Brake Actuator Assembly

Aston Martin V12 Vantage (upto 2016)

Find Your Part

Aston Martin V12 Vantage (upto 2016) - Brake Actuator Assembly

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
8D332450CF MAN BRK & BRKT $1,046.50 To Order
8D332450AF MAN BRK & BRKT $1,046.50 To Order
Photo Part No Description Price (each) Stock
703584 Screw, M8 x 40, Flange Head $0.87 To Order
Photo Part No Description Price (each) Stock
4G432D042AA KIT PAD MAN BRK/CL PDL $514.47 To Order
Photo Part No Description Price (each) Stock
4G437578AA Kit, Clutch Master Cylinder $557.95 IN STOCK
Photo Part No Description Price (each) Stock
3384098 Lip Seal, Master Cylinder $9.40 IN STOCK
Photo Part No Description Price (each) Stock
701342PK NUT M8 HEX P/T PLAS8 PACK OF 5 $13.57 To Order
Photo Part No Description Price (each) Stock
2984879 Pin, Joint $17.45 To Order
Photo Part No Description Price (each) Stock
6G3327328AA Clip, Safety, Nom Shaft, 5/16 $0.75 To Order
View All
Brake Actuator Assembly of Aston Martin Aston Martin V12 Vantage (upto 2016) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 8D332450CF
MAN BRK & BRKT
RHD 		$1,046.50 1
1 8D332450AF
MAN BRK & BRKT
LHD 		$1,046.50 1
2 703584
Screw, M8 x 40, Flange Head 		$0.87 3
3 4G432D042AA
KIT PAD MAN BRK/CL PDL 		$514.47 2
4 4G437578AA
Kit, Clutch Master Cylinder
IN STOCK 		$557.95 1
5 3384098
Lip Seal, Master Cylinder
IN STOCK 		$9.40 1
6 701342PK
NUT M8 HEX P/T PLAS8 PACK OF 5 		$13.57 2
7 2984879
Pin, Joint 		$17.45 1
8 6G3327328AA
Clip, Safety, Nom Shaft, 5/16 		$0.75 1
