SUNROOF of Maserati Maserati Grecale GT Automatic 2.0 T4 4WD 300HP MHEV

View All

Maserati Grecale GT Automatic 2.0 T4 4WD 300HP MHEV - SUNROOF (09711)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4LA615162	AIR DEFLECTOR FRONT RH BRAKE COO	Enquire	To Order
	523123567	DEFLECTOR - AIR - RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012080	RH MECHANISM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012081	LH MECHANISM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012082	GEAR MOTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012083	WIRING HARNESS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012085	PIPES MECHANISMS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012086	ROLLER PIPES	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012087	DEFLECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012088	FRONT GLASS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012089	KIT REAR GLASS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012093	KIT FRONT PAVILION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012091	SUNROOF SUNSHADE	Enquire	To Order
	673012090	SUNROOF SUNSHADE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012084	COVERING CENTRAL CROSS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012094	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012095	GASKETS KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012096	MECHANISMS COVER GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012100	CLIPS KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012101	RH KIT MOLDING GASKET	Enquire	To Order
	4ML071111	ACCESSORY FOR TRAILER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012102	LH KIT MOLDING GASKET	Enquire	To Order
	47B907070D	POWER ELECTRONICS INV. MPIL SERIE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012097	KIT GLASS FIXING SCREWS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012098	KIT ENGINE FIXING SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	673012099	KIT MECHANISM FIXING SCREWS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4LA615159	AIR DEFLECTOR FRONT LH BRAKE COO	Enquire	To Order
	670151196	REAR LH DOOR PANEL ASSEMBLY	Enquire	To Order
	670151199	REAR LH DOOR PANEL ASSEMBLY	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	670151204	REAR LH DOOR PANEL ASSEMBLY	Enquire	To Order
	670151206	REAR LH DOOR PANEL ASSEMBLY	Enquire	To Order
	F670125807	REAR LH DOOR PANEL ASSEMBLY	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	670174010	PLUG	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4LA615162	AIR DEFLECTOR FRONT RH BRAKE COO	4LA615162 AIR DEFLECTOR FRONT RH BRAKE COO Bespoke Assembly Number 0 - 2033021; EU AU CN UK JP ME JRH IN KO;	-	1	Enquire
1	523123567	DEFLECTOR - AIR - RADIATOR	523123567 DEFLECTOR - AIR - RADIATOR Bespoke Assembly Number 2033022 - 99999999; EU AU CN UK JP ME JRH IN KO N0 N8;	-	1	Enquire
4	673012080	RH MECHANISM	673012080 RH MECHANISM	-	1	Enquire
5	673012081	LH MECHANISM	673012081 LH MECHANISM	-	1	Enquire
6	673012082	GEAR MOTOR	673012082 GEAR MOTOR	-	2	Enquire
7	673012083	WIRING HARNESS	673012083 WIRING HARNESS	-	1	Enquire
8	673012085	PIPES MECHANISMS	673012085 PIPES MECHANISMS	-	1	Enquire
9	673012086	ROLLER PIPES	673012086 ROLLER PIPES	-	1	Enquire
10	673012087	DEFLECTOR	673012087 DEFLECTOR	-	1	Enquire
11	673012088	FRONT GLASS	673012088 FRONT GLASS	-	1	Enquire
12	673012089	KIT REAR GLASS	673012089 KIT REAR GLASS	-	1	Enquire
13	673012093	KIT FRONT PAVILION	673012093 KIT FRONT PAVILION	-	1	Enquire
14	673012091	SUNROOF SUNSHADE	673012091 SUNROOF SUNSHADE GREIGE;	-	1	Enquire
14	673012090	SUNROOF SUNSHADE	673012090 SUNROOF SUNSHADE BLACK;	-	1	Enquire
15	673012084	COVERING CENTRAL CROSS	673012084 COVERING CENTRAL CROSS	-	1	Enquire
16	673012094	GASKET	673012094 GASKET	-	1	Enquire
17	673012095	GASKETS KIT	673012095 GASKETS KIT	-	1	Enquire
18	673012096	MECHANISMS COVER GASKET	673012096 MECHANISMS COVER GASKET	-	1	Enquire
19	673012100	CLIPS KIT	673012100 CLIPS KIT CONTAINS 7 CLIPS;	-	2	Enquire
20	673012101	RH KIT MOLDING GASKET	673012101 RH KIT MOLDING GASKET Bespoke Assembly Number 0 - 2033021;	-	1	Enquire
20	4ML071111	ACCESSORY FOR TRAILER	4ML071111 ACCESSORY FOR TRAILER Bespoke Assembly Number 2033022 - 99999999;	-	1	Enquire
21	673012102	LH KIT MOLDING GASKET	673012102 LH KIT MOLDING GASKET Bespoke Assembly Number 0 - 2033021;	-	1	Enquire
21	47B907070D	POWER ELECTRONICS INV. MPIL SERIE	47B907070D POWER ELECTRONICS INV. MPIL SERIE Bespoke Assembly Number 2033022 - 99999999;	-	1	Enquire
22	673012097	KIT GLASS FIXING SCREWS	673012097 KIT GLASS FIXING SCREWS CONTAINS 6 SCREWS;	-	1	Enquire
23	673012098	KIT ENGINE FIXING SCREW	673012098 KIT ENGINE FIXING SCREW CONTAINS 4 SCREWS;	-	1	Enquire
24	673012099	KIT MECHANISM FIXING SCREWS	673012099 KIT MECHANISM FIXING SCREWS CONTAINS 12 SCREWS;	-	1	Enquire
25	4LA615159	AIR DEFLECTOR FRONT LH BRAKE COO	4LA615159 AIR DEFLECTOR FRONT LH BRAKE COO Bespoke Assembly Number 0 - 2033021; Available with: ROOF RAILS ;	-	1	Enquire
25	670151196	REAR LH DOOR PANEL ASSEMBLY	670151196 REAR LH DOOR PANEL ASSEMBLY WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 0 - 2033021; Not available with: ROOF RAILS;	-	1	Enquire
25	670151199	REAR LH DOOR PANEL ASSEMBLY	670151199 REAR LH DOOR PANEL ASSEMBLY Available with: ROOF RAILS ;	-	1	Enquire
25	670151202	REAR LH DOOR PANEL ASSEMBLY	670151202 REAR LH DOOR PANEL ASSEMBLY WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 2033022 - 99999999; Not available with: ROOF RAILS;	-	1	Enquire
26	670151204	REAR LH DOOR PANEL ASSEMBLY	670151204 REAR LH DOOR PANEL ASSEMBLY WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 0 - 2033021; Available with: ROOF RAILS ;	-	1	Enquire
26	670151206	REAR LH DOOR PANEL ASSEMBLY	670151206 REAR LH DOOR PANEL ASSEMBLY WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 0 - 2033021; Not available with: ROOF RAILS;	-	1	Enquire
26	F670125807	REAR LH DOOR PANEL ASSEMBLY	F670125807 REAR LH DOOR PANEL ASSEMBLY WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 2033022 - 99999999; Available with: ROOF RAILS ;	-	1	Enquire
26	F670264984	REAR LH DOOR PANEL ASSEMBLY	F670264984 REAR LH DOOR PANEL ASSEMBLY WARNING: in order to properly choose the spare part for a specific vehicle model, you must perform the configuration procedure once again and enter the "Assembly Number" or "VIN" Assembly Number 2033022 - 99999999; Not available with: ROOF RAILS;	-	1	Enquire
27	670174010	PLUG	670174010 PLUG Not available with: ROOF RAILS;	-	8	Enquire
