Find Your Part

TUNNEL - ACCESSORIES of Ferrari Ferrari 348 (2.7 Motronic)

View All

Ferrari 348 (2.7 Motronic) - TUNNEL - ACCESSORIES

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	62147100	RADIO CASING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14202782	BLOCK -Valid for SA-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15688375	SELF-TAPPING SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	133627	RUBBER PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62147900	SPRING FOR DOOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	621474	COVERED CAR RADIO OUTER SET HOLDER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62147800	PIN FOR DOOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62993700	COVERED INNER GLOVE BOX PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	146375	CONSOLE PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147111	TUNNEL PLATE -Not for GD-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62146600	ASH TRAY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	226942	CIGARETTE LIGHTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62147500	CAR RADIO GLOVE BOX INNER DOOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	226941	CIGARETTE LIGHTER SOCKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62146500	PLATE FOR MONEY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	633222	COVERED GLOVE BOX BOTTOM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61059000	CASSETTE BOX	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	636288	SUPPORT FOR CASSETTE BOX	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61059200	HINGE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	610594	CASSETTE BOX WITH MOULDING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61059900	BUTTON MOULDING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61059100	CASSETTE BOX SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61060000	INNER DOOR UPHOLSTERY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15913508	SCREW -Not for GTS-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13577411	WASHER -Not for GTS-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10615174	WASHER -Not for GTS-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16101714	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	319201	FUEL FILLER PIPE ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638124	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61059700	SPRING -Not for GTS-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61059600	PUSH BUTTON -Not for GTS-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	61059800	COVER FOR SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15914608	SCREW -Not for GTS-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	622260	COVERED CAR RADIO OUTER SET HOLDER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	63921600	Spider NAMEPLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	88074800	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15688375	SELF-TAPPING SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62769800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15669706	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14115980	BLOCK-Valid for USA-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	88822200	SCREW TORX HEAD M4 X 10MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14115580	FIXING BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	633396	COVERED GLOVE BOX BOTTOM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62993400	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16101714	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10615174	WASHER -Not for GTS-	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	633221	UPHOLSTERY	633221 UPHOLSTERY Valid for GTS	-	1	Enquire
