Door Trim Panel, Front

Rolls Royce Phantom Drophead Coupe

Find Your Part

Rolls Royce Phantom Drophead Coupe - Door trim panel, front

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
51419158757 Door trim panel, front left Enquire To Order
51419158758 Door trim panel, front right Enquire To Order
Photo Part No Description Price (each) Stock
51419113837 Capping, door, left Enquire To Order
51419113838 Capping, door, right Enquire To Order
51419158755 Capping, door, left Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
51417061692 Bracket Enquire To Order
Photo Part No Description Price (each) Stock
7147129317 Clip blue Enquire To Order
Photo Part No Description Price (each) Stock
7147075867 Torx bolt Enquire To Order
Photo Part No Description Price (each) Stock
51417220237 Speaker cover, mid-range speaker Enquire To Order
Photo Part No Description Price (each) Stock
65130420684 Loudspeaker HiFi, mid-range Enquire To Order
Photo Part No Description Price (each) Stock
7147135132 Fillister head screw Enquire To Order
Photo Part No Description Price (each) Stock
51218270148 Torx bolt Enquire To Order
Photo Part No Description Price (each) Stock
51417166963 Trim, door trim panel, front left Enquire To Order
51417166964 Trim, door trim panel, front right Enquire To Order
Photo Part No Description Price (each) Stock
7149144232 Insert Enquire To Order
Photo Part No Description Price (each) Stock
7149144233 Torx bolt Enquire To Order
Photo Part No Description Price (each) Stock
51168223113 Hex nut Enquire To Order
Photo Part No Description Price (each) Stock
51417166965 Armrest, front left Enquire To Order
51417166966 Armrest, front right Enquire To Order
51417166967 Armrest, front left Enquire To Order
...and 5 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
51416986387 Locator, ashtray, left Enquire To Order
51416986388 Locator, ashtray, right Enquire To Order
Photo Part No Description Price (each) Stock
51416978211 Ashtray Enquire To Order
Photo Part No Description Price (each) Stock
51416980069 FRAME LEFT Enquire To Order
51416980070 FRAME LEFT Enquire To Order
51417166969 FRAME LEFT Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
51177067802 Clip nut Enquire To Order
Photo Part No Description Price (each) Stock
7129905168 Torx screw Enquire To Order
Photo Part No Description Price (each) Stock
51419180779 Channel strip, door, left Enquire To Order
51419180780 Channel strip, door, right Enquire To Order
Photo Part No Description Price (each) Stock
51417061691 Cover, locking button Enquire To Order
Photo Part No Description Price (each) Stock
51417223809 Gas-filled strut, left Enquire To Order
51417223810 Gas-filled strut, right Enquire To Order
Photo Part No Description Price (each) Stock
65108139466 Oval head screw Enquire To Order
Photo Part No Description Price (each) Stock
51419133907 Axle, long, left Enquire To Order
51419133908 Axle, long, right Enquire To Order
Photo Part No Description Price (each) Stock
51419133905 Axle, left Enquire To Order
51419133906 Axle, right Enquire To Order
Photo Part No Description Price (each) Stock
51248119306 Stop buffer Enquire To Order
Photo Part No Description Price (each) Stock
7129904073 Isa screw Enquire To Order
Photo Part No Description Price (each) Stock
51417249811 Door pocket, left Enquire To Order
51417249812 Door pocket, right Enquire To Order
51419158753 Door pocket, left Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
51416986929 Mounting, hinge Enquire To Order
Photo Part No Description Price (each) Stock
51419115551 Set, seal, left Enquire To Order
51419115552 Set, seal, right Enquire To Order
Photo Part No Description Price (each) Stock
51226956875 Door handle, inside left Enquire To Order
51226956876 Door handle inner right Enquire To Order
Photo Part No Description Price (each) Stock
51419143799 Combi. fillister head self-tapping screw Enquire To Order
Photo Part No Description Price (each) Stock
11129157025 Body nut Enquire To Order
Photo Part No Description Price (each) Stock
51417022046 Clamp Enquire To Order
Photo Part No Description Price (each) Stock
51419158749 Covering left Enquire To Order
51419158750 Covering right Enquire To Order
Photo Part No Description Price (each) Stock
51419171250 Adhesive tape Enquire To Order
Photo Part No Description Price (each) Stock
51416986227 Mounting, power-window switch Enquire To Order
Photo Part No Description Price (each) Stock
51419158751 Armrest, left Enquire To Order
51419158752 Armrest, right Enquire To Order
Photo Part No Description Price (each) Stock
