Lamborghini Diablo SV (1995-1997) - Rear Suspension

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	WHT003355	NUT M12X1,25	WHT003355 NUT M12X1,25 DADO	-	4	Enquire
001	WHT003355	NUT M12X1,25	WHT003355 NUT M12X1,25 DADO	-	8	Enquire
002	410407127A	BOLT	410407127A BOLT ECCENTRICO	-	8	Enquire
003	410407295C	2.5 MM ADJUSTMENT SHIM	410407295C 2.5 MM ADJUSTMENT SHIM SPESSORE 2,5 MM	-	1	Enquire
003	5133488	SHIM	5133488 SHIM SPESSORE 1,5 MM	-	1	Enquire
003	410407295B	2.0 MM ADJUSTMENT SHIM	410407295B 2.0 MM ADJUSTMENT SHIM SPESSORE 2 MM	-	1	Enquire
003	410407295D	WASHER	410407295D WASHER SPESSORE 3 MM	-	1	Enquire
003	410407295	1.0 MM ADJUSTMENT SHIM	410407295 1.0 MM ADJUSTMENT SHIM SPESSORE 1 MM	-	1	Enquire
004	8921206	RESILIENT BUSHING	8921206 RESILIENT BUSHING BOCCOLA ELASTICA	-	8	Enquire
005	410407127A	BOLT	410407127A BOLT PERNO CON ECCENTRICO	-	8	Enquire
006	8200809	NUT	8200809 NUT DADO	-	4	Enquire
007	5227297	BUSHING	5227297 BUSHING BOCCOLA	-	8	Enquire
008	5227298	BUSHING	5227298 BUSHING BOCCOLA	-	4	Enquire
009	5109714	BOOT	5109714 BOOT CUFFIA	-	4	Enquire
010	8100807	SCREW	8100807 SCREW VITE	-	4	Enquire
011	5234393	TORSION BAR	5234393 TORSION BAR BARRA TORSIONE	-	1	Enquire
012	WHT002960	SCREW	WHT002960 SCREW VITE	-	4	Enquire
013	8410602	WASHER	8410602 WASHER RONDELLA	-	4	Enquire
014	5230258	RETAINER	5230258 RETAINER CAVALLOTTO	-	2	Enquire
015	5238302	BUSHING	5238302 BUSHING BOCCOLA	-	2	Enquire
016	410512383	FLEXIBLE BUSHING	410512383 FLEXIBLE BUSHING	-	8	Enquire
017	8101269	SCREW	8101269 SCREW VITE	-	8	Enquire
018	410512385	RUBBER RING	410512385 RUBBER RING	-	8	Enquire
019	5226157	SPRING	5226157 SPRING MOLLA	-	4	Enquire
020	5233269	SHOCK ABSORBER	5233269 SHOCK ABSORBER AMMORTIZZATORE	-	4	Enquire
021	417801931A	BALL JOINT	417801931A BALL JOINT GIUNTO SFERICO	-	2	Enquire
022	8201034	NUT	8201034 NUT DADO	-	2	Enquire
023	5209770	TIE ROD	5209770 TIE ROD TIRANTE	-	2	Enquire
024	8201035	NUT	8201035 NUT DADO	-	2	Enquire
025	5227295	BALL JOINT	5227295 BALL JOINT GIUNTO SFERICO	-	2	Enquire
026	8251702	PLUG	8251702 PLUG GHIERA	-	4	Enquire
027	8401708	WASHER	8401708 WASHER RONDELLA	-	4	Enquire
028	5225207	RESILIENT BUSHING	5225207 RESILIENT BUSHING BOCCOLA ELASTICA	-	8	Enquire
029	8401710	WASHER	8401710 WASHER RONDELLA	-	24	Enquire
030	5225906	ARM	5225906 ARM BRACCIO INFERIORE DX	-	1	Enquire
030	5225907	ARM	5225907 ARM BRACCIO INFERIORE SX	-	1	Enquire
031	5225204	PIN	5225204 PIN PERNO	-	2	Enquire
032	5225908	RH UPPER SUSPENSION ARM	5225908 RH UPPER SUSPENSION ARM	-	1	Enquire
032	5225909	ARM	5225909 ARM BRACCIO SUPERIORE SX	-	1	Enquire
033	5225205	PIN	5225205 PIN PERNO	-	2	Enquire
