Exhaust System 2

Lamborghini Gallardo (2008)

Find Your Part

Lamborghini Gallardo (2008) - Exhaust System 2

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Exhaust System 2 of Lamborghini Lamborghini Gallardo (2008) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 N0245097
CLAMP 		$18.10 1
002 400611937C
HOSE 		$82.67 1
003 N10201901
CLAMP 		$2.02 (71.5% off) 1
004 400611921
CONNECTOR 		$2.02 (71.3% off) 1
005 443131541
VACUUM TANK ASSEMBLY 		$34.69 1
006 N10017303
NUT 		$0.48 (93.4% off) 1
007 7L131611
HOSE 		$25.15 1
008 400906217A
BRACKET 		$33.43 1
009 N0902612
SCREW (M6X20) 		$0.53 1
010 400131381B
PIPE 		$713.70 1
011 7L131694
BRACKET 		$6.11 5
012 WHT001194
SCREW
IN STOCK 		$0.37 (95% off) 6
013 400127217
CLAMP
IN STOCK 		$0.40 (94.5% off) 28
014 400131849A
HOSE 		$5.39 2
015 7M131208
PIPE 		$19.57 2
016 400131385E
PIPE 		$1,686.83 1
017 N90937701
CABLE TIES
IN STOCK 		$1.55 (22.5% off) 4
018 7M131543
PROTECTION 		$97.03 2
020 400131585A
CONNECTOR 		$2.63 1
021 400131846
HOSE 		$15.99 2
022 400131843
HOSE 		$112.63 1
023 400131791
CONNECTOR 		$0.68 1
024 7L131605A
HOSE 		$47.60 1
025 400131245A
CONNECTOR 		$82.95 1
027 400906407
BRACKET 		$11.17 1
028 N0161661
RIVET (4.0X10.0) 		$0.28 2
029 77906283
SOLENOID VALVE
IN STOCK 		$57.20 1
030 400131850B
HOSE 		$15.33 1
031 400131845A
HOSE 		$27.43 1
032 400133587
REDUCTION 		$32.14 1
033 7M131145A
PIPE 		$27.10 1
037 46905291B
NON-RETURN VALVE 		$15.81 1
