
-
|
3 |
|
Enquire
|
|
|
36 |
185015 |
SPRING
|
185015
SPRING
Not as spare part replaced by 188321 / See ref. 42 |
$0.28 |
3 |
|
|
|
|
37 |
185016 |
ROLL
|
185016
ROLL
Not as spare part replaced by 188321 / See ref. 42 |
$0.49 |
3 |
|
|
|
|
38 |
201870 |
BUSHING
|
201870
BUSHING |
$25.35 |
1 |
|
|
|
|
39 |
188497 |
SHIM
|
188497
SHIM
Valid for secondary shaft with / groove for flexible ring 183976 / See Pos. 40 |
$86.75 |
1 |
|
|
|
|
40 |
183976 |
SNAP RING
|
183976
SNAP RING |
$13.70 |
1 |
|
|
|
|
41 |
188320 |
SYNCHRO BLOCK/BALL/SPRING REPLACEMENT KIT
|
188320
SYNCHRO BLOCK/BALL/SPRING REPLACEMENT KIT
SPRING REPLACEMENT KIT |
$13.58 |
1 |
|
|
|
|
42 |
188321 |
SPRING/ROLL/SYNCHRO REVERSE GEAR KIT
|
188321
SPRING/ROLL/SYNCHRO REVERSE GEAR KIT
KIT |
$3.60 |
1 |
|
|
