REAR SUSPENSION of Maserati Maserati Levante Modena Automatic 3.0 BT V6 4WD 430HP

View All

Maserati Levante Modena Automatic 3.0 BT V6 4WD 430HP - REAR SUSPENSION (06201)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	670152673	RH REAR HUB HOLDER ASSEMBLY	Enquire	To Order
	670152652	LH REAR HUB HOLDER ASSEMBLY	Enquire	To Order
	670108077	LH REAR HUB HOLDER ASSEMBLY	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	670158898	REAR CAMBER ROD	Enquire	To Order
	670308370	REAR CAMBER ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670035563	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000584	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670035573	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670035584	SCREW	Enquire	To Order
	670035572	SPECIAL SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670106334	RH REAR SWINGING ARM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670106331	LH REAR SWINGING ARM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670035562	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000127	NUT M12	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670035570	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670002806	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670035569	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670038850	REAR STABILISER BAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	675000140	SCREWM10X95	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670038692	LH BALL TIE ROD	Enquire	To Order
	670038693	RH BALL TIE ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670002916	NUT M10	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	670035582	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	670152673	RH REAR HUB HOLDER ASSEMBLY	670152673 RH REAR HUB HOLDER ASSEMBLY WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6072512 - 99999999; Available with: PERFORMANCE BRAKE SYSTEM - FRONT 380 [mm], REAR 345 [mm] Not available with: STANDARD BRAKE SYSTEM - FRONT 345 [mm], REAR 330 [mm], MEDIUM DUAL CAST BRAKE SYSTEM - FRONT 380 [mm], REAR 330 [mm];	-	1	Enquire
1	670152652	LH REAR HUB HOLDER ASSEMBLY	670152652 LH REAR HUB HOLDER ASSEMBLY WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 6072512 - 99999999; Available with: PERFORMANCE BRAKE SYSTEM - FRONT 380 [mm], REAR 345 [mm] Not available with: STANDARD BRAKE SYSTEM - FRONT 345 [mm], REAR 330 [mm], MEDIUM DUAL CAST BRAKE SYSTEM - FRONT 380 [mm], REAR 330 [mm];	-	1	Enquire
1	670108077	LH REAR HUB HOLDER ASSEMBLY	670108077 LH REAR HUB HOLDER ASSEMBLY Not available with: PERFORMANCE BRAKE SYSTEM - FRONT 380 [mm], REAR 345 [mm];	-	1	Enquire
1	670108079	RH REAR HUB HOLDER ASSEMBLY	670108079 RH REAR HUB HOLDER ASSEMBLY Not available with: PERFORMANCE BRAKE SYSTEM - FRONT 380 [mm], REAR 345 [mm];	-	1	Enquire
2	670158898	REAR CAMBER ROD	670158898 REAR CAMBER ROD	-	2	Enquire
2	670308370	REAR CAMBER ROD	670308370 REAR CAMBER ROD	-	2	Enquire
5	670035563	SCREW	670035563 SCREW	-	2	Enquire
7	675000584	NUT	675000584 NUT	-	2	Enquire
8	670035573	NUT	670035573 NUT	-	2	Enquire
10	670035584	SCREW	670035584 SCREW Available with: PERFORMANCE BRAKE SYSTEM - FRONT 380 [mm], REAR 345 [mm] ;	-	2	Enquire
10	670035572	SPECIAL SCREW	670035572 SPECIAL SCREW Not available with: PERFORMANCE BRAKE SYSTEM - FRONT 380 [mm], REAR 345 [mm];	-	2	Enquire
11	670106334	RH REAR SWINGING ARM	670106334 RH REAR SWINGING ARM	-	1	Enquire
12	670106331	LH REAR SWINGING ARM	670106331 LH REAR SWINGING ARM	-	1	Enquire
13	670035562	SCREW	670035562 SCREW	-	1	Enquire
17	675000127	NUT M12	675000127 NUT M12	-	2	Enquire
18	670035570	NUT	670035570 NUT	-	2	Enquire
19	670002806	WASHER	670002806 WASHER	-	2	Enquire
20	670035569	SCREW	670035569 SCREW	-	2	Enquire
25	670038850	REAR STABILISER BAR	670038850 REAR STABILISER BAR	-	1	Enquire
28	675000140	SCREWM10X95	675000140 SCREWM10X95	-	4	Enquire
30	670038692	LH BALL TIE ROD	670038692 LH BALL TIE ROD	-	1	Enquire
30	670038693	RH BALL TIE ROD	670038693 RH BALL TIE ROD	-	1	Enquire
31	670002916	NUT M10	670002916 NUT M10	-	2	Enquire
32	670035582	SCREW	670035582 SCREW	-	2	Enquire
