ADDITIONAL AIR SYSTEM (Available with: "GranSport MC Victory" Version) of Maserati Maserati GranSport Coupe (2005-2007)

View All

Maserati GranSport Coupe (2005-2007) - ADDITIONAL AIR SYSTEM (Available with: "GranSport MC Victory" Version)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	210189	VACUUM TANK	$99.69	To Order

Photo	Part No	Description	Price (each)	Stock
	208281	BRACKET	$24.18	To Order

Photo	Part No	Description	Price (each)	Stock
	14040614	NUT	$2.00	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	195066	VALVE AIR DELIVERY TUBE	$235.23	To Order
	195065	VALVE AIR DELIVERY TUBE	$415.81	To Order

Photo	Part No	Description	Price (each)	Stock
	171175	Secondary Air Valve	$197.00	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	186274	SECONDARY AIR VALVE PIPE	$157.07	To Order

Photo	Part No	Description	Price (each)	Stock
	186781	Gasket for Manifold	$6.18	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	$3.56	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	$1.57	To Order

Photo	Part No	Description	Price (each)	Stock
	231617	SCREW M6 X 18	$2.95	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	$1.57	To Order

Photo	Part No	Description	Price (each)	Stock
	155116	SLEEVE	$28.81	To Order

Photo	Part No	Description	Price (each)	Stock
	262111	SLEEVE FASTENING COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147121	L.H. RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	300100803	RUBBER HOSE	$100.76	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	257691	3-WAY UNION	$1.94	To Order

Photo	Part No	Description	Price (each)	Stock
	315769	On/Off Solenoid Valve	$77.32	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	14304124	SCREW TCEI M5 x 12	$2.00	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	181197	SECONDARY AIR PUMP	$740.32	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	184837	BRACKET	$27.20	To Order

Photo	Part No	Description	Price (each)	Stock
	16296924	SCREW	$2.52	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	190992	PIPE	$29.84	To Order

Photo	Part No	Description	Price (each)	Stock
	262111	SLEEVE FASTENING COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	$1.55	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	$2.44	To Order

Photo	Part No	Description	Price (each)	Stock
	162606	CLIP	$2.84	To Order

Photo	Part No	Description	Price (each)	Stock
	159740	CLIP	$1.27	To Order

Photo	Part No	Description	Price (each)	Stock
	388100423	RUBBER	$2.84	To Order

Photo	Part No	Description	Price (each)	Stock
	152630	THREADED UNION	$81.38	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	150595	NUT	$3.00	To Order

Photo	Part No	Description	Price (each)	Stock
	194436	STUD	$63.30	To Order

Photo	Part No	Description	Price (each)	Stock
	194437	STUD	$18.56	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	$2.44	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	$1.55	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	219456	VIBRATION-DAMPING MOUNT	$2.56	To Order

Photo	Part No	Description	Price (each)	Stock
	219457	SPACER	$27.04	To Order

Photo	Part No	Description	Price (each)	Stock
	14498801	Washer	$1.57	To Order

Photo	Part No	Description	Price (each)	Stock
	253896	NONRETURN VALVE	$41.33	To Order

Photo	Part No	Description	Price (each)	Stock
	257691	3-WAY UNION	$1.94	To Order

Photo	Part No	Description	Price (each)	Stock
	159541	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	211475	RUBBER HOSE	$4.38	To Order

Photo	Part No	Description	Price (each)	Stock
	118502	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	277185	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10418601	BRACKET WITH SHEATH	$2.28	To Order

Photo	Part No	Description	Price (each)	Stock
	14059214	Nut Flanged M6	$1.49	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	208359	RIGID PIPE	$63.95	To Order

Photo	Part No	Description	Price (each)	Stock
	215411	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	163092	RUBBER HOSE	$1.94	To Order

Photo	Part No	Description	Price (each)	Stock
	315769	On/Off Solenoid Valve	$77.32	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	13046011	NUT	$2.00	To Order

Photo	Part No	Description	Price (each)	Stock
	211068	SHIELD	$22.38	To Order

Photo	Part No	Description	Price (each)	Stock
	225102	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	257691	3-WAY UNION	$1.94	To Order

Photo	Part No	Description	Price (each)	Stock
	208461	R.H. RUBBER HOSE	$83.07	To Order

Photo	Part No	Description	Price (each)	Stock
	208460	L.H. RUBBER HOSE	$47.81	To Order

Photo	Part No	Description	Price (each)	Stock
	10441390	BRACKET WITH SHEATH	$2.00	To Order

Photo	Part No	Description	Price (each)	Stock
	208038	SOLENOID VALVE CABLE	$42.33	To Order
	208039	SOLENOID VALVE AND POTENTIOMETER LINKING CABLE	$55.93	To Order

