Intake Box For Electronic- Ally Controlled A/C System

Lamborghini Revuelto Coupe

Illustration Number: 820.01.00

Find Your Part

Lamborghini Revuelto Coupe - INTAKE BOX FOR ELECTRONIC- ALLY CONTROLLED A/C SYSTEM (820.01.00)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
47A816005 APPARECCHIO CLIMA. Enquire To Order
47C816005 APPARECCHIO CLIMA. Enquire To Order
Photo Part No Description Price (each) Stock
4S0819422 COVER Enquire To Order
Photo Part No Description Price (each) Stock
4M1820021C FAN MOTOR WITH WHEEL Enquire To Order
4M2820021C FAN MOTOR WITH WHEEL Enquire To Order
Photo Part No Description Price (each) Stock
47A819229 PLASTIC FOAM Enquire To Order
47C819229 PLASTIC FOAM Enquire To Order
Photo Part No Description Price (each) Stock
47A820153A INTAKE DUCT Enquire To Order
47C820153B INTAKE DUCT Enquire To Order
Photo Part No Description Price (each) Stock
4M0820511A SERVOMOTOR Enquire To Order
Photo Part No Description Price (each) Stock
4S0820061 SEAL Enquire To Order
Photo Part No Description Price (each) Stock
4S0820102A EVAPORATOR Enquire To Order
Photo Part No Description Price (each) Stock
47A820024 EVAPORATOR HOUSING Enquire To Order
47C820024 EVAPORATOR HOUSING Enquire To Order
Photo Part No Description Price (each) Stock
47B816105 EVAPORATOR Enquire To Order
Photo Part No Description Price (each) Stock
4S0898333 1 SET OF LEVERS Enquire To Order
Photo Part No Description Price (each) Stock
1KD907543A TEMPERATURE SENSOR Enquire To Order
Photo Part No Description Price (each) Stock
4S0819422A COVER Enquire To Order
Photo Part No Description Price (each) Stock
4S0898102 REPAIR SET Enquire To Order
Photo Part No Description Price (each) Stock
47A898037 REPAIR KIT Enquire To Order
47C898037 REPAIR KIT Enquire To Order
Photo Part No Description Price (each) Stock
4S0819031 HEAT EXCHANGER Enquire To Order
Photo Part No Description Price (each) Stock
47A971566 HARNESS FOR ELECTRONICALLY Enquire To Order
47C971566 HARNESS FOR ELECTRONICALLY Enquire To Order
Photo Part No Description Price (each) Stock
47B820356 AIR DISTRIBUTION HOUSING Enquire To Order
Photo Part No Description Price (each) Stock
47B819331 DEMISTER Enquire To Order
Photo Part No Description Price (each) Stock
47B816679 EXPANSION VALVE Enquire To Order
Photo Part No Description Price (each) Stock
4S0819439 FILTER INSERT WITH ODOUR AND HARMFUL SUBSTANCE FILTERING Enquire To Order
Photo Part No Description Price (each) Stock
47B820738 TUBO RIGID.LIQ.REF Enquire To Order
47B820739 WATER DRAIN PIPE SX Enquire To Order
Photo Part No Description Price (each) Stock
N90282501 SPEED NUT Enquire To Order
Photo Part No Description Price (each) Stock
N91136801 HEXAGON SOCKET HEAD PANEL BOLT Enquire To Order
Photo Part No Description Price (each) Stock
N90817002 HEXAGON SOCKET HEAD PANEL BOLT Enquire To Order
Photo Part No Description Price (each) Stock
4S0898919A SMALL PARTS KIT Enquire To Order
View All
INTAKE BOX FOR ELECTRONIC- ALLY CONTROLLED A/C SYSTEM of Lamborghini Lamborghini Revuelto Coupe Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 47A816005
APPARECCHIO CLIMA. 		- 1 Enquire
1 47C816005
APPARECCHIO CLIMA. 		- 1 Enquire
2 4S0819422
COVER 		- 1 Enquire
3 4M1820021C
FAN MOTOR WITH WHEEL 		- 1 Enquire
3 4M2820021C
FAN MOTOR WITH WHEEL 		- 1 Enquire
4 47A819229
PLASTIC FOAM 		- 1 Enquire
4 47C819229
PLASTIC FOAM 		- 1 Enquire
5 47A820153A
INTAKE DUCT 		- 1 Enquire
5 47C820153B
INTAKE DUCT 		- 1 Enquire
6 4M0820511A
SERVOMOTOR 		- 1 Enquire
7 4S0820061
SEAL 		- 1 Enquire
8 4S0820102A
EVAPORATOR 		- 1 Enquire
9 47A820024
EVAPORATOR HOUSING 		- 1 Enquire
9 47C820024
EVAPORATOR HOUSING 		- 1 Enquire
10 47B816105
EVAPORATOR 		- 1 Enquire
11 4S0898333
1 SET OF LEVERS 		- 1 Enquire
12 1KD907543A
TEMPERATURE SENSOR 		- 1 Enquire
13 4S0819422A
COVER 		- 1 Enquire
14 4S0898102
REPAIR SET 		- 1 Enquire
15 47A898037
REPAIR KIT 		- 1 Enquire
15 47C898037
REPAIR KIT 		- 1 Enquire
16 4S0819031
HEAT EXCHANGER 		- 1 Enquire
17 47A971566
HARNESS FOR ELECTRONICALLY 		- 1 Enquire
17 47C971566
HARNESS FOR ELECTRONICALLY 		- 1 Enquire
18 47B820356
AIR DISTRIBUTION HOUSING 		- 1 Enquire
19 47B819331
DEMISTER 		- 1 Enquire
20 47B816679
EXPANSION VALVE 		- 1 Enquire
21 47B898253
FIXING SET 		- 1 Enquire
22 4S0819439
FILTER INSERT WITH ODOUR AND HARMFUL SUBSTANCE FILTERING 		- 1 Enquire
23 47B820738
TUBO RIGID.LIQ.REF
RIGHT 		- 1 Enquire
23 47B820739
WATER DRAIN PIPE SX
LEFT 		- 1 Enquire
24 N90282501
SPEED NUT
M4X13X11,5 		- 1 Enquire
25 N91136801
HEXAGON SOCKET HEAD PANEL BOLT
4,2X11 		- 1 Enquire
26 N90817002
HEXAGON SOCKET HEAD PANEL BOLT
M6X17 		- 1 Enquire
27 4S0898919A
SMALL PARTS KIT 		- 1 Enquire
