IGNITION SYSTEM: SENSORS of Maserati Maserati 3200 GT / Assetto Corsa

View All

Maserati 3200 GT / Assetto Corsa - IGNITION SYSTEM: SENSORS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	585089700	KNOCK SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	585066200	CAMSHAFT SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	585069401	CRANKSHAFT SENSOR	Enquire	To Order
	585069401	CRANKSHAFT SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	585061800	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	585061500	SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	571079600	PRESSURE SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	300100803	RUBBER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	97218	PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	585410703	UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187713	RETAINING CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	585000300	WIRE INLET RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	328751332	CURRUGATED PIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604178	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14304121	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231617	SCREW M6 X 18	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14305821	SCREWM6X40	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12604470	RETAINING WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16043436	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	262109	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	383210103	BRACKET	Enquire	To Order
	383200103	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	479001500	THREADED ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14498801	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14054577	NUT	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	585089700	KNOCK SENSOR	585089700 KNOCK SENSOR	-	2	Enquire
2	585066200	CAMSHAFT SENSOR	585066200 CAMSHAFT SENSOR	-	1	Enquire
3	585069401	CRANKSHAFT SENSOR	585069401 CRANKSHAFT SENSOR Valid from Ass.Nr.4286-	-	1	Enquire
3	585069401	CRANKSHAFT SENSOR	585069401 CRANKSHAFT SENSOR Valid till Ass.Nr.4285-	-	1	Enquire
4	585061800	SPACER	585061800 SPACER	-	2	Enquire
5	585061500	SUPPORT	585061500 SUPPORT	-	1	Enquire
6	571079600	PRESSURE SENSOR	571079600 PRESSURE SENSOR	-	2	Enquire
7	14039614	NUT	14039614 NUT	-	2	Enquire
8	300100803	RUBBER HOSE	300100803 RUBBER HOSE Section in meters: order minimum amount of 1 m or multiples	-	-	Enquire
9	97218	PIPE	97218 PIPE Section in meters: order minimum amount of 1 m or multiples	-	-	Enquire
10	585410703	UNION	585410703 UNION	-	2	Enquire
11	187713	RETAINING CLIP	187713 RETAINING CLIP	-	2	Enquire
12	585000300	WIRE INLET RING	585000300 WIRE INLET RING	-	1	Enquire
13	328751332	CURRUGATED PIP	328751332 CURRUGATED PIP Section in meters: order minimum amount of 1 m or multiples	-	-	Enquire
14	12604178	WASHER	12604178 WASHER	-	2	Enquire
15	14304121	SCREW	14304121 SCREW	-	2	Enquire
16	10519424	WASHER	10519424 WASHER	-	3	Enquire
17	231617	SCREW M6 X 18	231617 SCREW M6 X 18	-	3	Enquire
18	14305821	SCREWM6X40	14305821 SCREWM6X40	-	1	Enquire
19	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	2	Enquire
20	12604470	RETAINING WASHER	12604470 RETAINING WASHER	-	2	Enquire
21	16043436	SCREW	16043436 SCREW	-	2	Enquire
22	10519424	WASHER	10519424 WASHER	-	3	Enquire
23	262109	COLLAR	262109 COLLAR	-	4	Enquire
24	383210103	BRACKET	383210103 BRACKET Only rh drive	-	1	Enquire
24	383200103	BRACKET	383200103 BRACKET Only Ih drive	-	1	Enquire
25	479001500	THREADED ROD	479001500 THREADED ROD	-	2	Enquire
26	14498801	Washer	14498801 Washer	-	1	Enquire
27	14054577	NUT	14054577 NUT	-	5	Enquire
