Lamborghini Gallardo LP560 Spyder - Electrical System 4

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Electrical System 4 of Lamborghini Lamborghini Gallardo LP560 Spyder Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 407971140F
CENTRAL WIRING HARNESS (RNS / CD CHANGER) 		- 1 Enquire
003 400971036B
DOOR WIRING HARNESS (PASSENGER SIDE) 		- 1 Enquire
003 402971035B
DOOR WIRING HARNESS (DRIVER SIDE) 		- 1 Enquire
008 400971194B
WIRING HARNESS 		- 1 Enquire
011 407971551G
WIRING HARNESS INFOTAINMENT (RNS / CD CHANGER / I-POD / USB / REAR VIEW CAMERA) 		- 1 Enquire
011 407971551H
WIRING HARNESS INFOTAINMENT (RNS / CD CHANGER / I-POD / USB / REAR VIEW CAMERA / BLUETOOTH) 		- 1 Enquire
011 407971551J
WIRING HARNESS INFOTAINMENT (RNS / CD CHANGER / I-POD / USB / BLUETOOTH) 		- 1 Enquire
011 407971551F
WIRING HARNESS INFOTAINMENT (RNS / CD CHANGER / I-POD / USB) 		- 1 Enquire
013 400971235B
CABLE 		- 1 Enquire
015 400971793D
CABLE (CABLE STARTER MOTOR EXCITATION) 		- 1 Enquire
017 407971320D
WIRING HARNESS DASHBOARD (VERSIONS WITHOUT NAVIGATOR) 		- 1 Enquire
017 407971320F
WIRING HARNESS DASHBOARD (VERSIONS WITH NAVIGATOR) 		- 1 Enquire
018 400971679A
WIRING HARNESS (PASSENGER SIDE DRAWER) 		- 1 Enquire
019 400971899
CLAMP ( - 23 MM) 		- 4 Enquire
026 N10003703
SCREW M6X17.00 (M6X17) 		- 4 Enquire
