Front Suspension of Lamborghini Lamborghini Diablo VT (1993-1998)

View All

Lamborghini Diablo VT (1993-1998) - Front Suspension

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	WHT003355	NUT M12X1,25 IN STOCK	WHT003355 NUT M12X1,25 DADO IN STOCK	$21.86	4
002	410512383	FLEXIBLE BUSHING	410512383 FLEXIBLE BUSHING	$587.37	4
003	8101259	SCREW	8101259 SCREW VITE	$15.53	2
004	5134315	SPACER	5134315 SPACER DISTANZIALE	$35.93	2
005	8401234	WASHER	8401234 WASHER RONDELLA	$1.68 MSRP: ~~7.11~~ (76.4% off)	12
006	5133229	SCREW	5133229 SCREW VITE	$110.91	2
007	410512385	RUBBER RING IN STOCK	410512385 RUBBER RING IN STOCK	$53.43	4
008	5133618	SPRING	5133618 SPRING MOLLA	$199.13 MSRP: ~~206.50~~ (3.6% off)	2
009	5133344	ARM	5133344 ARM BRACCIO SUPERIORE DX	$1,679.09	1
009	5133345	ARM	5133345 ARM BRACCIO SUPERIORE SX	$1,758.70	1
010	5134392	TORSION BAR	5134392 TORSION BAR BARRA TORSIONE	$941.69	1
011	8101269	SCREW	8101269 SCREW VITE	$5.14	4
012	410407295B	2.0 MM ADJUSTMENT SHIM	410407295B 2.0 MM ADJUSTMENT SHIM DISTANZIALE 2 MM	$6.66	1
012	410407295D	WASHER	410407295D WASHER DISTANZIALE 3 MM	$29.71	1
012	5133488	SHIM	5133488 SHIM DISTANZIALE 1 ,5 MM	$3.25	1
012	410407295	1.0 MM ADJUSTMENT SHIM	410407295 1.0 MM ADJUSTMENT SHIM DISTANZIALE 1 MM	$4.52	1
012	410407295C	2.5 MM ADJUSTMENT SHIM	410407295C 2.5 MM ADJUSTMENT SHIM DISTANZIALE 2,5	$7.32	1
013	8921206	RESILIENT BUSHING	8921206 RESILIENT BUSHING BOCCOLA ELASTICA	$50.31	8
014	WHT003355	NUT M12X1,25 IN STOCK	WHT003355 NUT M12X1,25 DADO IN STOCK	$21.86	8
016	5238302	BUSHING IN STOCK	5238302 BUSHING BOCCOLA IN STOCK	$144.81	2
017	5230258	RETAINER	5230258 RETAINER CAVALLOTTO	$311.40	2
018	8410602	WASHER IN STOCK	8410602 WASHER RONDELLA IN STOCK	$44.87	4
019	8700609	SCREW	8700609 SCREW VITE	$0.53 MSRP: ~~7.31~~ (92.7% off)	4
020	5109714	BOOT	5109714 BOOT CAPPUCCIO	$26.25	4
021	5227297	BUSHING	5227297 BUSHING BOCCOLA	$32.36	8
022	8100810	SCREW	8100810 SCREW VITE	-	4	Enquire
023	417801931A	BALL JOINT	417801931A BALL JOINT GIUNTO SFERICO	$264.79	2
024	8201014	NUT	8201014 NUT DADO	$6.15	2
025	6209770	TIE ROD	6209770 TIE ROD TIRANTE	-	2	Enquire
026	8201016	NUT	8201016 NUT DADO	$22.76	2
027	5227295	BALL JOINT	5227295 BALL JOINT GIUNTO SFERICO	$152.72	2
028	410407127A	BOLT	410407127A BOLT PERNO CON ECCENTRICO	$2,318.56	4
029	410407127A	BOLT	410407127A BOLT ECCENTRICO	$2,318.56	4
030	5133039	ARM	5133039 ARM BRACCIO INFERIORE SX	$1,305.64	1
030	5133038	ARM	5133038 ARM BRACCIO INFERIORE DX	$1,305.64	1
031	WHT002941	SCREW M6X1X10	WHT002941 SCREW M6X1X10 VITE	$0.97 MSRP: ~~7.24~~ (86.6% off)	4
032	410407361B	COUPLING	410407361B COUPLING TESTA A SNODO	$1,260.75	2
033	410407171C	BUSH	410407171C BUSH BUSSOLA	$1,465.06	4
034	8201003	NUT	8201003 NUT DADO	$3.48	2
035	WHT000919	WASHER	WHT000919 WASHER	$14.99	2
036	5129541	BUSHING	5129541 BUSHING BUSSOLA	$47.35	2
037	410407365	Coupling	410407365 Coupling TESTA A SNODO	$262.75	2
038	8200804	NUT M8 IN STOCK	8200804 NUT M8 DADO IN STOCK	$1.16 MSRP: ~~7.28~~ (84.1% off)	4
039	5227298	BUSHING	5227298 BUSHING BOCCOLA	$17.62	4
040	5133165	SHOCK ABSORBER	5133165 SHOCK ABSORBER AMMORTIZZATORE ANTERIORE	$1,330.64	2
