Fuel System 2

Lamborghini Murcielago Roadster

Find Your Part

Lamborghini Murcielago Roadster - Fuel System 2

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Fuel System 2 of Lamborghini Lamborghini Murcielago Roadster Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 410201299
GASKET 		- 1 Enquire
002 410201643
PROTECTION 		- 1 Enquire
003 410201644
PROTECTION 		- 1 Enquire
004 8200808
NUT 		- 4 Enquire
005 410201652
TIE ROD 		- 1 Enquire
006 410201639
CLAMP 		- 1 Enquire
007 410201783
GASKET 		- 1 Enquire
008 410201639
CLAMP 		- 1 Enquire
009 8820304
SPLIT PIN 		- 2 Enquire
010 8580604
CLIP 		- 2 Enquire
011 6233763
JOURNAL 		- 1 Enquire
012 8931203
PLUG 		- 1 Enquire
013 WHT003362
WASHER 		- 1 Enquire
014 410201300
GASKET 		- 1 Enquire
015 410201075E
FUEL TANK (COMPLETE) 		- 1 Enquire
016 400201365C
PROTECTION 		- 1 Enquire
017 417201537
PROTECTION 		- 1 Enquire
