EXTERNAL SIDE MEMBER FOR WHEEL HOUSING of Lamborghini Lamborghini Revuelto Coupe

View All

Lamborghini Revuelto Coupe - EXTERNAL SIDE MEMBER FOR WHEEL HOUSING (853.01.00)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	47B863045GRU	SIDE MEMBER TRIM	Enquire	To Order
	47B863046GRU	SIDE MEMBER TRIM	Enquire	To Order
	47B863045BGRU	SIDE MEMBER TRIM	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	47B8630973FZ	COVER	Enquire	To Order
	47B863097AY9B	COVER	Enquire	To Order
	47B863097B	COVER	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	47B863233	BRACKET	Enquire	To Order
	47B863234	BRACKET	Enquire	To Order
	47B863233A	BRACKET	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	47B863345	BRACKET	Enquire	To Order
	47B863346	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90342503	SPEED NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	1K0867388	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90475903	SPEED NUT M5 X 13.6 X 11.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10442204	HEXAGON SOCKET OVAL HEAD BOLT (COMBI)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91188301	HEXAGON SOCKET HEAD BOLT M6 X 20	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91042302	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91180901	FLAT HEAD MULTI-POINT SOCKET BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B854499	NAMEPLATE	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	47B863045GRU	SIDE MEMBER TRIM	47B863045GRU SIDE MEMBER TRIM LEFT-PRIMED	-	1	Enquire
1	47B863046GRU	SIDE MEMBER TRIM	47B863046GRU SIDE MEMBER TRIM RIGHT-PRIMED	-	1	Enquire
1	47B863045BGRU	SIDE MEMBER TRIM	47B863045BGRU SIDE MEMBER TRIM PRIMED	-	1	Enquire
1	47B863046BGRU	SIDE MEMBER TRIM	47B863046BGRU SIDE MEMBER TRIM PRIMED	-	1	Enquire
2	47B8630973FZ	COVER	47B8630973FZ COVER LEFT - MATT BLACK-MATT BLACK	-	1	Enquire
2	47B863097AY9B	COVER	47B863097AY9B COVER LEFT - SHINY BLACK-BRILLIANT BLACK	-	1	Enquire
2	47B863097B	COVER	47B863097B COVER CARBON LOOK MATT-LEFT	-	1	Enquire
2	47B863097C	COVER	47B863097C COVER CARBON LOOK SHINY-LEFT	-	1	Enquire
2	47B8630983FZ	COVER	47B8630983FZ COVER RIGHT - MATT BLACK-MATT BLACK	-	1	Enquire
2	47B863098AY9B	COVER	47B863098AY9B COVER RIGHT - SHINY BLACK-BRILLIANT BLACK	-	1	Enquire
2	47B863098B	COVER	47B863098B COVER CARBON LOOK MATT-RIGHT	-	1	Enquire
2	47B863098C	COVER	47B863098C COVER CARBON LOOK SHINY-RIGHT	-	1	Enquire
3	47B863233	BRACKET	47B863233 BRACKET LEFT	-	1	Enquire
3	47B863234	BRACKET	47B863234 BRACKET RIGHT	-	1	Enquire
3	47B863233A	BRACKET	47B863233A BRACKET LEFT	-	1	Enquire
3	47B863234A	BRACKET	47B863234A BRACKET RIGHT	-	1	Enquire
4	47B863345	BRACKET	47B863345 BRACKET LEFT	-	1	Enquire
4	47B863346	BRACKET	47B863346 BRACKET RIGHT	-	1	Enquire
5	N90342503	SPEED NUT	N90342503 SPEED NUT M6X19,5X18	-	1	Enquire
6	1K0867388	CLIP	1K0867388 CLIP	-	1	Enquire
7	N90475903	SPEED NUT M5 X 13.6 X 11.5	N90475903 SPEED NUT M5 X 13.6 X 11.5 M5X13,6X11,5	-	1	Enquire
8	N10442204	HEXAGON SOCKET OVAL HEAD BOLT (COMBI)	N10442204 HEXAGON SOCKET OVAL HEAD BOLT (COMBI) M6X40	-	1	Enquire
9	N91188301	HEXAGON SOCKET HEAD BOLT M6 X 20	N91188301 HEXAGON SOCKET HEAD BOLT M6 X 20 M6X20	-	1	Enquire
10	N91042302	OVAL HEXAGON SOCKET HEAD BOLT	N91042302 OVAL HEXAGON SOCKET HEAD BOLT M6X16	-	1	Enquire
11	N91180901	FLAT HEAD MULTI-POINT SOCKET BOLT	N91180901 FLAT HEAD MULTI-POINT SOCKET BOLT M5X20	-	1	Enquire
12	47B854499	NAMEPLATE	47B854499 NAMEPLATE "REVUELTO"	-	1	Enquire