51419190911 Take-up, gas-filled strut Enquire To Order
Photo Part No Description Price (each) Stock
7147135132 Fillister head screw Enquire To Order
Photo Part No Description Price (each) Stock
51419126963 Bush Enquire To Order
Photo Part No Description Price (each) Stock
51417249813 Trim, door pocket, left Enquire To Order
51417249814 Trim, door pocket, right Enquire To Order
View All
Door trim panel, front of Rolls Royce Rolls Royce Phantom Drophead Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 7147266373
Gasket ring 		- - Enquire
- 51419158741
Armrest, front left
QUOTE COLOUR 		- - Enquire
- 51419158742
Armrest, front right
QUOTE COLOUR 		- - Enquire
- 51419158743
Armrest, front left
QUOTE COLOUR 		- - Enquire
- 51419158744
Armrest, front right
QUOTE COLOUR 		- - Enquire
1 51419158757
Door trim panel, front left
QUOTE COLOUR 		- - Enquire
1 51419158758
Door trim panel, front right
QUOTE COLOUR 		- - Enquire
2 51419113837
Capping, door, left
TEAK 		- - Enquire
2 51419113838
Capping, door, right
TEAK 		- - Enquire
2 51419158755
Capping, door, left
QUOTE COLOUR 		- - Enquire
2 51459158756
Capping, door, right
QUOTE COLOUR 		- - Enquire
3 51417061692
Bracket 		- - Enquire
4 7147129317
Clip blue 		- - Enquire
5 7147075867
Torx bolt
ISA M6X22 		- - Enquire
6 51417220237
Speaker cover, mid-range speaker
CHROME 		- - Enquire
7 65130420684
Loudspeaker HiFi, mid-range 		- - Enquire
8 7147135132
Fillister head screw
ISA 4X12 		- - Enquire
9 51218270148
Torx bolt 		- - Enquire
10 51417166963
Trim, door trim panel, front left
CHROM 		- - Enquire
10 51417166964
Trim, door trim panel, front right
CHROM 		- - Enquire
11 7149144232
Insert 		- - Enquire
12 7149144233
Torx bolt 		- - Enquire
13 51168223113
Hex nut
M4 		- - Enquire
14 51417166965
Armrest, front left
QUOTE VENEER 		- - Enquire
14 51417166966
Armrest, front right
QUOTE VENEER 		- - Enquire
14 51417166967
Armrest, front left
QUOTE VENEER 		- - Enquire
14 51417166968
Armrest, front right
QUOTE VENEER 		- - Enquire
14 51419158741
Armrest, front left
QUOTE COLOUR 		- - Enquire
14 51419158742
Armrest, front right
QUOTE COLOUR 		- - Enquire
14 51419158743
Armrest, front left
QUOTE COLOUR 		- - Enquire
14 51419158744
Armrest, front right
QUOTE COLOUR 		- - Enquire
15 51416986387
Locator, ashtray, left 		- - Enquire
15 51416986388
Locator, ashtray, right 		- - Enquire
16 51416978211
Ashtray 		- - Enquire
17 51416980069
FRAME LEFT
CHROM 		- - Enquire
17 51416980070
FRAME LEFT
CHROM 		- - Enquire
17 51417166969
FRAME LEFT
CHROM 		- - Enquire
17 51417166970
FRAME RIGHT
CHROM 		- - Enquire
18 51177067802
Clip nut 		- - Enquire
19 7129905168
Torx screw
M4X12 		- - Enquire
20 51419180779
Channel strip, door, left
CHROM 		- - Enquire
20 51419180780
Channel strip, door, right
CHROM 		- - Enquire
21 51417061691
Cover, locking button 		- - Enquire
22 51417223809
Gas-filled strut, left 		- - Enquire
22 51417223810
Gas-filled strut, right 		- - Enquire
23 65108139466
Oval head screw
TS 4X10MM 		- - Enquire
24 51419133907
Axle, long, left 		- - Enquire
24 51419133908
Axle, long, right 		- - Enquire
25 51419133905
Axle, left 		- - Enquire
25 51419133906
Axle, right 		- - Enquire
26 51248119306
Stop buffer 		- - Enquire
27 7129904073
Isa screw
M6X20-ZNS3 		- - Enquire
28 51417249811
Door pocket, left
COLOUR NEUTRAL 		- - Enquire
28 51417249812
Door pocket, right
COLOUR NEUTRAL 		- - Enquire
28 51419158753
Door pocket, left
QUOTE COLOUR 		- - Enquire
28 51419158754
Door pocket, right
QUOTE COLOUR 		- - Enquire
29 51416986929
Mounting, hinge 		- - Enquire
30 51419115551
Set, seal, left 		- - Enquire
30 51419115552
Set, seal, right 		- - Enquire
31 51226956875
Door handle, inside left
BLUE CHROME 		- - Enquire
31 51226956876
Door handle inner right
BLUE CHROME 		- - Enquire
32 51419143799
Combi. fillister head self-tapping screw
ST 4,8X16 		- - Enquire
33 11129157025
Body nut 		- - Enquire
34 51417022046
Clamp 		- - Enquire
35 51419158749
Covering left
QUOTE COLOUR 		- - Enquire
35 51419158750
Covering right
QUOTE COLOUR 		- - Enquire
36 51419171250
Adhesive tape 		- - Enquire
37 51416986227
Mounting, power-window switch 		- - Enquire
38 51419158751
Armrest, left
QUOTE COLOUR 		- - Enquire
38 51419158752
Armrest, right
QUOTE COLOUR 		- - Enquire
39 51419190911
Take-up, gas-filled strut 		- - Enquire
40 7147135132
Fillister head screw
ISA 4X12 		- - Enquire
41 51419126963
Bush 		- - Enquire
42 51417249813
Trim, door pocket, left
COLOUR NEUTRAL 		- - Enquire
42 51417249814
Trim, door pocket, right
COLOUR NEUTRAL 		- - Enquire