-	622261	DOOR UPHOLSTERY	622261 DOOR UPHOLSTERY Valid for USA	-	1	Enquire
-	610595	UPHOLSTERY -Not for GTS-	610595 UPHOLSTERY -Not for GTS-	-	1	Enquire
-	633219	UPHOLSTERY	633219 UPHOLSTERY	-	1	Enquire
-	147112	TUNNEL PLATE -Valid for GD-	147112 TUNNEL PLATE -Valid for GD-	-	1	Enquire
-	157146	CONSOLE PLATE	157146 CONSOLE PLATE Valid for Spider	-	1	Enquire
-	621477	DOOR UPHOLSTERY	621477 DOOR UPHOLSTERY Not for USA	-	1	Enquire
1	62147100	RADIO CASING	62147100 RADIO CASING	-	1	Enquire
2	14202782	BLOCK -Valid for SA-	14202782 BLOCK -Valid for SA-	-	2	Enquire
3	15688375	SELF-TAPPING SCREW	15688375 SELF-TAPPING SCREW	-	2	Enquire
4	133627	RUBBER PLUG	133627 RUBBER PLUG	-	1	Enquire
5	62147900	SPRING FOR DOOR	62147900 SPRING FOR DOOR	-	1	Enquire
6	621474	COVERED CAR RADIO OUTER SET HOLDER	621474 COVERED CAR RADIO OUTER SET HOLDER SET HOLDER / Not for USA	-	1	Enquire
7	62147800	PIN FOR DOOR	62147800 PIN FOR DOOR	-	1	Enquire
8	62993700	COVERED INNER GLOVE BOX PLATE	62993700 COVERED INNER GLOVE BOX PLATE PLATE	-	1	Enquire
9	146375	CONSOLE PLATE	146375 CONSOLE PLATE Not for Spider	-	1	Enquire
10	147111	TUNNEL PLATE -Not for GD-	147111 TUNNEL PLATE -Not for GD-	-	1	Enquire
11	62146600	ASH TRAY	62146600 ASH TRAY Only part. 12 included	-	1	Enquire
13	226942	CIGARETTE LIGHTER	226942 CIGARETTE LIGHTER	-	1	Enquire
14	62147500	CAR RADIO GLOVE BOX INNER DOOR	62147500 CAR RADIO GLOVE BOX INNER DOOR INNER DOOR -Not for USA	-	1	Enquire
15	226941	CIGARETTE LIGHTER SOCKET	226941 CIGARETTE LIGHTER SOCKET	-	1	Enquire
16	62146500	PLATE FOR MONEY	62146500 PLATE FOR MONEY	-	1	Enquire
17	633222	COVERED GLOVE BOX BOTTOM	633222 COVERED GLOVE BOX BOTTOM	-	1	Enquire
18	61059000	CASSETTE BOX	61059000 CASSETTE BOX Not for GTS	-	1	Enquire
19	636288	SUPPORT FOR CASSETTE BOX	636288 SUPPORT FOR CASSETTE BOX BOX -Not for GTS	-	1	Enquire
20	61059200	HINGE	61059200 HINGE Not for GTS	-	1	Enquire
21	610594	CASSETTE BOX WITH MOULDING	610594 CASSETTE BOX WITH MOULDING MOULDING -Not for GTS	-	1	Enquire
22	61059900	BUTTON MOULDING	61059900 BUTTON MOULDING Not for GTS	-	1	Enquire
23	61059100	CASSETTE BOX SHIELD	61059100 CASSETTE BOX SHIELD Not for GTS	-	4	Enquire
24	61060000	INNER DOOR UPHOLSTERY	61060000 INNER DOOR UPHOLSTERY Not for GTS	-	1	Enquire
25	15913508	SCREW -Not for GTS-	15913508 SCREW -Not for GTS-	-	2	Enquire
26	13577411	WASHER -Not for GTS-	13577411 WASHER -Not for GTS-	-	8	Enquire
27	10615174	WASHER -Not for GTS-	10615174 WASHER -Not for GTS-	-	8	Enquire
28	16101714	NUT	16101714 NUT	-	8	Enquire
29	319201	FUEL FILLER PIPE ASSEMBLY	319201 FUEL FILLER PIPE ASSEMBLY	-	1	Enquire
30	12638124	WASHER	12638124 WASHER	-	1	Enquire
31	61059700	SPRING -Not for GTS-	61059700 SPRING -Not for GTS-	-	1	Enquire
32	61059600	PUSH BUTTON -Not for GTS-	61059600 PUSH BUTTON -Not for GTS-	-	1	Enquire
33	61059800	COVER FOR SPRING	61059800 COVER FOR SPRING Not for GTS	-	1	Enquire
34	15914608	SCREW -Not for GTS-	15914608 SCREW -Not for GTS-	-	12	Enquire
35	622260	COVERED CAR RADIO OUTER SET HOLDER	622260 COVERED CAR RADIO OUTER SET HOLDER SET HOLDER / Valid for USA	-	1	Enquire
36	63921600	Spider NAMEPLATE	63921600 Spider NAMEPLATE Valid for USA	-	1	Enquire
37	88074800	CLIP	88074800 CLIP Valid for USA	-	2	Enquire
38	15688375	SELF-TAPPING SCREW	15688375 SELF-TAPPING SCREW	-	2	Enquire
39	62769800	WASHER	62769800 WASHER	-	2	Enquire
40	15669706	SCREW	15669706 SCREW	-	4	Enquire
41	14115980	BLOCK-Valid for USA-	14115980 BLOCK-Valid for USA-	-	2	Enquire
42	88822200	SCREW TORX HEAD M4 X 10MM	88822200 SCREW TORX HEAD M4 X 10MM	-	2	Enquire
43	14115580	FIXING BLOCK	14115580 FIXING BLOCK	-	2	Enquire
44	633396	COVERED GLOVE BOX BOTTOM	633396 COVERED GLOVE BOX BOTTOM Valid for GTS	-	1	Enquire
45	62993400	CLIP	62993400 CLIP	-	2	Enquire
46	16101714	NUT	16101714 NUT	-	2	Enquire
47	10615174	WASHER -Not for GTS-	10615174 WASHER -Not for GTS-	-	2	Enquire
