Bumpers of Lamborghini Lamborghini Diablo VT (1993-1998)

View All

Lamborghini Diablo VT (1993-1998) - Bumpers

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	9430142	NET	9430142 NET RETE	$363.55	2
002	9463133	FRONT BUMPER	9463133 FRONT BUMPER PARAURTI ANTERIORE	-	1	Enquire
003	9430128	NET	9430128 NET RETE	$68.97	2
004	9453108	RIGHT AIR INTAKE	9453108 RIGHT AIR INTAKE PRESA D'ARIA DX	$254.97 MSRP: ~~267.00~~ (4.5% off)	1
005	9453109	PIPE	9453109 PIPE TUBO	$89.34	2
006	410807255	5.0 MM SHIM	410807255 5.0 MM SHIM SPESSORE Dl REGISTRO	$153.25	1
007	7063145	SHIM	7063145 SHIM use : 410807567	-	1	Enquire
008	9463115	SHIM	9463115 SHIM SPESSORE Dl REGISTRO	$25.69 MSRP: ~~26.85~~ (4.3% off)	1
009	9463117	SCREW	9463117 SCREW VITE	$46.59	2
010	8100810	SCREW	8100810 SCREW VITE	-	2	Enquire
011	WHT001942	WASHER IN STOCK	WHT001942 WASHER RONDELLA IN STOCK	$3.30	4
012	7063142	WASHER	7063142 WASHER SPESSORE Dl REGISTRO	$17.56 MSRP: ~~18.30~~ (4% off)	2
013	9463109	WASHER	9463109 WASHER RONDELLA	$43.12 MSRP: ~~43.60~~ (1.1% off)	4
014	9463110	SPACER	9463110 SPACER DISTANZIALE	$15.21	1
014	9463111	SPACER	9463111 SPACER DISTANZIALE	$28.47 MSRP: ~~28.80~~ (1.1% off)	1
015	8200804	NUT M8 IN STOCK	8200804 NUT M8 DADO IN STOCK	$1.16 MSRP: ~~7.28~~ (84.1% off)	2
016	8220506	CLIP IN STOCK	8220506 CLIP MOLLETTA IN STOCK	$42.51	14
017	9453115	LEFT AIR INTAKE	9453115 LEFT AIR INTAKE PRESA D'ARIA SX	$254.97 MSRP: ~~267.00~~ (4.5% off)	1
018	8100831	SCREW	8100831 SCREW VITE	$0.25 MSRP: ~~7.35~~ (96.6% off)	2
019	WHT001942	WASHER IN STOCK	WHT001942 WASHER RONDELLA IN STOCK	$3.30	4
020	9463207	SPACER	9463207 SPACER DISTANZIALE	$122.94	2
021	9463005	REAR BUMPER	9463005 REAR BUMPER PARAURTI POSTERIORY	$10,911.88	1
022	9463204	SHIELD	9463204 SHIELD PROTEZIONE	$243.19	2
023	8200804	NUT M8 IN STOCK	8200804 NUT M8 DADO IN STOCK	$1.16 MSRP: ~~7.28~~ (84.1% off)	4
024	WHT001942	WASHER IN STOCK	WHT001942 WASHER RONDELLA IN STOCK	$3.30	4
025	9463220	PLATE	9463220 PLATE PIASTRA	$38.85	2
026	9463209	PLATE	9463209 PLATE PIASTRA	$11.31 MSRP: ~~11.45~~ (1.2% off)	2
027	9463208	SUPPORT - SUPPORTO	9463208 SUPPORT - SUPPORTO O	$244.64	2
028	8200804	NUT M8 IN STOCK	8200804 NUT M8 DADO IN STOCK	$1.16 MSRP: ~~7.28~~ (84.1% off)	4
029	8400801	WASHER	8400801 WASHER RONDELLA	$0.68	4
030	8300820	STUD	8300820 STUD PRIGIONIERO	$2.48 MSRP: ~~7.03~~ (64.7% off)	4
031	9466112	BRACKET	9466112 BRACKET STAFFA	$227.27	2
032	9466111	BRACKET	9466111 BRACKET STAFFA	$179.48	2
