BRAKING DEVICES ON REAR WHEELS of Maserati Maserati MC20 Leggenda Automatic 3.0 BT V6 2WD 630HP

View All

Maserati MC20 Leggenda Automatic 3.0 BT V6 2WD 630HP - BRAKING DEVICES ON REAR WHEELS (04112)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	670161622	REAR BRAKE DISC	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000081	SCREW M10	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670219655	BRAKE DISC SHIELD	Enquire	To Order
	670219686	BRAKE DISC SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675001032	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	19938333	EC conformity certificate	Enquire	To Order
	19938332	EC conformity certificate	Enquire	To Order
	670215074	RH REAR CALIPER ASSEMBLY	Enquire	To Order

...and 9 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	675001192	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670156282	FLEXIBLE PIPE TO REAR CALIPERS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670212955	LH BRACKET	Enquire	To Order
	670212954	RH BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675001159	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000276	SPRING PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012868	REAR PADS KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673010935	RH BRACKET AND SCREW	Enquire	To Order
	673010936	LH BRACKET AND SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673001646	BLEEDER SCREW AND PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673010932	SPRING AND PINS KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670219436	RH REAR AIR CONVEYOR	Enquire	To Order
	670219437	LH REAR AIR CONVEYOR	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	670161622	REAR BRAKE DISC	670161622 REAR BRAKE DISC Available with: DUAL-CAST STEEL BRAKES Not available with: CARBON CERAMIC BRAKES;	-	2	Enquire
2	675000081	SCREW M10	675000081 SCREW M10	-	2	Enquire
3	670219655	BRAKE DISC SHIELD	670219655 BRAKE DISC SHIELD RH side; Available with: DUAL-CAST STEEL BRAKES Not available with: CARBON CERAMIC BRAKES;	-	1	Enquire
3	670219686	BRAKE DISC SHIELD	670219686 BRAKE DISC SHIELD LH side; Available with: DUAL-CAST STEEL BRAKES Not available with: CARBON CERAMIC BRAKES;	-	1	Enquire
4	675001032	SCREW	675001032 SCREW	-	6	Enquire
5	19938333	EC conformity certificate	19938333 EC conformity certificate WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 7003461 - 99999999; Available with: BRAKE CALIPERS ANODIZED IN GREY, DUAL-CAST STEEL BRAKES ;	-	1	Enquire
5	19938332	EC conformity certificate	19938332 EC conformity certificate WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 7003461 - 99999999; Available with: SILVER BRAKE CALIPERS, DUAL-CAST STEEL BRAKES ;	-	1	Enquire
5	670215074	RH REAR CALIPER ASSEMBLY	670215074 RH REAR CALIPER ASSEMBLY Available with: YELLOW BRAKE CALIPERS Not available with: BRAKE CALIPERS ANODIZED IN GREY, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, BLUE BRAKE CALIPERS, SILVER BRAKE CALIPERS;	-	1	Enquire
5	670215072	RH REAR CALIPER ASSEMBLY	670215072 RH REAR CALIPER ASSEMBLY Available with: BLACK BRAKE CALIPERS Not available with: BRAKE CALIPERS ANODIZED IN GREY, RED BRAKE CALIPERS, BLUE BRAKE CALIPERS, SILVER BRAKE CALIPERS, YELLOW BRAKE CALIPERS;	-	1	Enquire
