12V

Lamborghini Revuelto Coupe

Illustration Number: 915.01.00

Find Your Part

Lamborghini Revuelto Coupe - 12V (915.01.00)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
4P0915089 AGM BATTERIE Enquire To Order
95C915105JY LITHIUM-BATTERY Enquire To Order
95C915105GY LITHIUM BATTERY 74X MY25 + KD0 Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
47A803123E CLAMPING STRIP Enquire To Order
47C803123C CLAMPING STRIP Enquire To Order
Photo Part No Description Price (each) Stock
4G0915531 CORRUGATED PIPE Enquire To Order
47B915505 HOSE TUBO DEGAS Enquire To Order
Photo Part No Description Price (each) Stock
9J1915137B TERMINAL CLAMP PLUS Enquire To Order
Photo Part No Description Price (each) Stock
47A803123A CLAMPING STRIP Enquire To Order
Photo Part No Description Price (each) Stock
1EA915181C BATTERY MANAGEMENTDIAG-ADR: 071 Enquire To Order
8S0915181D BATTERIE MANAGEMENT Enquire To Order
9Y0971235 EARTH CABLE FOR BATTERY Enquire To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
95978929 BOX MESSA IN SICUREZZA INTERFA Enquire To Order
Photo Part No Description Price (each) Stock
9J1937588 COVER Enquire To Order
Photo Part No Description Price (each) Stock
N01508210 HEXAGON COLLAR NUT Enquire To Order
Photo Part No Description Price (each) Stock
N10748001 HEXAGON SOCKET HEAD COLLARED BOLT, THREAD FORMING Enquire To Order
Photo Part No Description Price (each) Stock
4H0915143 GROMMET Enquire To Order
Photo Part No Description Price (each) Stock
WHT003401 WELD STUDS WITH CAP NUTS Enquire To Order
Photo Part No Description Price (each) Stock
9J1805769 JOURNAL FREMDSTARTPUNKT Enquire To Order
View All
12V of Lamborghini Lamborghini Revuelto Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 4P0915089
AGM BATTERIE
PB 		- 1 Enquire
1 95C915105JY
LITHIUM-BATTERY
H3-40AH 		- 1 Enquire
1 95C915105GY
LITHIUM BATTERY 74X MY25 + KD0
40 AH 		- 1 Enquire
1 915089BG
BATTERY, FILLED AND CHARGED
PB 		- 1 Enquire
2 47A803123E
CLAMPING STRIP 		- 1 Enquire
2 47C803123C
CLAMPING STRIP 		- 1 Enquire
3 4G0915531
CORRUGATED PIPE 		- 1 Enquire
3 47B915505
HOSE TUBO DEGAS 		- 1 Enquire
4 9J1915137B
TERMINAL CLAMP PLUS 		- 1 Enquire
5 47A803123A
CLAMPING STRIP 		- 1 Enquire
6 1EA915181C
BATTERY MANAGEMENTDIAG-ADR: 071 		- 1 Enquire
6 8S0915181D
BATTERIE MANAGEMENT 		- 1 Enquire
6 9Y0971235
EARTH CABLE FOR BATTERY 		- 1 Enquire
6 95978930
ANCORAGGIO PER SOLLEVAMENTO VE 		- 1 Enquire
7 95978929
BOX MESSA IN SICUREZZA INTERFA 		- 1 Enquire
8 9J1937588
COVER 		- 1 Enquire
9 N01508210
HEXAGON COLLAR NUT
M6 		- 1 Enquire
10 N10748001
HEXAGON SOCKET HEAD COLLARED BOLT, THREAD FORMING
6X16 		- 1 Enquire
11 4H0915143
GROMMET
M8 		- 1 Enquire
12 WHT003401
WELD STUDS WITH CAP NUTS
M8 		- 1 Enquire
13 9J1805769
JOURNAL FREMDSTARTPUNKT 		- 1 Enquire
