Driveshafts and Propeller Shaft of Lamborghini Lamborghini Diablo VT (1993-1998)

View All

Lamborghini Diablo VT (1993-1998) - Driveshafts and Propeller Shaft

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	2534887	BOOT KIT	2534887 BOOT KIT KIT CUFFIA	-	2	Enquire
002	2534274	PLATE	2534274 PLATE PIASTRINA	-	6	Enquire
003	8410812	WASHER	8410812 WASHER RONDELLA	-	12	Enquire
004	8700802	SCREW	8700802 SCREW VITE	-	12	Enquire
005	2534283	RIGHT HALF SHAFT	2534283 RIGHT HALF SHAFT SEMIASSE DESTRO	-	1	Enquire
006	2234277	PROPELLER SHAFT	2234277 PROPELLER SHAFT ALBERO TRASMISSIONE	-	1	Enquire
007	8700802	SCREW	8700802 SCREW VITE	-	12	Enquire
008	8410812	WASHER	8410812 WASHER RONDELLA	-	12	Enquire
009	2234273	PLATE	2234273 PLATE PIASTRINA	-	6	Enquire
010	2434496	RUBBER PAD	2434496 RUBBER PAD TAMPONEGOMMA	-	1	Enquire
011	2530901	SHIELD	2530901 SHIELD PROTEZIONE	-	1	Enquire
012	WHT003053	WASHER	WHT003053 WASHER RONDELLA	-	2	Enquire
013	8100613	SCREW	8100613 SCREW VITE	-	2	Enquire
014	2530896	Shield	2530896 Shield PROTEZIONE	-	1	Enquire
015	2534285	RIGHT HALF SHAFT	2534285 RIGHT HALF SHAFT SEMIASSE DESTRO	-	1	Enquire
016	N10667901	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	N10667901 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD VITE	-	24	Enquire
017	8411011	WASHER	8411011 WASHER RONDELLA	-	24	Enquire
018	2533290	PLATE	2533290 PLATE PIASTRINA	-	12	Enquire
019	2534286	LEFT HALF SHAFT	2534286 LEFT HALF SHAFT SEMIASSE SINISTRO	-	1	Enquire
020	2512808	KIT SEMIASSE	2512808 KIT SEMIASSE use : 002537315	-	4	Enquire
021	2234523	GASKET	2234523 GASKET GUARNIZIONE	-	2	Enquire
022	2534666	GASKET	2534666 GASKET GUARNIZIONE	-	2	Enquire
023	2534284	LEFT HALF SHAFT	2534284 LEFT HALF SHAFT SEMIASSE SINISTRO	-	1	Enquire