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	210189	VACUUM TANK	210189 VACUUM TANK	$99.69	1
2	208281	BRACKET	208281 BRACKET	$24.18	1
3	14040614	NUT IN STOCK	14040614 NUT IN STOCK	$2.00	4
4	195066	VALVE AIR DELIVERY TUBE	195066 VALVE AIR DELIVERY TUBE Not for RHD	$235.23	1
4	195065	VALVE AIR DELIVERY TUBE	195065 VALVE AIR DELIVERY TUBE Valid for RHD	$415.81	1
5	171175	Secondary Air Valve IN STOCK	171175 Secondary Air Valve IN STOCK	$197.00 MSRP: ~~295.94~~ (33.4% off)	2
6	186274	SECONDARY AIR VALVE PIPE	186274 SECONDARY AIR VALVE PIPE	$157.07	2
7	186781	Gasket for Manifold IN STOCK	186781 Gasket for Manifold IN STOCK	$6.18	4
8	248334	SCREW M6 X 14MM IN STOCK	248334 SCREW M6 X 14MM IN STOCK	$3.56	4
9	127494	WASHER	127494 WASHER	$1.57	4
10	231617	SCREW M6 X 18 IN STOCK	231617 SCREW M6 X 18 IN STOCK	$2.95	4
11	127494	WASHER	127494 WASHER	$1.57	4
12	155116	SLEEVE	155116 SLEEVE	$28.81	2
13	262111	SLEEVE FASTENING COLLAR	262111 SLEEVE FASTENING COLLAR	-	4	Enquire
14	147121	L.H. RUBBER HOSE	147121 L.H. RUBBER HOSE	-	1	Enquire
15	300100803	RUBBER HOSE IN STOCK	300100803 RUBBER HOSE Supplied in meters- -(Minimum quantity 1m. or multiples) IN STOCK	$100.76	-
16	257691	3-WAY UNION	257691 3-WAY UNION	$1.94	1
17	315769	On/Off Solenoid Valve IN STOCK	315769 On/Off Solenoid Valve IN STOCK	$77.32	1
18	14304124	SCREW TCEI M5 x 12	14304124 SCREW TCEI M5 x 12	$2.00	2
19	12604178	WASHER	12604178 WASHER D.5.3-11X0.5	-	2	Enquire
20	181197	SECONDARY AIR PUMP IN STOCK	181197 SECONDARY AIR PUMP IN STOCK	$740.32	1
21	184837	BRACKET	184837 BRACKET	$27.20	1
22	16296924	SCREW IN STOCK	16296924 SCREW IN STOCK	$2.52	2
23	190992	PIPE	190992 PIPE	$29.84	1
24	262111	SLEEVE FASTENING COLLAR	262111 SLEEVE FASTENING COLLAR	-	2	Enquire
25	14039614	NUT IN STOCK	14039614 NUT IN STOCK	$1.55	3
26	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D. 6,40-12X 0,5	$2.44	3
27	162606	CLIP	162606 CLIP	$2.84	1
28	159740	CLIP	159740 CLIP	$1.27	1
29	388100423	RUBBER	388100423 RUBBER	$2.84	1
30	152630	THREADED UNION IN STOCK	152630 THREADED UNION IN STOCK	$81.38	2
31	150595	NUT	150595 NUT	$3.00	2
32	194436	STUD	194436 STUD	$63.30	1
33	194437	STUD	194437 STUD	$18.56	1
34	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D.6.4-12X2.4	$2.44	2
35	14039614	NUT IN STOCK	14039614 NUT IN STOCK	$1.55	2
36	219456	VIBRATION-DAMPING MOUNT	219456 VIBRATION-DAMPING MOUNT Valid after stock exhaustion of 315520375	$2.56	2
37	219457	SPACER	219457 SPACER	$27.04	2
38	14498801	Washer	14498801 Washer	$1.57	4
39	253896	NONRETURN VALVE	253896 NONRETURN VALVE	$41.33	1
40	257691	3-WAY UNION	257691 3-WAY UNION	$1.94	1
41	159541	RUBBER HOSE	159541 RUBBER HOSE	-	1	Enquire
42	211475	RUBBER HOSE	211475 RUBBER HOSE	$4.38	1
43	118502	RUBBER HOSE	118502 RUBBER HOSE	-	1	Enquire
44	277185	RUBBER HOSE	277185 RUBBER HOSE	-	1	Enquire
45	10418601	BRACKET WITH SHEATH	10418601 BRACKET WITH SHEATH	$2.28	1
46	14059214	Nut Flanged M6 IN STOCK	14059214 Nut Flanged M6 M6 IN STOCK	$1.49	1
47	208359	RIGID PIPE	208359 RIGID PIPE	$63.95	1
48	215411	CLIP	215411 CLIP	-	8	Enquire
49	163092	RUBBER HOSE	163092 RUBBER HOSE	$1.94	1
50	315769	On/Off Solenoid Valve IN STOCK	315769 On/Off Solenoid Valve IN STOCK	$77.32	1
51	13046011	NUT	13046011 NUT M5	$2.00	4
52	211068	SHIELD	211068 SHIELD	$22.38	1
53	225102	RUBBER HOSE	225102 RUBBER HOSE	-	1	Enquire
54	257691	3-WAY UNION	257691 3-WAY UNION	$1.94	1
55	208461	R.H. RUBBER HOSE	208461 R.H. RUBBER HOSE	$83.07	1
56	208460	L.H. RUBBER HOSE	208460 L.H. RUBBER HOSE	$47.81	1
57	10441390	BRACKET WITH SHEATH	10441390 BRACKET WITH SHEATH	$2.00	2
58	208038	SOLENOID VALVE CABLE	208038 SOLENOID VALVE CABLE Not for cars with opt. Xeno Headlights and Headligts Washer- -Valid for cars USA and CDN with opt. Xeno Headlights and Headligts Washer	$42.33	1
58	208039	SOLENOID VALVE AND POTENTIOMETER LINKING CABLE	208039 SOLENOID VALVE AND POTENTIOMETER LINKING CABLE Valid for cars with opt. Xeno Headlights and Headligts Washer- -Not for USA and CDN	$55.93	1
