TIMING of Maserati Maserati Levante Modena Automatic 3.0 BT V6 4WD 350HP

View All

Maserati Levante Modena Automatic 3.0 BT V6 4WD 350HP - TIMING (01242)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	299481	TRANSMISSION CHAIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	323476	LH FIXED SLIDING BLOCK	Enquire	To Order
	276589	LH FIXED SLIDING BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	276588	RH FIXED SLIDING BLOCK	Enquire	To Order
	323474	RH FIXED SLIDING BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	299779	SCREW M6 X 30	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	299883	SCREW M6 X 16	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	295221	LH MOBILE SLIDING BLOCK	Enquire	To Order
	323475	LH MOBILE SLIDING BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	216292	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	339329	HYDRAULIC TIGHTENER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	276584	RH MOBILE SLIDING BLOCK	Enquire	To Order
	323473	RH MOBILE SLIDING BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	276581	FIXED SLIDING BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	339327	RH HYDRAULIC TENSIONER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	276587	LH HYDRAULIC TENSIONER	Enquire	To Order
	295222	LH HYDRAULIC TENSIONER	Enquire	To Order
	339038	LH HYDRAULIC TENSIONER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	276590	TIMING CHAIN	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	299671	ENGINE SHAFT TOOTHED WHEEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	304376	SCREW M8 X 75	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	299501	TRANSMISSION TOOTHED WHEEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187742	ROLLER CAGE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	310102	DIAMOND WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	299140	SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	291771	SCREW M6 X 45	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14305821	SCREWM6X40	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	781822	FRONT COVER ASSEMBLY	Enquire	To Order
	321255	FRONT COVER ASSEMBLY	Enquire	To Order
	878658	FRONT COVER ASSEMBLY	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	300452	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	275339	GASKET, CRANK SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	326846	CPL. CROSSOVER	Enquire	To Order
	291773	CPL. CROSSOVER	Enquire	To Order
	291773	CPL. CROSSOVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673010776	GASKET KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW M6 X 25	Enquire	To Order
	291776	SCREWM6X25	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231624	SCREWM6X45	Enquire	To Order
	291771	SCREW M6 X 45	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	280912	GASKET	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
2	299481	TRANSMISSION CHAIN	299481 TRANSMISSION CHAIN	-	1	Enquire
3	323476	LH FIXED SLIDING BLOCK	323476 LH FIXED SLIDING BLOCK	-	1	Enquire
3	276589	LH FIXED SLIDING BLOCK	276589 LH FIXED SLIDING BLOCK Bespoke Engine Number 0 - 318012;	-	1	Enquire
4	276588	RH FIXED SLIDING BLOCK	276588 RH FIXED SLIDING BLOCK Bespoke Engine Number 0 - 318012;	-	1	Enquire
4	323474	RH FIXED SLIDING BLOCK	323474 RH FIXED SLIDING BLOCK	-	1	Enquire
5	299779	SCREW M6 X 30	299779 SCREW M6 X 30	-	9	Enquire
6	299883	SCREW M6 X 16	299883 SCREW M6 X 16	-	3	Enquire
7	295221	LH MOBILE SLIDING BLOCK	295221 LH MOBILE SLIDING BLOCK Bespoke Engine Number 0 - 318012;	-	1	Enquire
7	323475	LH MOBILE SLIDING BLOCK	323475 LH MOBILE SLIDING BLOCK	-	1	Enquire
