(A/C COMPRESSOR > A/C CONDENSER) of Lamborghini Lamborghini Revuelto Coupe

View All

Lamborghini Revuelto Coupe - (A/C COMPRESSOR > A/C CONDENSER) (260.02.00)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	47B820891B	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B820495B	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	80A816797F	AIR CONDITIONING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B820892A	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B820195F	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B816726B	AC_DISCHARGE_LINE_EKK-RH_CONDENSER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B816421	CONDENSER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B816580A	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B816579A	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B816750A	REFRIGERANT LINE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	47B816573B	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10714501	SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4KE820067F	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4KE317867F	BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91032702	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4KE820879C	SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4KE121277A	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91097301	HEXAGON SOCKET FLAT HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4KE820879B	SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90780901	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10347204	HEXAGON SOCKET HEAD BOLT, SELF-LOCKING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10414402	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91042303	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10714801	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91195701	SPEED NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N0206245	RETAINING CLAMP D1-22X15	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4E0260749B	SEAL RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4E0260749A	SEAL RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0959603E	PRESSURE SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0261185	SEAL RING	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	47B820891B	BRACKET	47B820891B BRACKET	-	1	Enquire
2	47B820495B	BRACKET	47B820495B BRACKET ORDER ALSO 47B820195F	-	1	Enquire
3	80A816797F	AIR CONDITIONING	80A816797F AIR CONDITIONING	-	1	Enquire
4	47B820892A	BRACKET	47B820892A BRACKET	-	1	Enquire
5	47B820195F	BRACKET	47B820195F BRACKET ORDER ALSO 47B820495B	-	1	Enquire
6	47B816726B	AC_DISCHARGE_LINE_EKK-RH_CONDENSER	47B816726B AC_DISCHARGE_LINE_EKK-RH_CONDENSER	-	1	Enquire
7	47B816421	CONDENSER	47B816421 CONDENSER	-	1	Enquire
8	47B816580A	BRACKET	47B816580A BRACKET	-	1	Enquire
9	47B816579A	BRACKET	47B816579A BRACKET	-	1	Enquire
10	47B816750A	REFRIGERANT LINE	47B816750A REFRIGERANT LINE	-	1	Enquire
11	47B816573B	BRACKET	47B816573B BRACKET	-	1	Enquire
12	N10714501	SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD	N10714501 SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD M8X90X80	-	1	Enquire
13	4KE820067F	BUSH	4KE820067F BUSH	-	1	Enquire
14	4KE317867F	BEARING	4KE317867F BEARING	-	1	Enquire
15	N91032702	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD	N91032702 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD M6X20	-	1	Enquire
16	4KE820879C	SPRING	4KE820879C SPRING	-	1	Enquire
17	4KE121277A	SPACER	4KE121277A SPACER	-	1	Enquire
18	N91097301	HEXAGON SOCKET FLAT HEAD BOLT	N91097301 HEXAGON SOCKET FLAT HEAD BOLT M6X45	-	1	Enquire
19	4KE820879B	SPRING	4KE820879B SPRING	-	1	Enquire
20	N90780901	OVAL HEXAGON SOCKET HEAD BOLT	N90780901 OVAL HEXAGON SOCKET HEAD BOLT M6X16	-	1	Enquire
21	N10347204	HEXAGON SOCKET HEAD BOLT, SELF-LOCKING	N10347204 HEXAGON SOCKET HEAD BOLT, SELF-LOCKING M6X25	-	1	Enquire
22	N10414402	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	N10414402 SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD M8X28	-	1	Enquire
23	N91042303	OVAL HEXAGON SOCKET HEAD BOLT	N91042303 OVAL HEXAGON SOCKET HEAD BOLT M6X16	-	1	Enquire
24	N10714801	OVAL HEXAGON SOCKET HEAD BOLT	N10714801 OVAL HEXAGON SOCKET HEAD BOLT M6X18	-	1	Enquire
25	N91195701	SPEED NUT	N91195701 SPEED NUT	-	1	Enquire
26	N0206245	RETAINING CLAMP D1-22X15	N0206245 RETAINING CLAMP D1-22X15	-	1	Enquire
27	4E0260749B	SEAL RING	4E0260749B SEAL RING 13,7X2,5	-	1	Enquire
28	4E0260749A	SEAL RING	4E0260749A SEAL RING 11X2,5	-	1	Enquire
29	4M0959603E	PRESSURE SENSOR	4M0959603E PRESSURE SENSOR INCLUDED IN REF.6	-	1	Enquire
30	4M0261185	SEAL RING	4M0261185 SEAL RING INCLUDED IN REF.6-8X1,5	-	1	Enquire

(EXPANSION VALVE > DRIER) (260.01.00)

(A/C COMPRESSOR > A/C CONDENSER) (260.02.00)
