Sound Diffusion System

Maserati Levante Modena Automatic 3.0 BT V6 4WD 350HP

Illustration Number: 0870

(Available with: SOUND SYSTEM Not available with: HIGH PREMIUM SOUND SYSTEM, PREMIUM SOUND SYSTEM)
Find Your Part

Maserati Levante Modena Automatic 3.0 BT V6 4WD 350HP - SOUND DIFFUSION SYSTEM (08701)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
670155167 MID-WOOFER LOUDSPEAKER Enquire To Order
Photo Part No Description Price (each) Stock
670033156 TWEETER ADAPTER Enquire To Order
Photo Part No Description Price (each) Stock
675001953 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
670038095 GASKET Enquire To Order
Photo Part No Description Price (each) Stock
675000809 TWEETER Enquire To Order
View All
SOUND DIFFUSION SYSTEM of Maserati Maserati Levante Modena Automatic 3.0 BT V6 4WD 350HP Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 670155167
MID-WOOFER LOUDSPEAKER
Bespoke Assembly Number 6074862 - 99999999; Available with: SOUND SYSTEM ; 		- 4 Enquire
5 670033156
TWEETER ADAPTER
Available with: SOUND SYSTEM ; 		- 4 Enquire
6 675001953
SCREW 		- 12 Enquire
7 670038095
GASKET 		- 12 Enquire
10 675000809
TWEETER
Bespoke Assembly Number 6072547 - 99999999; Available with: SOUND SYSTEM ; 		- 4 Enquire