8	216292	GASKET	216292 GASKET	-	1	Enquire
9	339329	HYDRAULIC TIGHTENER	339329 HYDRAULIC TIGHTENER Bespoke Assembly Number 6035538 - 99999999;	-	1	Enquire
10	276584	RH MOBILE SLIDING BLOCK	276584 RH MOBILE SLIDING BLOCK Bespoke Engine Number 0 - 318012;	-	1	Enquire
10	323473	RH MOBILE SLIDING BLOCK	323473 RH MOBILE SLIDING BLOCK	-	1	Enquire
11	276581	FIXED SLIDING BLOCK	276581 FIXED SLIDING BLOCK	-	1	Enquire
12	339327	RH HYDRAULIC TENSIONER	339327 RH HYDRAULIC TENSIONER Bespoke Assembly Number 6035538 - 99999999;	-	1	Enquire
13	276587	LH HYDRAULIC TENSIONER	276587 LH HYDRAULIC TENSIONER	-	1	Enquire
13	295222	LH HYDRAULIC TENSIONER	295222 LH HYDRAULIC TENSIONER Bespoke Engine Number 0 - 352061;	-	1	Enquire
13	339038	LH HYDRAULIC TENSIONER	339038 LH HYDRAULIC TENSIONER	-	1	Enquire
14	276590	TIMING CHAIN ARRIVING SOON	276590 TIMING CHAIN ARRIVING SOON	-	2	Enquire
15	299671	ENGINE SHAFT TOOTHED WHEEL	299671 ENGINE SHAFT TOOTHED WHEEL	-	1	Enquire
16	304376	SCREW M8 X 75	304376 SCREW M8 X 75	-	1	Enquire
17	299501	TRANSMISSION TOOTHED WHEEL	299501 TRANSMISSION TOOTHED WHEEL	-	1	Enquire
18	187742	ROLLER CAGE	187742 ROLLER CAGE	-	2	Enquire
19	310102	DIAMOND WASHER	310102 DIAMOND WASHER	-	1	Enquire
20	299140	SUPPORT	299140 SUPPORT	-	1	Enquire
24	291771	SCREW M6 X 45	291771 SCREW M6 X 45 Bespoke Assembly Number 6035538 - 99999999;	-	19	Enquire
25	14305821	SCREWM6X40	14305821 SCREWM6X40	-	1	Enquire
26	781822	FRONT COVER ASSEMBLY	781822 FRONT COVER ASSEMBLY Bespoke Engine Number 0 - 441893;	-	1	Enquire
26	321255	FRONT COVER ASSEMBLY	321255 FRONT COVER ASSEMBLY CROSSOVER IN REF.30 NOT INCLUDED, PLEASE ORDER SEPARATELY WITH PN 326846. FOR ENGINE SERIAL NUMBER < 441894, PLEASE ORDER ALSO PN 670001322; Bespoke Engine Number 441894 - 455322;	-	1	Enquire
26	878658	FRONT COVER ASSEMBLY	878658 FRONT COVER ASSEMBLY CROSSOVER IN REF.30 NOT INCLUDED, PLEASE ORDER SEPARATELY WITH PN 326846. FOR ENGINE SERIAL NUMBER < 441894, PLEASE ORDER ALSO PN 670001322; Bespoke Engine Number 455323 - 473146;	-	1	Enquire
26	910507	FRONT COVER ASSEMBLY	910507 FRONT COVER ASSEMBLY CROSSOVER IN REF.30 INCLUDED. FOR ENGINE SERIAL NUMBER INCLUDED BETWEEN 441894 AND 473146 RANGE, PLEASE ORDER ALSO PN 670031951;	-	1	Enquire
28	300452	STUD	300452 STUD Bespoke Assembly Number 6035538 - 99999999;	-	2	Enquire
29	275339	GASKET, CRANK SHAFT	275339 GASKET, CRANK SHAFT	-	1	Enquire
30	326846	CPL. CROSSOVER	326846 CPL. CROSSOVER PLASTIC - NOT INCLUDED WITH CPL TIMING COVER 321255 AND 878658, PLEASE ORDER SEPARATELY; Bespoke Engine Number 441894 - 473146;	-	1	Enquire
30	291773	CPL. CROSSOVER	291773 CPL. CROSSOVER ALUMINUM - INCLUDED WITH THE TIMING COVER; Bespoke Engine Number 0 - 441893;	-	1	Enquire
30	291773	CPL. CROSSOVER	291773 CPL. CROSSOVER ALUMINUM - INCLUDED WITH THE TIMING COVER. IF IN REPLACEMENT OF THE PLASTIC CROSSOVER ALSO ORDER THE SCREWS 32-33 AND THE GASKET 34; Bespoke Engine Number 441894 - 473146;	-	1	Enquire
31	673010776	GASKET KIT	673010776 GASKET KIT	-	1	Enquire
32	231620	SCREW M6 X 25	231620 SCREW M6 X 25 INCLUDED AND VALID ONLY WITH PN 326846 (PLASTIC CROSSOVER); Bespoke Engine Number 441894 - 473146;	-	4	Enquire
32	291776	SCREWM6X25	291776 SCREWM6X25 NOT INCLUDED AND VALID ONLY FOR THE CROSSOVER IN ALUMINUM P/N 291773;	-	4	Enquire
33	231624	SCREWM6X45	231624 SCREWM6X45 INCLUDED AND VALID ONLY WITH PN 326846 (PLASTIC CROSSOVER); Bespoke Engine Number 441894 - 473146;	-	7	Enquire
33	291771	SCREW M6 X 45	291771 SCREW M6 X 45 NOT INCLUDED AND VALID ONLY FOR THE CROSSOVER IN ALUMINUM P/N 291773;	-	7	Enquire
34	280912	GASKET	280912 GASKET ONLY FOR THE CROSSOVER IN ALUMINUM P/N 291773 - NOT INCLUDED, ORDER SEPARATELY;	-	1	Enquire
