LH CYLINDER HEAD (Available with: "GranSport MC Victory" Version) of Maserati Maserati GranSport Coupe (2005-2007)

View All

Maserati GranSport Coupe (2005-2007) - LH CYLINDER HEAD (Available with: "GranSport MC Victory" Version)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	218038	COMPLETE L.H. HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187816	LH HEAD CYLINDER COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	198928	LH Head Cover Gasket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	192390	SECONDARY AIR VALVE FIX. BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14304424	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14497878	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	185313	LH WIRING HARNESS COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	156834	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	156830	ALLEN SCREW M6 X 40	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187713	RETAINING CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	124342	Threaded Union	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14326050	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	180267	OIL NON RETURN VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10263360	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10261060	COPPER WASHER D.12- 16 X 1.5MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127635	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164400	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187706	Spark Plug Sleeve Gasket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13543424	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	191633	UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14326150	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134233	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	141563	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13541224	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13516624	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	186563	VARIATOR CONTROL SOLENOID VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231617	SCREW M6 X 18	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11087376	3-POINT CIRCLIP D.12	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	184681	OIL PRESSURE CHECK VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	241406	OIL FILTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248334	SCREW M6 X 14MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	219866	TIMING SENSOR	Enquire	To Order
	219349	TIMING SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187142	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14040711	NUT M8 FLANGED	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11193874	WASHERD.8.4-16X1.4	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187710	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187711	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12639724	WASHERD.6.15-11X1	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102725	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14305821	SCREWM6X40	Enquire	To Order
	231622	SCREWM6X35	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187963	PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	321187	CYLINDER HEAD NUT & WASHER KIT	Enquire	To Order
	321187	CYLINDER HEAD NUT & WASHER KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	151117	WASHER 11.25-22X2.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	185471	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10441290	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14305024	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157218	SCREWM6X25	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	218038	COMPLETE L.H. HEAD	218038 COMPLETE L.H. HEAD	-	1	Enquire
2	187816	LH HEAD CYLINDER COVER	187816 LH HEAD CYLINDER COVER	-	1	Enquire
3	198928	LH Head Cover Gasket	198928 LH Head Cover Gasket Supplied also in the cover gasket revision kit (cod. 980020005)	-	1	Enquire
4	192390	SECONDARY AIR VALVE FIX. BRACKET	192390 SECONDARY AIR VALVE FIX. BRACKET	-	1	Enquire
5	14304424	SCREW	14304424 SCREW	-	3	Enquire
6	14497878	WASHER	14497878 WASHER	-	3	Enquire
7	185313	LH WIRING HARNESS COVER	185313 LH WIRING HARNESS COVER	-	1	Enquire
8	156834	SCREW	156834 SCREW	-	8	Enquire
9	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D.6.4-12X2.4	-	16	Enquire
10	156830	ALLEN SCREW M6 X 40	156830 ALLEN SCREW M6 X 40	-	1	Enquire
11	187713	RETAINING CLIP	187713 RETAINING CLIP	-	2	Enquire
12	124342	Threaded Union	124342 Threaded Union	-	1	Enquire
13	14326050	THREADED PLUG	14326050 THREADED PLUG	-	6	Enquire
14	180267	OIL NON RETURN VALVE	180267 OIL NON RETURN VALVE	-	1	Enquire
15	10263360	GASKET	10263360 GASKET	-	1	Enquire
16	10261060	COPPER WASHER D.12- 16 X 1.5MM	10261060 COPPER WASHER D.12- 16 X 1.5MM	-	1	Enquire
17	127635	THREADED PLUG	127635 THREADED PLUG	-	4	Enquire
18	164400	THREADED PLUG	164400 THREADED PLUG	-	1	Enquire
19	187706	Spark Plug Sleeve Gasket	187706 Spark Plug Sleeve Gasket Supplied also in the cover gasket revision kit (cod. 980020005)	-	4	Enquire
20	13543424	STUD	13543424 STUD	-	8	Enquire
21	191633	UNION	191633 UNION	-	1	Enquire
22	14326150	THREADED PLUG	14326150 THREADED PLUG	-	1	Enquire
23	134233	GASKET	134233 GASKET Supplied also in the cover gasket revision kit (cod. 980020005)	-	1	Enquire
24	141563	THREADED PLUG	141563 THREADED PLUG	-	6	Enquire
25	13541224	STUD	13541224 STUD	-	8	Enquire
26	13516624	STUD	13516624 STUD	-	2	Enquire
27	186563	VARIATOR CONTROL SOLENOID VALVE	186563 VARIATOR CONTROL SOLENOID VALVE	-	1	Enquire
28	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D.6.4-12X2.4	-	1	Enquire
29	231617	SCREW M6 X 18	231617 SCREW M6 X 18	-	1	Enquire
30	11087376	3-POINT CIRCLIP D.12	11087376 3-POINT CIRCLIP D.12	-	1	Enquire
31	184681	OIL PRESSURE CHECK VALVE	184681 OIL PRESSURE CHECK VALVE	-	1	Enquire
32	241406	OIL FILTER	241406 OIL FILTER Supplied also in the cover gasket revision kit (cod. 980020005)	-	1	Enquire
33	248334	SCREW M6 X 14MM	248334 SCREW M6 X 14MM	-	1	Enquire
34	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D.6.4-12X2.4	-	1	Enquire
35	219866	TIMING SENSOR	219866 TIMING SENSOR Valid after stock exhaustion of 177673	-	1	Enquire
35	219349	TIMING SENSOR	219349 TIMING SENSOR	-	1	Enquire
36	187142	BRACKET	187142 BRACKET	-	1	Enquire
37	14040711	NUT M8 FLANGED	14040711 NUT M8 FLANGED	-	2	Enquire
38	11193874	WASHERD.8.4-16X1.4	11193874 WASHERD.8.4-16X1.4 D.8.4-16X1.4	-	2	Enquire
39	187710	STUD	187710 STUD	-	1	Enquire
40	187711	STUD	187711 STUD	-	1	Enquire
41	14039614	NUT	14039614 NUT	-	2	Enquire
42	12639724	WASHERD.6.15-11X1	12639724 WASHERD.6.15-11X1 D.6.15-11X1	-	2	Enquire
43	102725	CENTERING DOWEL	102725 CENTERING DOWEL	-	22	Enquire
44	14305821	SCREWM6X40	14305821 SCREWM6X40 M6X40 M 6X40	-	4	Enquire
44	231622	SCREWM6X35	231622 SCREWM6X35 M 6X35	-	18	Enquire
45	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2 D.6.4-12X2.4	-	22	Enquire
46	187963	PLUG	187963 PLUG	-	1	Enquire
47	321187	CYLINDER HEAD NUT & WASHER KIT	321187 CYLINDER HEAD NUT & WASHER KIT M11	-	10	Enquire
47	321187	CYLINDER HEAD NUT & WASHER KIT	321187 CYLINDER HEAD NUT & WASHER KIT	-	10	Enquire
48	151117	WASHER 11.25-22X2.5	151117 WASHER 11.25-22X2.5 D.11.25-22X2.5	-	10	Enquire
49	185471	BRACKET	185471 BRACKET	-	1	Enquire
50	10441290	BRACKET WITH SHEATH	10441290 BRACKET WITH SHEATH	-	1	Enquire
51	14305024	SCREW	14305024 SCREW	-	1	Enquire
52	10519424	WASHER	10519424 WASHER	-	1	Enquire
53	157218	SCREWM6X25	157218 SCREWM6X25 M6X25	-	7	Enquire