5	670215073	RH REAR CALIPER ASSEMBLY	670215073 RH REAR CALIPER ASSEMBLY Available with: RED BRAKE CALIPERS Not available with: BRAKE CALIPERS ANODIZED IN GREY, BLACK BRAKE CALIPERS, BLUE BRAKE CALIPERS, SILVER BRAKE CALIPERS, YELLOW BRAKE CALIPERS;	-	1	Enquire
5	670175296	RH REAR CALIPER ASSEMBLY	670175296 RH REAR CALIPER ASSEMBLY Available with: BLUE BRAKE CALIPERS Not available with: BRAKE CALIPERS ANODIZED IN GREY, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, SILVER BRAKE CALIPERS, YELLOW BRAKE CALIPERS;	-	1	Enquire
5	19938331	EC conformity certificate	19938331 EC conformity certificate WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 7003461 - 99999999; Available with: BRAKE CALIPERS ANODIZED IN GREY, DUAL-CAST STEEL BRAKES ;	-	1	Enquire
5	670215076	LH REAR CALIPER ASSEMBLY	670215076 LH REAR CALIPER ASSEMBLY Available with: RED BRAKE CALIPERS Not available with: BRAKE CALIPERS ANODIZED IN GREY, BLACK BRAKE CALIPERS, BLUE BRAKE CALIPERS, SILVER BRAKE CALIPERS, YELLOW BRAKE CALIPERS;	-	1	Enquire
5	670215077	LH REAR CALIPER ASSEMBLY	670215077 LH REAR CALIPER ASSEMBLY Available with: YELLOW BRAKE CALIPERS Not available with: BRAKE CALIPERS ANODIZED IN GREY, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, BLUE BRAKE CALIPERS, SILVER BRAKE CALIPERS;	-	1	Enquire
5	19938330	EC conformity certificate	19938330 EC conformity certificate WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 7003461 - 99999999; Available with: SILVER BRAKE CALIPERS, DUAL-CAST STEEL BRAKES ;	-	1	Enquire
5	670175306	LH REAR CALIPER ASSEMBLY	670175306 LH REAR CALIPER ASSEMBLY Available with: BLUE BRAKE CALIPERS Not available with: BRAKE CALIPERS ANODIZED IN GREY, BLACK BRAKE CALIPERS, RED BRAKE CALIPERS, SILVER BRAKE CALIPERS, YELLOW BRAKE CALIPERS;	-	1	Enquire
5	670215075	LH REAR CALIPER ASSEMBLY	670215075 LH REAR CALIPER ASSEMBLY Available with: BLACK BRAKE CALIPERS Not available with: BRAKE CALIPERS ANODIZED IN GREY, RED BRAKE CALIPERS, BLUE BRAKE CALIPERS, SILVER BRAKE CALIPERS, YELLOW BRAKE CALIPERS;	-	1	Enquire
6	675001192	SCREW	675001192 SCREW	-	4	Enquire
7	670156282	FLEXIBLE PIPE TO REAR CALIPERS	670156282 FLEXIBLE PIPE TO REAR CALIPERS	-	2	Enquire
8	670212955	LH BRACKET	670212955 LH BRACKET	-	1	Enquire
8	670212954	RH BRACKET	670212954 RH BRACKET	-	1	Enquire
9	675001159	SCREW	675001159 SCREW	-	2	Enquire
10	675000276	SPRING PLATE	675000276 SPRING PLATE	-	2	Enquire
11	673012868	REAR PADS KIT	673012868 REAR PADS KIT Available with: DUAL-CAST STEEL BRAKES Not available with: CARBON CERAMIC BRAKES;	-	1	Enquire
12	673010935	RH BRACKET AND SCREW	673010935 RH BRACKET AND SCREW	-	1	Enquire
12	673010936	LH BRACKET AND SCREW	673010936 LH BRACKET AND SCREW	-	1	Enquire
14	673001646	BLEEDER SCREW AND PLUG	673001646 BLEEDER SCREW AND PLUG Available with: DUAL-CAST STEEL BRAKES Not available with: CARBON CERAMIC BRAKES;	-	2	Enquire
15	673010932	SPRING AND PINS KIT	673010932 SPRING AND PINS KIT	-	2	Enquire
16	670219436	RH REAR AIR CONVEYOR	670219436 RH REAR AIR CONVEYOR Available with: DUAL-CAST STEEL BRAKES Not available with: CARBON CERAMIC BRAKES; EU AU CN US CD UK JP ME JRH IN;	-	1	Enquire
16	670219437	LH REAR AIR CONVEYOR	670219437 LH REAR AIR CONVEYOR Available with: DUAL-CAST STEEL BRAKES Not available with: CARBON CERAMIC BRAKES; EU AU CN US CD UK JP ME JRH IN;	-	1	Enquire
